IEI Technology iSDV-200CTR User Manual

Sdvoe transmitter / receiver, semtech blueriver avp2000t, dual 128mx16 ddr3, 1gbe rj-45, 10gbe rj-45/sfp+, audio, ir in/out, two hdmi 2.0, usb-hid, rs-232, rohs compliant
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
iSDV-200CTR
System
MODEL:
iSDV-200CTR
SDVoE Transmitter/Receiver, Semtech BlueRiver® AVP2000T,
Dual 128Mx16 DDR3, 1GbE RJ-45, 10GbE RJ-45/SFP+, Audio,
IR In/Out, Two HDMI 2.0, USB-HID, RS-232, RoHS Compliant
User Manual
Page I
Rev. 1.00 – August 2, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iSDV-200CTR and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology iSDV-200CTR

Summary of Contents for IEI Technology iSDV-200CTR

  • Page 1 System MODEL: iSDV-200CTR SDVoE Transmitter/Receiver, Semtech BlueRiver® AVP2000T, Dual 128Mx16 DDR3, 1GbE RJ-45, 10GbE RJ-45/SFP+, Audio, IR In/Out, Two HDMI 2.0, USB-HID, RS-232, RoHS Compliant User Manual Page I Rev. 1.00 – August 2, 2022...
  • Page 2 Revision Date Version Changes August 2, 2022 1.00 Initial release Page II...
  • Page 3 Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 F ......................3 RONT ANEL 1.3.1 LED Indicators ....................3 1.4 R ......................5 ANEL 1.5 T ..................5 ECHNICAL PECIFICATIONS 2 UNPACKING .........................
  • Page 6 4 SOFTWARE APPLICATION ..................22 4.1 I ......................23 NTRODUCTION 4.2 S ..................23 OFTWARE NSTALLATION 4.2.1 Microsoft Windows 10/11 ................. 24 4.2.2 Ubuntu 18.04 ....................27 4.2.3 QNAP QTS 5.0 ....................28 4.3 M ......................29 4.4 O ....................
  • Page 7 List of Figures Figure 1-1: iSDV-200CTR Transceiver ..................2 Figure 1-2: Front Panel ........................3 Figure 1-3: Rear Panel ........................5 Figure 3-1: USB HID Mode Switch Location ................12 Figure 3-2: HDMI Connector ......................13 Figure 3-3: RJ-45 Ethernet Connector ..................15 Figure 3-4: 10GbE SFP+ Connector ....................
  • Page 8 List of Tables Table 1-1: LED Indicators ......................4 Table 1-2: Technical Specifications ....................6 Table 2-1: Package List ........................9 Table 3-1: USB HID Mode Selection .................... 12 Table 3-2: HDMI Connector Pinouts ................... 13 Table 3-3: IR Receiver Cable Pinouts ..................14 Table 3-4: IR Blaster Cable Pinouts ....................

  • Page 9: Introduction

    Chapter Introduction Page 1...

  • Page 10: Overview

    1.1 Overview Figure 1-1: iSDV-200CTR Transceiver The iSDV-200CTR is a 4K HDR SDVoE IP combo transceiver with a Semtech BlueRiver® AVP2000T AV processor and two on-board 128Mx16 DDR3 memory. With its 10GbE combo port design, the iSDV-200CTR allows streaming over copper cable or fiber cable in one single device to deliver zero-latency video and audio for live event, video wall or situation room.

  • Page 11: Front Panel

    1.3 Front Panel The front panel of the iSDV-200CTR are shown in F igure 1-2. 6 9 2 H 6 9 2 H Figure 1-2: Front Panel 1.3.1 LED Indicators The descriptions of each LED indicator on the front panel are listed below.

  • Page 12: Table 1-1: Led Indicators

    Video Out Green Video Out Stable Reflects status of HDMI signal received from a transmitter as transported over the 10GbE link to the receiver. 10G Tx Green 10G Tx LED Indicates if Ethernet packets are transmitting. Off: No packets transmitting.

  • Page 13: Rear Panel

    1.4 Rear Panel The rear panel of the iSDV-200CTR are shown in Figure 1-3. Figure 1-3: Rear Panel 1.5 Technical Specifications The specifications for the iSDV-200CTR are listed below. iSDV-200CTR AV Processor BlueRiver® AVP2000T Memory 2 x 128Mx16 DDR3 onboard Video Interfaces HDMI 2.0 supporting all resolutions up to 594MHz...

  • Page 14: Table 1-2: Technical Specifications

    I/O Ports 1 x 1GbE LAN 1 x 3.5mm audio-in jack 1 x 10GbE LAN 1 x 3.5mm audio-out jack 1 x 10GbE SFP+ 4 x USB-HID 1 x IR in 2 x RS-232 1 x IR out 9 x LED indicator 1 x HDMI 2.0 in...

  • Page 15: Unpacking

    Chapter Unpacking Page 7...

  • Page 16: Npacking

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the iSDV-200CTR was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 17: Table 2-1: Package List

    Power adapter (40 W) Power cord USB cable (Type A to Type A) Screw pack Table 2-1: Package List Page 9...

  • Page 18: Hardware Installation

    Chapter Hardware Installation Page 10...

  • Page 19: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the iSDV-200CTR. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the iSDV-200CTR or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 20: Usb Hid Mode Selection

    3.3 USB HID Mode Selection The iSDV-200CTR has one USB remote port on the front panel and four USB-HID ports on the rear panel. The USB remote port is for connecting with PC; the USB-HID ports are for connecting USB devices such as keyboard and mouse.

  • Page 21: External Peripheral Interface Connection

    3.4 External Peripheral Interface Connection The following section describes each external peripheral interface connector in details. 3.4.1 HDMI Connectors Use the HDMI input connector to connect with a video/graphic source device; use the HDMI output connector to connect with an output display. The HDMI connectors support up to 4K @ 60Hz.

  • Page 22: Infrared Connectors

    3.4.2 Infrared Connectors The iSDV-200CTR has one IR-out connector and one IR-in connector, both in 3.5 mm jacks.  IR In: for connecting an IR receiver  IR Out: for connecting an IR blaster. Description IR Receiver Cable Power...

  • Page 23: Lan Connector - 1Gbe

    3.4.3 LAN Connector – 1GbE The 1GbE connector allows connection to an Ethernet supporting device. Description Description MDIA0+ MDIA2- MDIA0- MDIA1- MDIA1+ MDIA3+ MDIA2+ MDIA3- Table 3-5: LAN Connector Pinouts Figure 3-3: RJ-45 Ethernet Connector Page 15...

  • Page 24: Lan Connector - 10Gbe

    3.4.4 LAN Connector - 10GbE The iSDV-200CTR is equipped with two types of 10GbE connector – one SFP+ connector and one RJ-45 connector. Users can choose either one of the 10GbE connectors to connect the iSDV-200CTR with a 10GbE network switch.

  • Page 25: 10Gbe Rj-45

    Description Description RX_LOS Table 3-6: 10GbE SFP+ Pinouts Figure 3-4: 10GbE SFP+ Connector 3.4.4.2 10GbE RJ-45 The 10GbE RJ-45 connector on the rear panel allows transfer rate of up to 10 gigabits per second. The pinouts of the 10GbE RJ-45 connector are listed below.

  • Page 26: Power Connector

    3.4.5 Power Connector The connector supports 12 V power adapters. Description Table 3-8: Power Connector Pinouts Figure 3-6: Power Connector 3.4.6 RS-232 Serial Port Connectors The RS-232 serial port connectors allow connection to a serial device. The pinouts are detailed below.

  • Page 27: Power-On Procedure

    Step 3: The LEDs on the front panel will blink (except video) for about 5-10 seconds. When the LEDs stop blinking release the reset button. Step 4: The iSDV-200CTR completes its boot-up process and restoring the factory default settings. Page 19...

  • Page 28: Configuration Examples

    Figure 3-7: Reset Button Location 3.7 Configuration Examples The following diagrams provide users some advanced configuration examples of the iSDV-200CTR, including video wall, matrix and multiview. 3.7.1 Video Wall Page 20...

  • Page 29: Matrix

    3.7.2 Matrix 3.7.3 Multiview Page 21...

  • Page 30: Software Application

    Chapter Software Application Page 22...

  • Page 31: Introduction

    4.1 Introduction The iSDV Network Video Orchestrator is a free software to manage all your iSDV devices from a central console. The free software can run in different platforms, and has intuitive user interface allowing you to setup Tx and Rx modes, quickly configure display array, and check the status of all devices in real-time.

  • Page 32: Microsoft Windows 10/11

    Step 1: Download the software from IEI Resource Download Center: Go to https://download.ieiworld.com. Type iSDV-200CTR and press Enter. Download and save the iSDV installer (for Windows) to the computer. Step 2: Double click the iSDV installer to start the installation.
  • Page 33 Step 4: The Ready to Install window appears. Click Install to start installing the software. Step 5: After the installation process is complete, a confirmation screen appears. Click Finish to exit the program. Page 25...
  • Page 34 Step 6: Click the iSDV web app to start using iSDV Network Video Orchestrator. Step 7: Log in the app. The default username and password are: Username: admin Password: admin Page 26...

  • Page 35: Ubuntu 18.04

    Step 1: Download the software from IEI Resource Download Center: Go to https://download.ieiworld.com. Type iSDV-200CTR and press Enter. Download and save the iSDV software (for Ubuntu) to the computer. Step 2: Enter into Ubuntu 18.04 Desktop Version.

  • Page 36: Qnap Qts 5.0

    4.2.3 QNAP QTS 5.0 To install iSDV Network Video Orchestrator in a computer running QNAP QTS 5.0 OS, follow the steps below. Step 1: Launch App Center in QNAP QTS 5. Step 2: Search for “iSDV”. Step 3: Click the Install button to install the iSDV application.

  • Page 37: Main Menu

    The main menu located on the top the user interface contains four buttons to access the main function pages of the application. The main function of each button is described in the following table. Operation Mode Deploy display setting to the iSDV-200CTR devices Configuration Setup device setting, group devices, and configure display array Global Setting...

  • Page 38: Operation Mode

    The operation mode features are shown in Figure 4-1. Figure 4-1: Operation Mode Transmitter List Lists all of the iSDV-200CTR transmitters Display Layout Allows users to deploy transmitters Information Shows the information of the device and the display array.

  • Page 39: Transmitter List

    4.4.1 Transmitter List All of the iSDV-200CTR transmitters are shown in the transmitter list. The following setting can also be configured in the Transmitter List.  Display on/off  Audio on/off Page 31...

  • Page 40: Display Layout

    4.4.2 Display Layout Use this interface to deploy transmitters and receivers. You can drag one or multiple transmitters from the transmitter list onto the display layout to setup a video wall or multiview layout. IEI Network Video Orchestrator allows users to create various video wall matrix such as 2x2, 3x4 and 6x6.

  • Page 41: Information

    4.4.3 Information The Information section contains two sub-page - Device and Display Array. The Device page shows the information of the selected device; it also includes some options for users to configure the device. The Display Array page shows the information of the display array you are working on, and allows users to setup bezel compensation.

  • Page 42: Configuration

    Display Array page Use this page to configure the following settings:  Display Array Name  Bezel Compensation The following information is shown for reference:  Columns  Rows  Device Count  Resolution  FPS 4.5 Configuration Three subpages are available in Configuration – Device Setup, Display and Device Summary.

  • Page 43: Device Setup

    4.5.1 Device Setup Use the Device Setup page to configure the following settings:  DHCP  MCU Firmware Update  Claim  RS-232 Setting  Add/Delete/Change Group  HDMI Mode Setting  iSDV Firmware Update  Audio The following information is shown in the Device Setup for reference: ...

  • Page 44: Display

    In the Display page, users can setup the matrix size and deploy the connected receivers onto the matrix by drag-and-drop operation. Receiver List Lists all of the iSDV-200CTR receivers Allows users to create a new display array, deploy receivers or Display Array delete receiver device.

  • Page 45: Device Summary

    4.5.3 Device Summary The Device Summary page shows the information of all the connected iSDV devices, including:  Status  Firmware  Temperature  IP Address  Name  Subnet Mask  Type  Gateway  Claim  ID...

  • Page 46: Global Setting

    4.6 Global Setting The Global Setting page allows users to download device logs, reboot devices, and restore the devices to factory default. Figure 4-3: Global Setting 4.7 Log The Log page displays device logs. Figure 4-4: Log Page 38...

  • Page 47: How To Setup A Video Wall

    4.8 How to Setup a Video Wall To setup a 2x2 video wall in IEI Network Video Orchestrator, follow the steps below. Step 1: Go to Configuration  Display page. Step 2: Click the Create button to set up a 2x2 display array in the pop-up window.
  • Page 48 Step 5: Go to Operation Mode page. Step 6: Drag a transmitter from the transmitter list onto the display array. Step 7: Drag the bottom right corner of the transmitter block to enlarge it, enabling the transmitter to cover all of the receiver blocks.

  • Page 49: How To Setup Multiview

    4.9 How to Setup Multiview To setup multiview in IEI Network Video Orchestrator, follow the steps below. Step 1: Go to Configuration  Display page. Step 2: Click the Create button to set up a 1x1 display array in the pop-up window.
  • Page 50 Page 42...

  • Page 51: A Regulatory Compliance

    Appendix Regulatory Compliance Page 43...
  • Page 52 DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU)  Low-Voltage Directive (2006/95/EC, 2014/35/EU)  RoHS II Directive (2011/65/EU, 2015/863/EU)  Ecodesign Directive 2009/125/EC  If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 53 Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
  • Page 54 Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU.
  • Page 55 FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and  This device must accept any interference received, including interference that ...

  • Page 56: B Safety Precautions

    Appendix Safety Precautions Page 48...

  • Page 57: Safety Precautions

    Electric shocks can occur if the iSDV-200CTR chassis is opened when it is  running. To avoid risk of electric shock, this device must only be connected to a supply mains with protective earth.

  • Page 58: Product Disposal

     DO NOT: Drop the device against a hard surface. In a site where the ambient temperature exceeds the rated temperature B.1.2 Product Disposal  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 59: Maintenance And Cleaning Precautions

    Always make sure your hands are dry when unplugging the power cable. Prior to cleaning any part or component of the iSDV-200CTR, please read the details below. Never spray or squirt liquids directly onto any other components.

  • Page 60: C Hazardous Materials Disclosure

    Appendix Hazardous Materials Disclosure Page 52...

  • Page 61: Rohs Ii Directive (2015/863/Eu)

    C.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 62: China Rohs

    C.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 54...
