Quick Start Guide
N9310A Overview
Rear Panel at a Glance
6
10
I IN
MOD IN
REF IN
1V RM S
M AX
Q IN
PULSE MOD IN
REF OUT
9
8
7
6
5
1 AC power switch
2 AC power connector
3 USB host connector
4 Trigger input connector
5 Reference output connector 11 VGA connector
6 Reference input connector
The signal generator rear panel provides input, output, and
remote interface connections. Refer to "Rear Panel Overview"
on User's Guide for more information.
11
12
VGA OUTPUT
N9310A N9310A-CFG002
SER:CN* * * * * * * * *
Made in China
DEV
HOST
LINE:
TRIG IN
100-240V
50-60Hz
100W MAX
HIPOT PASS
3
4
7
Pulse input connector
8
Modulation source input connector
9
Q input connector
10 I input connector
12 USB device connectors
1
2
