Preparation for Use
1
Connect the power cord. Insert the plug into a power socket
provided with a protective earth. Set the tilt adjustor for
your preference.
Figure 1
Plug in and angle adjustment
2
Connect an RF cable to the output connector of the signal
generator and then connect the cable to your DUT (device
under test) or other instrument.
Figure 2
Setup for DUT test with ESA
Quick Start Guide
Preparation for Use
DUT
7
