Generating a Continuous Wave Signal

Setting up Frequency
Setting up Amplitude
To simplify the example, assume you wish to generate a
continuous wave (CW) signal with a:
• Frequency of 1 GHz
• Power level of 20.0 dBm
–
Operation
1. Press hardkey
Preset
2. Press hardkey
Frequency
3. Enter using the
1
numeric keypad and
press softkey
GHz
Operation
1. Press hardkey
Amplitude
2. Enter 20 using the
–
numeric keypad and
press softkey
dBm
Generating a Continuous Wave Signal
Notes
Sets the signal generator to its
factory-defined instrument state.
Frequency becomes the active function in
the data entry area. This area displays the
factory preset frequency.
The FREQUENCY area and the active entry
area both display the new carrier frequency
(1.0000000000 GHz).
Notes
Frequency becomes the active function in
the data entry area. This area displays the
factory preset frequency.
The AMPLITUDE area and the active entry
area display the new level (
Quick Start Guide
20.0 dBm).
–
9
