Autostart AS-2360 TW Installation Manual

Manual transmissi on remote starter
Hide thumbs Also See for AS-2360 TW:
Table of Contents

Advertisement

Quick Links

Download this manual
M A N U A L
T R A N S M I S S I O N
R E M O T E
S T A R T E R
AS-2360 TW
Installation Guide
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of
the product, be that either damage to the vehicle itself or to the unit. This unit must be installed by a certified
technician using all safety devices supplied. Please note that this guide has been written for properly trained
Autostart technicians: a certain level of skills and knowledge is therefore assumed. Please review the
installation guide carefully before beginning any work.
Warning
manual
This remote car starter system is designed for vehicles with a
transmission only. Before
installing the unit, test that the OEM door switch contacts of the vehicle work well, and that the parking brake
system operates properly.
September 9, 2004
CA
DOC:1.00
Manufactured in Canada
AS-2360TW Installation Guide
P. 1

Advertisement

Table of Contents
loading

Related Manuals for Autostart AS-2360 TW

Summary of Contents for Autostart AS-2360 TW

  • Page 1 This unit must be installed by a certified technician using all safety devices supplied. Please note that this guide has been written for properly trained Autostart technicians: a certain level of skills and knowledge is therefore assumed. Please review the installation guide carefully before beginning any work.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ........2 Closing Up ..........22 Introduction..........3 Supplementary Information.....23 Included in the Kit ........3 Fifth Relay Output (2 IGN, ACC or Installation Points to Remember....4 CRANK) ..........23 Harness Description .........5 Clutch bypass .........23 Flashing the Hood-Pin Switch....12 Ignition-controlled Door Locks ....25 The Programming Assistance Button ..13 Secure Lock..........26...

  • Page 3: Introduction

    Introduction This guide contains all the information relevant and necessary for the installation of the module. Most of the features of this product are explained in the user guide. Therefore, if you need detailed information about a feature of the product, we recommend that you refer to the user guide.

  • Page 4: Installation Points To Remember

    Installation Points to Remember ♦ Make sure that vehicles equipped with ♦ Do not disconnect the battery on an automatic transmission do not start vehicles equipped with air bags and while in any of the drive gears. If the anti-theft radios. vehicle starts in gear, install a ♦...

  • Page 5: Harness Description

    Note: The parking light output relay of ♦ Parking light flashes to which the text the unit gives two clicking sounds for refers throughout this manual refer to each flash of the lights: one click when the parking light output of the unit, not the lights would go and one click of the vehicle.
  • Page 6 This wire will power the heater blower motor. Usually connected to the accessories wire of the vehicle. The source wire must have power with the ignition key in the position only (no IGNITION ON (RUN) power in the position). CRANK (+) Accessori Warning: at the ignition switch of certain vehicles, ORANGE...
  • Page 7 This wire provides a +12 V output and must be connected on the vehicle to the parking lights wire that tests +12 V when the light switch is in the ON (+) 12 V position. YELLOW Parking Light Note: ensure that the voltage does not decrease or output increase when the dimmer control switch is turned.
  • Page 8 Caution! The installer should use either the positive or the negative Door input. Never use both of them simultaneously. It is essential that the Remote Car Starter be connected in such a way as will allow each one of the Doors to turn off Ready Mode: the driver-side Door Pin does not constitute by itself a sufficient connection.
  • Page 9 The external trigger wire can be used for remote- starting the vehicle with an external device. When the vehicle is running, triggering this input will activate idle mode. The external trigger wire can also be used to operate as a negative trigger with the trunk pin-switch, the key sense wire or the door pin- switch: Option 1 Connects to negative trunk pin.
  • Page 10 This wire provides a constant 500 mA ground output while the module is running. This output becomes active at the same time as the ignition and shuts off when the module shuts down, e.g.: when the run (–) Ground time has expired, when the button has START/STOP WHITE...
  • Page 11 In diesel mode, this positive input will monitor the glow plug light: it will wait for up to 30 seconds until the glow-plug light goes out before allowing the module to proceed to cranking the engine. Connect to the side of the glow-plug light which is positive when the light is on.

  • Page 12: Flashing The Hood-Pin Switch

    • Connecting the glow-plug input wire of the module to ignition will hold the ignition ON for the maximum waiting time (15 seconds recommended) • Keeping the module’s glow-plug input wire (+) Glow-Plug unconnected will hold the ignition ON for the YELLOW input minimum waiting time (3 sec., not recommended...

  • Page 13: The Programming Assistance Button

    Here are the steps which the installer must follow in order to flash the hood-pin switch: The installer … The module … 1. Press and hold the hood-pin switch for 4 seconds. 2. Release the hood-pin switch. The parking lights will turn 3.

  • Page 14: Programming A Transmitter

    Programming a Transmitter Before you Proceed The Transmitter of the Remote Car Starter is not delivered pre-programmed: it must be programmed after the wiring of the Remote Car Starter is completed. The Remote Car Starter has the ability to retain up to 4 different Transmitter codes; if a fifth Transmitter is code-programmed, the code of the first Transmitter will be lost from memory.
  • Page 15 Note: The unit will stay in the selected programming mode until the hood pin-switch or the brake pedal is pressed again. Therefore take your time to make the proper selection. Pressing the brake pedal will take you back to the programming centre, where you can select a different mode. 1.

  • Page 16: Programming Options

    Programming Options MODE 1 * INDICATES DEFAULT SETTING FUNCTION 1 – Ignition-controlled Door Locks OPTION 1* Ignition Lock DISABLED OPTION 2 Ignition Lock ENABLED OPTION 3 Ignition UNLOCK ONLY OPTION 4 Ignition LOCK ONLY FUNCTION 2 – Secure Lock OPTION 1* Secure Lock (1-sec.

  • Page 17: Multi-Level Features (Default State)

    FUNCT ION 5 – Ig tion Valet OPTION 1 Ignition Valet DISABLED OPTION 2* Ignition Valet ENABLE D OPTION 3 Ignition Valet NABLED MODE 3 * INDICATES DEFAULT SETTING FUNCTION 1 – Home Valet OPTION 1 Home Valet ENABLED OPTION 2* Home Valet DISABLED OPTION 3...
  • Page 18 Customized Features (press the SHIFT button 3X) (May not be applicable for certain vehicles) Your installer can add customized features s uch as turning on the radio, opening sliding doors, etc....customized feature 1 SHIFT SHIFT SHIFT LOCK ....customized feature 2 SHIFT SHIFT...

  • Page 19: Horn Honk Timing

    Example: If the multi-level features were set to option 3, the setup would be as follows: Level 1 Customized feature Level 2 Multi car operation Level 3 Basic features The “Basic features” are now programmed as level 3 and therefore: To access the aux.2 feature, the user needs to press on the button three (3) times SHIFT...

  • Page 20: Multi-Speed Tach Programming

    If order to carry out Tach Programming, you may simply follow the Automatic Tach Programming procedure. The Remote Car Starter stores Tach settings regardless of the procedure used at the time of Tach programming. All Tach settings are cleared when the Remote Car Starter is reset.

  • Page 21: Tach Adjustments

    Tach Adjustments After having programmed the tach you might need to adjust it (increase or decrease the idle speed). In order to do so, you will need to follow these steps: Flash the hood pin (see page 12) Enter the programming centre (see page 14). Press and hold the brake pedal Press simultaneously the buttons.

  • Page 22: Closing Up

    Remaining in ready Mode Once the vehicle is in Ready Mode, you can start and stop the vehicle at wish. However, should any one of the following occur, the vehicle will exit Ready Mode, thus disabling remote start capabilities until Ready Mode is restored: •...

  • Page 23: Supplementary Information

    Mount all switches in good and accessible locations where they do not risk getting kicked or hit accidentally. Most comebacks are the result of misunderstandings about how a product works or performs. Take the time to properly explain all functions and features to the customers before they leave the premises.
  • Page 24 Before any Hot Wiring attempts: Test and record the way each wire tests in the following positions: With the pedal up: test the wire with the Ignition Key in the position test the wire with the Key in the position IGNITION ON (RUN) test the wire with the Key in the position...

  • Page 25: Ignition-Controlled Door Locks

    Positive Systems: Very similar to the negative system, except that the vehicle's clutch relay is trigger by 12 V, instead of a negative signal. In a Positive system, when the clutch is pressed; a positive (12 V) signal is sent to the relay, the relay energizes, when the Key is turned to position the 12 V from the start wire is allowed to pass through the relay and to START starter motor.

  • Page 26: Secure Lock

    If option Ignition Unlock Only is selected, the system will all Doors when the key UNLOCK is turned to the position (provided that the Ignition key was in the IGNITION ON (RUN) position and that the Brake Pedal was pressed at least once). Secure Lock This feature allows the Remote Car Starter to control certain OEM factory Alarm systems without requiring the use of other wires for disarming the OEM Alarm.

  • Page 27: Passive Or Active Arming

    Caution!!! When installing the Starter Kill, it is extremely important that pin 86 be wired to Ignition: do not jump it to pin 30 (damage to the vehicle could result). Note: Installation of the Starter Kill system requires an external relay. (Not included!) Passive or Active Arming The Remote Car Starter can be set to: •...

  • Page 28: Events Playback

    Events playback Ensure that the Hood is up, that the vehicle is not in Valet Mode and that the Ignition is • Hold down the Hood Pin-switch for 4 seconds. • Release the Pin-switch. The Parking Lights will come on. •...

  • Page 29: Diagnostics - Parking Light Flash Table

    Diagnostics – Parking Light Flash Table Flashes Description • Doors locked, Starter Kill armed. • End of Run Time. • button pressed TRUNK • Start signal received by the Remote Car Starter. • Cold Weather Mode cancelled. • Cannot start after maximum number of attempts is reached. •...
  • Page 30 Programming Options MODE 1 * INDICATES DEFAULT SETTING FUNCTION 1 – Ignition-controlled Door Locks FUNCTION 3 – Starter Kill Passive / Active Arming OPTION 1* Ignition Lock DISABLED OPTION 1* PASSIVE Arming (60 sec.) OPTION 2 Ignition Lock ENABLED OPTION 2 ACTIVE Arming OPTION 3 Ignition UNLOCK ONLY...
  • Page 31 AS-2360TW Programming Options and Wiring Diagram...
