10. Specifications

10. Specifications

10.1 Digital indicator model CPH6200

EN
Digital indicator model CPH6200
Electrical connection for reference pressure sensor
Measuring inputs
Sensor compatibility
Connection to CPH6200
Sensor connection cable
Display
Display indication
Indication range
Pressure types
Pressure units
Functions
Measuring rate
Mean value filter
Data logger
Real-time clock
Min./Max. memory
38
1 input for CPH6200-S1
■
2 inputs for CPH6200-S2
■
Compatible with reference pressure sensor model CPT6200
6-pin, shielded mini DIN female connector with interlocking
Cable with 6-pin mini DIN connector and 7-pin bayonet
■
connector, length 1.1 m [3.3 ft]
Extension cable, length 3.8 m [12.5 ft], overall cable length
■
approx. 5 m [16.4 ft]
Large 4 ½-digit LC display for indication of two pressure values
and additional information
-19999 ... 19999 digits (dependent upon connected reference
pressure sensor)
Dependent upon connected reference pressure sensor
Gauge pressure, absolute pressure or vacuum
■
Differential pressure measurement only with CPH6200-S2, and
■
two model CPT6200 reference pressure sensors connected
Freely adjustable depending on the measuring range
bar kPa
■ ■
mbar MPa
■ ■
psi mmHg
■ ■
Pa inHg
■ ■
Measuring rate (can be set via menu)
4/s ("Slo" - slow measurement)
■
1,000/s filtered ("FASt" - fast measurement)
■
> 1,000/s unfiltered ("P.det" - peak value detection)
■
1 ... 120 seconds (can be set via menu)
Individual value logger
■
⇒
Up to 99 recordings incl. time via button press
Cyclic logger
■
⇒
Automatic recording of up to 10,000 values incl. time
⇒
Cycle time freely adjustable in the range from
1 ... 3,600 seconds
For data logger, (can be set via menu)
Minimum or maximum measured value (can be accessed via
function button)
