The ATWINC1510 provides internal Flash memory and multiple peripheral interfaces, including UART and SPI. The
only external clock source needed for the ATWINC1510 is the built-in, high-speed crystal, or oscillator (26 MHz). The
ATWINC1510 is available in a QFN package or as a certified module.
The communication interface between the ATSAMD21G18A and ATWINC1510 Wi-Fi module is the SPI, together with
some enabled signals and interrupts. The rest of the connections are left unconnected.
Table 4-6. ATWINC1510 Connections
ATWINC1510 Pin
4 RESET_N PB10
9 GND -
10 SPI_CFG -
11 WAKE PA19
12 GND -
13 IRQN PA18
15 SPI_MOSI PA12
16 SPI_SSN PA14
17 SPI_MISO PA15
18 SPI_SCK PA13
20 VBAT -
22 CHIP_EN PB11
23 VDDIO -
28 GND -
29 PADDLE -
©
2022 Microchip Technology Inc.
and its subsidiaries
ATSAMD21G18A Pin
GPIO
Ground
Pulled-up to VCC_WINC
GPIO
Ground
EIC EXT INT 2
SERCOM 4 SPI MOSI
SERCOM 4 SPI CS
SERCOM 4 SPI MISO
SERCOM 4 SPI Clock
VCC_WINC (3.3V)
GPIO
VCC_WINC (3.3V)
Ground
Ground
