Quick Start Guide
This quick start guide is intended to provide a quick overview of your WELLJET's key
features and to offer basic instructions for getting started. For detailed information,
please refer to the latest operating instructions (OI) that can be found at
biosciences.com

Intended Use

This is a general-purpose laboratory instrument. Any use of this instrument in a medical or IVD
setting is the sole responsibility of the user. WELLJET is a rapid reagent dispenser in the volume
range of 0.5 – 9'999 µl using different dispensing cassettes.

Safety information

Regardless of the listed safety notes, all locally applicable regulations must be observed.
1) This product may only be operated in a secure, protected network with trustworthy clients.
2) WELLJET may only be used by properly trained personnel in a manner specified by INTEGRA
Biosciences.
3) Observe the hazard warnings on the device. Keep the plate carrier moving area free of any
labware and keep hands away.
4) Do not use the device near flammable material or in an atmosphere with danger of explosion.
Also, do not dispense highly flammable liquids such as acetone or ether.
5) Servicing work and repairs may only be performed by INTEGRA Biosciences or an authorized
after-sales service member.

Getting started

Set up the instrument on a perfectly horizontal surface.
Supply voltage: 100
Insert the adapter cable in the socket on the right side of the WELLJET and connect the adapter via
a 3-core cable to the electricity mains.
a
g
f
e
d
Switch on the device. Press OK to initialize the WELLJET.
Remove hands from WELLJET during initialization and operation.
191951_V00_QSG_WELLJET_EN.docx
WELLJET Dispenser / Dispenser Stacker
in different languages.
–  
 240 VAC,
–  
 6
47
3
Hz
a. Hood of pump unit, open to install
b. Plate carrier with clamp mechanism
c. Display
d. Waste trough with drain fitting for waste
b
c
e. Deck
f.
g. Lever for tightening and releasing the
Switch on/off:
Press the main switch on the right side.
.
dispensing cassette
tubing, serves also as reservoir holder
Mounting bar for attaching the tube holder
dispensing cassette
www.integra-
1/4
