IVS-110 Embedded System
eIVS-110 Embedded System
MODEL:
MODEL:
IVS-110
IEI Fanless Embedded System with Intel® Atom® x7-E39xx
Processor, 4 GB DDR3L, RS-232/422/485, OBD-II,
On-board GPS, HDMI, VGA, Dual SIM Slot, RoHS Compliant,
User Manual
Page i
Rev. 1.00 – January 31, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVS-110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology IVS-110

Summary of Contents for IEI Technology IVS-110

  • Page 1 IVS-110 Embedded System eIVS-110 Embedded System MODEL: MODEL: IVS-110 IEI Fanless Embedded System with Intel® Atom® x7-E39xx Processor, 4 GB DDR3L, RS-232/422/485, OBD-II, On-board GPS, HDMI, VGA, Dual SIM Slot, RoHS Compliant, User Manual Page i Rev. 1.00 – January 31, 2018...
  • Page 2 IVS-110 Embedded System Revision Date Version Changes January 31, 2018 1.00 Initial release Page ii...
  • Page 3 IVS-110 Embedded System Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 IVS-110 Embedded System Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
  • Page 5 IVS-110 Embedded System Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 6 IVS-110 Embedded System Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 7: Table Of Contents

    IVS-110 Embedded System Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 B ........................2 ENEFITS 1.3 F ........................3 EATURES 1.4 M ....................3 ODEL ARIATIONS 1.5 F ......................4 RONT ANEL 1.5.1 LED Indicators ....................4 1.6 R...
  • Page 8 IVS-110 Embedded System 3.9.1 VESA Mount ..................... 29 3.10 E I/O C ................. 30 XTERNAL ONNECTORS 3.10.1 COM Port Connection ................... 30 3.10.2 DIO Connection ..................... 31 3.10.3 OBD-II Connection ..................32 3.11 P ..................33 OWER ROCEDURE 3.11.1 Installation Checklist..................33 3.11.2 Power Input Connection .................
  • Page 9 IVS-110 Embedded System 4.3.10 IEI Feature ..................... 61 4.4 C ........................62 HIPSET 4.4.1 North Bridge Configuration ................63 4.4.1.1 Intel IGD Configuration ................63 4.4.2 South Bridge Configuration ................65 4.4.2.1 HD-Audio Configuration ................66 4.4.2.2 PCI Express Configuration ............... 67 4.4.2.3 SATA Configuration ..................
  • Page 10 IVS-110 Embedded System B.1.2 Anti-static Precautions ..................93 B.1.3 Product Disposal ..................... 94 B.2 M ............95 AINTENANCE AND LEANING RECAUTIONS B.2.1 Maintenance and Cleaning ................95 B.2.2 Cleaning Tools ....................95 C BIOS MENU OPTIONS ..................... 97 C.1 BIOS C ................
  • Page 11 IVS-110 Embedded System List of Figures Figure 1-1: IVS-110 Series Embedded System ................2 Figure 1-2: Front Panel ........................4 Figure 1-3: LED Indicators ......................4 Figure 1-4: Rear Panel ........................5 Figure 1-5: Bottom Panel ....................... 6 Figure 1-6: Dimensions (mm) ......................7 Figure 3-1: Bottom Panel Retention Screws ................
  • Page 12 IVS-110 Embedded System List of Tables Table 1-1: Model Variations ......................3 Table 1-2: LED Indicators ......................5 Table 1-3: Technical Specifications ....................9 Table 2-1: Package List ........................ 12 Table 2-2: Optional Items ......................13 Table 3-1: mSATA/E-Window Module Slot (MINI-PCIE3) Pinouts ..........21 Table 3-2: WWAN Module Slot (MINI-PCIE1) Pinouts ...............
  • Page 13 IVS-110 Embedded System List of BIOS Menus BIOS Menu 1: Main ........................42 BIOS Menu 2: Advanced ......................43 BIOS Menu 3: Trusted Computing ....................44 BIOS Menu 4: ACPI Settings ....................... 45 BIOS Menu 5: F81866 Super IO Configuration ................46 BIOS Menu 6: Serial Port n Configuration Menu ...............

  • Page 15: Introduction

    IVS-110 Embedded System Chapter Introduction Page 1...

  • Page 16: Overview

    / x7-E3930 processor. It is designed for in-vehicle applications that require minimum installation space. The IVS-110 accepts a wide range of DC power input (9 V–36 V), allowing it to be powered anywhere. Wi-Fi and WWAN capabilities plus one RJ-45 Ethernet connector ensure smooth network connectivity.

  • Page 17: Features

     Optional 802.11a/b/g/n/ac wireless connection 1.4 Model Variations There are three models in the IVS-110 embedded system series. The three models are all preinstalled with 4 GB of DDR3L memory. The model variations are listed in Table 1-1 below. Processor ®...

  • Page 18: Front Panel

    IVS-110 Embedded System 1.5 Front Panel An overview of the front panel is shown in Figure 1-2 below. Figure 1-2: Front Panel 1.5.1 LED Indicators The LED indicators on the front panel show the status of power, HDD, Wi-Fi and GPRS/HSUPA connection.

  • Page 19: Rear Panel

    IVS-110 Embedded System The WWAN module is not installed or the SIM slot is not being used. SIM LED Green The WWAN module is installed and the SIM slot is being used for WWAN connection. The Wi-Fi module is not installed.

  • Page 20: Bottom Panel

    IVS-110 Embedded System 1.7 Bottom Panel The bottom panel of the IVS-110 contains several screw holes for VESA mount and wall mounting brackets. The bottom panel also provides access to the internal components, including SATA drive bay, mSATA slot and PCIe Mini card slots.

  • Page 21: Dimensions

    IVS-110 Embedded System 1.8 Dimensions The dimensions of the IVS-110 are listed below and shown in Figure 1-6. Figure 1-6: Dimensions (mm) Page 7...

  • Page 22: Technical Specifications

    IVS-110 Embedded System 1.9 Technical Specifications The specifications for the Intel based embedded systems are listed below. IVS-110 ® CPU (SoC) Intel Atom® x7-E3950 (quad-core, 2.0 GHz, 12W TDP) ® Intel Atom® x7-E3940 (quad-core, 1.8 GHz, 9.5W TDP) ® Intel Atom®...

  • Page 23: Table 1-3: Technical Specifications

    IVS-110 Embedded System Expansion Slot 1 x Full/Half-size PCIe Mini slot (reserved for WWAN) 1 x Full/Half-size PCIe Mini slot (reserved for mSATA or IEI E-Window module) 1 x Half-size PCIe Mini slot (reserved for WLAN) Indicators 2 x SIM LED...

  • Page 24: Unpacking

    IVS-110 Embedded System Chapter Unpacking Page 10...

  • Page 25: Unpacking

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the IVS-110 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 26: Optional Items

    IVS-110 Embedded System Mounting brackets Screws (M3*8) for mounting brackets Screws (M4*5) for VESA mounting Screws (M3*5) for SSD installation Screws (M2*3) for PCIe module installation Driver and manual CD Table 2-1: Package List 2.3 Optional Items The following are optional component(s) which may be separately purchased:...

  • Page 27: Table 2-2: Optional Items

    IVS-110 Embedded System ACC power cable (P/N: 32002-001900-100-RS) OBD-II cable (P/N: 32025-003400-100-RS) Wi-Fi kit with AW-CB161H 802.11a/b/g/n/ac and Bluetooth 4.0 combo module (P/N: IVS-WIFI-KIT02-R10) WWAN kit (P/N: IVS-3G-KIT02-R10) GPS/LTE antenna (supports 2G/3G/4G) (P/N: 32506-000400-100-RS) Table 2-2: Optional Items Page 13...

  • Page 28: Installation

    IVS-110 Embedded System Chapter Installation Page 14...

  • Page 29: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the WAFER series motherboard and the power module. (Dry climates are especially susceptible to ESD.) It is therefore critical that whenever the IVS-110 is opened and any electrical component handled, the following anti-static precautions are strictly adhered to.

  • Page 30: High Surface Temperature

    Air Circulation: Make sure there is sufficient air circulation when installing the IVS-110. The IVS-110’s cooling vents must not be obstructed by any objects. Blocking the vents can cause overheating of the IVS-110. Leave at least 5 cm of clearance around the IVS-110 to prevent overheating.

  • Page 31: Open The Bottom Cover

    Before the internal component can be installed, the bottom cover must be removed to access the main board. To remove the back cover, please follow the steps below: Step 1: Turn the IVS-110 over. Step 2: Remove the bottom panel retention screws to detach the bottom panel from the chassis (Figure 3-1).

  • Page 32: Pcie Mini / Msata Card Installation

    IVS-110 Embedded System Figure 3-1: Bottom Panel Retention Screws Step 3: Lift and carefully remove the bottom cover. Please be noted that a bracket for installing SSD is attached on the inside of the bottom cover. Be careful when removing the bottom cover.

  • Page 33: Figure 3-2: Pcie Mini Slot Location

    IVS-110 Embedded System Figure 3-2: PCIe Mini Slot Location Step 3: Line up the notch on the card with the notch on the slot. Slide the PCIe Mini card into the socket at an angle of about 20º (Figure 3-3).

  • Page 34: Msata/E-Window Module Slot (Mini-Pcie3) Pinouts

    IVS-110 Embedded System Figure 3-4: Securing the Full-size PCIe Mini Card 3.5.1 mSATA/E-Window Module Slot (MINI-PCIE3) Pinouts The pinouts for the mSATA/E-Window module slot (MINI-PCIE3) are listed in the table below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION WAKE# VCC3 VCC1.5...

  • Page 35: Wlan/Wwan Module Installation

    IVS-110 Embedded System PCIE_TXN SMB_DATA PCIE_TXP USB_DATA_N USB_DATA_P VCC3 VCC3 VCC1.5 SATADET# VCC3 Table 3-1: mSATA/E-Window Module Slot (MINI-PCIE3) Pinouts 3.6 WLAN/WWAN Module Installation To install the optional WLAN or WWAN module, please follow the steps below. Step 1: Open the bottom cover. See Section 3.4.

  • Page 36: Wwan Module Slot (Mini-Pcie1) Pinouts

    IVS-110 Embedded System Step 3: Line up the notch on the WLAN/WWAN module with the notch on the slot. Slide the WLAN/WWAN module into the slot at an angle of about 20º. Step 4: Secure the WLAN/WWAN module with the M2*3 screw shipped with the IVS-110.

  • Page 37: Wlan Module Slot (Mini-Pcie2) Pinouts

    IVS-110 Embedded System HSUPA_ON VCC3 VCC1.5 USB_DATA_N USB_DATA_P VCC3 VCC3 3GLED_EN VCC1.5 VCC3 Table 3-2: WWAN Module Slot (MINI-PCIE1) Pinouts 3.6.2 WLAN Module Slot (MINI-PCIE2) Pinouts The pinouts for the WLAN module slot (MINI-PCIE2) are listed in the table below.

  • Page 38: Sim Card Installation

    To be able to use the WWAN network connection, SIM cards must be installed in the IVS-110. Follow the steps below to install SIM cards. Step 1: Install a WWAN module into the IVS-110. See Section 3.6. Step 2: Remove the two retention screws (Figure 3-7) to detach the SIM slot cover.

  • Page 39: Figure 3-8: Sim Card Slot Locations

    IVS-110 Embedded System Step 3: Locate the SIM card slots on the rear panel (Figure 3-8). Figure 3-8: SIM Card Slot Locations Step 4: Insert a SIM card into the SIM 1 slot with the gold contacts facing down. Insert a SIM card into the SIM 2 slot with the gold contacts facing up.

  • Page 40: Solid-State Drive Installation

    IVS-110 Embedded System 3.8 Solid-State Drive Installation One 2.5” SATA SSD can be installed in the IVS-110. The SATA SSD is installed into a hard drive bracket attached on the inside of the bottom surface. To install the SSD into the system, please follow the steps below.

  • Page 41: Figure 3-10: Ssd Retention Screws

    IVS-110 Embedded System Figure 3-10: SSD Retention Screws Step 5: Connect the SATA cable to the SATA connector and SATA power connector on the motherboard. Step 6: Re-install the SSD bracket onto the bottom surface by aligning the four retention screw holes in the SSD bracket to the four screw holes on the bottom surface and securing with the four previously removed retention screws.

  • Page 42: Mounting The System

    IVS-110 Embedded System 3.9 Mounting the System To mount the embedded system onto a wall or some other surface using the two mounting brackets, please follow the steps below. Step 1: Turn the embedded system over. Step 2: Align the two retention screw holes in each bracket with the retention screw holes on the sides of the bottom surface.

  • Page 43: Vesa Mount

    The IVS-110 is VESA (Video Electronics Standards Association) compliant and can be mounted on a mounting device with a 100 mm interface pad. The IVS-110 VESA mount retention screw holes are shown in Figure 3-12. Refer to the installation guide that came with the mounting device to mount the IVS-110.

  • Page 44: External I/O Connectors

    IVS-110 Embedded System 3.10 External I/O Connectors This section provides an overview of the external I/O connectors of the IVS-110. 3.10.1 COM Port Connection The IVS-110 has one DB-9 connectors for RS-232/422/485 serial port connection. The pinouts for the RS-232/422/485 connector (COM1) are listed in the figure and table below.

  • Page 45: Dio Connection

    IVS-110 Embedded System 3.10.2 DIO Connection The IVS-110 has one DB-25 connector for DIO connection. The pinouts for the DIO connector are listed in the figure and table below. Figure 3-14: DIO Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DIN0...

  • Page 46: Obd-Ii Connection

    IVS-110 Embedded System 3.10.3 OBD-II Connection The IVS-110 has one DB-9 connector for OBD-II/J1939 connection. The pinouts for the OBD-II connector are listed in the figure and table below. Figure 3-15: OBD-II Connector PIN NO. DESCRIPTION OBD-CAN_H ISO-9141-2-K OBD-CAN_L J1850-...

  • Page 47: Power-On Procedure

    [Optional Choice] The OBD-II cable (Figure 3-16) can be purchased separately. The user can use the cable to connect the IVS-110 with the vehicle. The pinout locations of OBD-II cable connector are also shown below. Figure 3-16: OBD-II Cable and Connector Pinouts 3.11 Power-On Procedure...

  • Page 48: Power Input Connection

    Table 3-7: Power Input Connector Pinouts [Optional Choice] The IVS-110 can use either ACC power or DC power from the vehicle. To use ACC power, connect the IVS-110 to the vehicle through the ACC power cable. See Figure 3-18. Figure 3-18: ACC Power Cable...

  • Page 49: Power-On Procedure

    IVS-110 Embedded System To use DC power, connect the IVS-110 to the vehicle cigarette lighter connector through the optional cigarette lighter cable or to the power adapter through the transfer cable. See Figure 3-19 and Figure 3-20. Figure 3-19: Optional Cigarette Lighter Cable Figure 3-20: Optional Power Adapter and Transfer Cable 3.11.3 Power-on Procedure...

  • Page 50: Driver Installation

    Visit the IEI website or contact technical support for the latest updates. All the drivers for the IVS-110 are on the utility CD that came with the system. The utility CD contains drivers for Windows 10 operating system. The drivers include: ...

  • Page 51: Mobile Ap

    IVS-110 Embedded System 3.13 Mobile AP IEI provides an application tool, Mobile AP, for the users of the IVS-110 with the WWAN module installed to manage mobile network and make a phone call. 3.13.1 Installation To install this application tool, please locate the WLAN folder in the utility CD. This folder contains two files for different operating systems.

  • Page 52: Usage

    IVS-110 Embedded System 3.13.2 Usage To launch the application, double click the MobileAP icon on the Windows desktop. The user interface appears as shown in Figure 3-22. The functions are described below. Figure 3-22: Mobile AP–Connection  Sim card switch: Select a SIM card to designate a SIM card to use or click the Refresh SIM status button to let the system detect automatically.

  • Page 53: Bios

    IVS-110 Embedded System Chapter BIOS Page 39...

  • Page 54: Introduction

    IVS-110 Embedded System 4.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 55: Getting Help

    IVS-110 Embedded System Function Decrease the numeric value or make changes Page up Move to the next page Page down Move to the previous page Main Menu – Quit and do not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu --...

  • Page 56: Main

    IVS-110 Embedded System 4.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.

  • Page 57: Advanced

    IVS-110 Embedded System 4.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 58: Trusted Computing

    IVS-110 Embedded System 4.3.1 Trusted Computing Use the Trusted Computing menu (BIOS Menu 3) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Advanced Configuration...

  • Page 59: Acpi Settings

    IVS-110 Embedded System 4.3.2 ACPI Settings The ACPI Settings menu (BIOS Menu 4) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI sleep state the system will...

  • Page 60: F81866 Super Io Configuration

    IVS-110 Embedded System 4.3.3 F81866 Super IO Configuration Use the F81866 Super IO Configuration menu (BIOS Menu 5) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Advanced F81866 Super IO Configuration...

  • Page 61: Serial Port [Enabled]

    IVS-110 Embedded System 4.3.3.1.1 Serial Port 1 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enable the serial port Enabled EFAULT  Change Settings [IO=3F8h; IRQ=4] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 62: Transfer Mode [Rs232]

    IVS-110 Embedded System  Transfer Mode [RS232] Use the Transfer Mode option to select the Serial Port 1 signaling mode.  Serial Port 1 signaling mode is RS-422 RS422  Serial Port 1 signaling mode is RS-232 RS232 EFAULT ...

  • Page 63: Serial Port [Enabled]

    IVS-110 Embedded System 4.3.3.1.3 Serial Port 3 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enable the serial port Enabled EFAULT  Change Settings [IO=3E8h; IRQ=10] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 64: F81866 H/W Monitor

    IVS-110 Embedded System  IO=3E8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=10 address is IRQ10  Serial Port I/O port address is 2E8h and the interrupt IO=2E8h; EFAULT address is IRQ10 IRQ=10  IO=3E0h; Serial Port I/O port address is 3E0h and the interrupt...

  • Page 65: Smart Fan Mode Configuration

    IVS-110 Embedded System CPU Temperature System Temperature  Fan Speed: CPU Fan speed  Voltages: CPU_CORE +12V +5VSB +3.3V +3.3VSB 4.3.4.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 8) to configure fan temperature and speed settings.

  • Page 66: Cpu_Fan1 Smart Fan Control [Auto Duty-Cycle Mode]

    IVS-110 Embedded System  CPU_FAN1 Smart Fan Control [Auto Duty-Cycle Mode] Use the CPU_FAN1 Smart Fan Control BIOS option to configure the CPU Smart Fan.  The fan spins at the speed set in the Manual Manual Duty Mode Duty Mode option ...

  • Page 67: Power Management

    IVS-110 Embedded System 4.3.5 Power Management Use the Power Management menu (BIOS Menu 9) to configure the power management function. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Advanced Current Voltage : +12.0 V Set Low Voltage Warning...

  • Page 68: Power State

    IVS-110 Embedded System  1 hour  Auto Power Off Delay [20 sec] Use the Auto Power Off Delay option to set the automatic power-off delay time. Configuration options are listed below.  20 sec EFAULT  1 min ...

  • Page 69: Usb Configuration

    IVS-110 Embedded System 4.3.6 USB Configuration Use the USB Configuration menu (BIOS Menu 10) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 70: Cpu Configuration

    IVS-110 Embedded System  Enabled Legacy USB support enabled EFAULT  Legacy USB support disabled Disabled  Auto Legacy USB support disabled if no USB devices are connected 4.3.7 CPU Configuration Use the CPU Configuration menu (BIOS Menu 11) to view detailed CPU specifications and configure the CPU.

  • Page 71: Eist [Enabled]

    IVS-110 Embedded System  Intel HT Technology: Indicates if Intel HT Technology is supported by the CPU.  Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the CPU.  L1 Data Cache: Lists the amount of data storage space on the L1 cache.

  • Page 72: Rtc Wake Settings

    IVS-110 Embedded System  Disabled Disable VT-d support. EFAULT  Enable VT-d support. Enabled 4.3.8 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 12) configures RTC wake event. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.

  • Page 73: Serial Port Console Redirection

    IVS-110 Embedded System selected: Wake up date Wake up hour Wake up minute Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. 4.3.9 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 13) allows the console redirection options to be configured.

  • Page 74: Legacy Console Redirection Settings

    IVS-110 Embedded System  Disabled Disabled the console redirection function EFAULT  Enabled the console redirection function Enabled 4.3.9.1 Legacy Console Redirection Settings The Legacy Console Redirection Settings menu (BIOS Menu 14) allows the legacy console redirection options to be configured.

  • Page 75: Iei Feature

    IVS-110 Embedded System 4.3.10 IEI Feature Use the IEI Feature menu (BIOS Menu 15) to configure One Key Recovery function. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Advanced iEi Feature Auto Recovery Function Reboot and recover Auto Recovery Function...

  • Page 76: Chipset

    IVS-110 Embedded System 4.4 Chipset Use the Chipset menu (BIOS Menu 16) to access the North Bridge and South Bridge configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 77: North Bridge Configuration

    IVS-110 Embedded System 4.4.1 North Bridge Configuration Use the North Bridge menu (BIOS Menu 17) to configure the north bridge chipset. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset > Intel IGD Configuration Config Intel IGD Settings.

  • Page 78: Primary Display [Igd]

    IVS-110 Embedded System  Primary Display [IGD] Use the Primary Display option to select the graphics controller used as the primary boot device. Select either an integrated graphics controller (IGD) or a PCI express (PEG) controller. Configuration options are listed below: ...

  • Page 79: South Bridge Configuration

    IVS-110 Embedded System  Default 4.4.2 South Bridge Configuration Use the South Bridge menu (BIOS Menu 19) to configure the audio device connected to the system. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset > HD-Audio Configuration HD-Audio Configuration >...

  • Page 80: Hd-Audio Configuration

    IVS-110 Embedded System 4.4.2.1 HD-Audio Configuration Use the HD-Audio Configuration menu (BIOS Menu 20) to configure the HD Audio. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset HD-Audio Configuration Enable/Disable HD-Audio HD-Audio Support [Enable] Support --------------------- : Select Screen ↑...

  • Page 81: Pci Express Configuration

    IVS-110 Embedded System 4.4.2.2 PCI Express Configuration Use the PCI Express Configuration menu (BIOS Menu 21) to configure the PCI Express. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset PCI Express Configuration Control the PCI Express > Onboard LAN1 Root Port.

  • Page 82: Bios Menu 22: Rtl8111Gn Lan

    IVS-110 Embedded System 4.4.2.2.1 Onboard LAN1 Use the Onboard LAN1 menu (BIOS Menu 22) to configure the LAN 1 port. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset Onboard LAN1 [Enable] Control the PCI Express PCIe Speed [Auto] Root Port.

  • Page 83: Bios Menu 23: Mini-Pcie

    IVS-110 Embedded System 4.4.2.2.2 MINI-PCIE Use the MINI-PCIE menu (BIOS Menu 23) to configure the PCIe Mini slots. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset MINI-PCIE2 [Enable] Control the PCI Express PCIe Speed [Auto] Root Port.

  • Page 84: Sata Configuration

    IVS-110 Embedded System  PCIe Speed [Auto] Use the PCIe Speed option to configure PCIe Mini slot speed.  Configure PCIe Mini slot speed to auto Auto EFAULT  Configure PCIe Mini slot speed to Gen1 Gen 1  Gen 2 Configure PCIe Mini slot speed to Gen2 4.4.2.3 SATA Configuration...

  • Page 85: Stat Controller [Enable]

    IVS-110 Embedded System  STAT Controller [Enable] Use the STAT Controller option to enable or disable the SATA device.  Enables the SATA device. Enable EFAULT  Disables the SATA device. Disable  SATA Mode Selection [AHCI] Use the SATA Mode Selection option to configure SATA devices as AHCI devices.

  • Page 86: Security

    IVS-110 Embedded System 4.5 Security Use the Security menu (BIOS Menu 25) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set,...

  • Page 87: Boot

    IVS-110 Embedded System 4.6 Boot Use the Boot menu (BIOS Menu 26) to configure system boot options. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Select the keyboard...

  • Page 88: Quiet Boot [Enabled]

    IVS-110 Embedded System  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  OEM Logo displayed instead of POST messages Enabled EFAULT  Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.

  • Page 89: Save & Exit

    IVS-110 Embedded System 4.7 Save & Exit Use the Save & Exit menu (BIOS Menu 27) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Main...

  • Page 90: Restore User Defaults

    IVS-110 Embedded System  Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options. Page 76...

  • Page 91: Troubleshooting And Maintenance

    IVS-110 Embedded System Chapter Troubleshooting and Maintenance Page 77...

  • Page 92: System Maintenance Overview

    Failure to follow these instructions may lead to personal injury and system damage. To preserve the working integrity of the IVS-110 embedded system, the system must be properly maintained. If embedded system components need replacement, the proper maintenance procedures must be followed to ensure the system can continue to operate normally.

  • Page 93: The System Doesn't Boot Up

    WARNING: If all troubleshooting measures have been taken and the system still fails to start, contact the IEI reseller or vendor you purchased the IVS-110 from or contact an IEI sales representative directly. To contact sales representative, please...

  • Page 94: Txe Override Jumper

    IVS-110 Embedded System Step 3: Make the jumper settings in accordance with the settings described and defined in the following sections. Step 0: 5.3.1 TXE Override Jumper The TXE Override jumper (J_FLASH1) allows users to enable or disable the TXE firmware update.

  • Page 95: Interface Connectors

    IVS-110 Embedded System Chapter Interface Connectors Page 81...

  • Page 96: Peripheral Interface Connectors

    IVS-110 Embedded System 6.1 Peripheral Interface Connectors The IVS-110 series’ motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 6-1. The Pin 1 locations of the on-board connectors are also indicated in the diagrams below. The connector pinouts for these connectors are listed in the following sections.

  • Page 97: Internal Peripheral Connectors

    IVS-110 Embedded System 6.2 Internal Peripheral Connectors Internal peripheral connectors (Table 6-1) are found on the motherboard and are only accessible when the motherboard is outside of the chassis. Pinouts of the internal connectors not described in the previous chapters can be found in the following sections.

  • Page 98: Mcu Programming Connector (Jmcu1)

    IVS-110 Embedded System 6.2.2 MCU Programming Connector (JMCU1) PIN NO. DESCRIPTION MCLR +5V_MCU ICSPCLK2 ICSPDAT2 Table 6-3: MCU Programming Connector (JMCU1) Pinouts 6.2.3 OBD-II Programming Connector (JOBD1) PIN NO. DESCRIPTION MCLR#-1 ICSP_CLK ICSP_DAT Table 6-4: OBD-II Programming Connector (JOBD1) Pinouts 6.2.4 SATA Power Connector (SATA_PWR1)

  • Page 99: Spi Flash Connector, Bios (J_Spi1)

    IVS-110 Embedded System 6.2.5 SPI Flash Connector, BIOS (J_SPI1) PIN NO. DESCRIPTION +V3.3M_SPI_CON SPI_CS SPI_SO_SW SPI_CLK_SW SPI_SI_SW Table 6-6: SPI Flash Connector (J_SPI1) Pinouts 6.2.6 TPM Connector (TPM1, Debug Only) PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCLK LFRAME# LRERST# LAD3...

  • Page 100: A Regulatory Compliance

    IVS-110 Embedded System Appendix Regulatory Compliance Page 86...
  • Page 101 IVS-110 Embedded System DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives:  EMC Directive (2004/108/EC, 2014/30/EU)  Low-Voltage Directive (2006/95/EC, 2014/35/EU)  RoHS II Directive (2011/65/EU, 2015/863/EU) If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 102 IVS-110 Embedded System Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
  • Page 103 IVS-110 Embedded System Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU.
  • Page 104 IVS-110 Embedded System FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:  This device may not cause harmful interference, and  This device must accept any interference received, including interference that may cause undesired operation.

  • Page 105: B Safety Precautions

    IVS-110 Embedded System Appendix Safety Precautions Page 91...

  • Page 106: Safety Precautions

     Electric shocks can occur if the IVS-110 chassis is opened when it is running. To avoid risk of electric shock, this device must only be connected to a supply mains with protective earth.

  • Page 107: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IVS-110. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IVS-110 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 108: Product Disposal

    IVS-110 Embedded System B.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 109: Maintenance And Cleaning Precautions

    Always make sure your hands are dry when unplugging the power cable. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the IVS-110, please read the details below.  Never spray or squirt liquids directly onto any other components. To clean the embedded system, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth.
  • Page 110 IVS-110 Embedded System  Water or rubbing alcohol–A cloth moistened with water or rubbing alcohol can be used to clean the device.  Using solvents–The use of solvents is not recommended when cleaning the device as they may damage the plastic parts.

  • Page 111: Cbios Menu Options

    IVS-110 Embedded System Appendix BIOS Menu Options Page 97...

  • Page 112: Bios Configuration Options

    IVS-110 Embedded System C.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 4. System Date [xx/xx/xx] ......................42 System Time [xx:xx:xx] ....................... 42 Security Device Support [Disable] ..................44 ACPI Sleep State [S3 (Suspend to RAM)] ................45 Serial Port [Enabled] ......................
  • Page 113 IVS-110 Embedded System Auto Recovery Function [Disabled] ................... 61 Primary Display [IGD] ......................64 Integrated Graphics Device [Enable] ................. 64 DVMT Pre-Allocated [256M] ....................64 DVMT Total Gfx Mem [MAX] ....................64 HD-Audio Support [Enable] ....................66 Onboard LAN1 [Enable] ...................... 68 PCIe Speed [Auto] ........................

  • Page 114: D Watchdog Timer

    IVS-110 Embedded System Appendix Watchdog Timer Page 100...
  • Page 115 IVS-110 Embedded System NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 116 IVS-110 Embedded System NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 117: E Hazardous Materials Disclosure

    IVS-110 Embedded System Appendix Hazardous Materials Disclosure Page 103...
  • Page 118 IVS-110 Embedded System The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 119 IVS-110 Embedded System 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...

This manual is also suitable for:

Ivs-110-al-e3/4gIvs-110-al-e2/4gIvs-110-al-e1/4gIvs-110-al-e3/4g-r10Ivs-110-al-e2/4g-r10

Table of Contents
