SE 1223 Integrated VLD Scanner
USER'S GUIDE
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
PN: 961-032-042
Revision B
September 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE1223 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intermec SE1223

Summary of Contents for Intermec SE1223

  • Page 1 SE 1223 Integrated VLD Scanner USER’S GUIDE " " " " " " " " " " " " " " " " " " " " " " " " " " " " PN: 961-032-042 Revision B September 1999...
  • Page 2 " NOTICE The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.

  • Page 3: Table Of Contents

    " " SECTION 1 General Information SE 1223 Integrated VLD Scanner Overview Definition of Terms Aperture ASCII ..........
  • Page 4 Laser Hazard Classifications SE 1223 Scanner User’s Guide ........
  • Page 5 2-27 2-28 2-29 2-30 2-31 2-32 2-33 2-34 2-35 ....2-36 2-37 2-37 2-38 2-38 2-39 2-40 SE 1223 Scanner User’s Guide...
  • Page 6 ..........SE 1223 Scanner User’s Guide .
  • Page 7 ......SE 1223 Wide Angle Scanner Decode Zone SE 1223 Very High Density (VHD) Scanner SE 1223 Very High Density (VHD) Scanner Decode Zone SE 1223 Long Range (LR) Scanner SE 1223 Long Range (LR) Scanner Decode Zone...
  • Page 8 CONTENTS SE 1223 Scanner User’s Guide...

  • Page 9: General Information

    " SE 1223 Integrated VLD Scanner Overview Your SE 1223 Integrated VLD Scanner is a miniature, vis- ible-laser scanner with an integrated decoder. The SE 1223 scanner contains an inboard microcontroller that scans and processes bar codes into ASCII data.

  • Page 10: Ascii

    The number of characters represented per unit of measure- ment (e.g. characters per inch). Bar Code Security The level of bar code quality that the scanner will attempt to decode. Bar Height The dimension of a bar measured perpendicular to the bar...

  • Page 11: Cdrh Class I

    Those characters available for encodation in a particular bar code symbology. Check Digit A digit used to verify a correct symbol decode. The scanner inserts the decoded data into an arithmetic formula and checks that the resulting number matches the encoded check digit.

  • Page 12: Codabar

    Number of data characters in a bar code between the start and stop characters. Continuous Code A bar code or symbol in which all spaces within the symbol are parts of characters. There are no intercharacter gaps in SE 1223 Scanner User’s Guide...

  • Page 13: Dead Zone

    The absence of gaps allows for greater information density. Dead Zone An area within a scanner’s field of view, in which specular reflection may prevent a successful decode. Decode To recognize a bar code symbology such as UPC/EAN and then analyze the content of the specific bar code scanned.

  • Page 14: Ean

    IEC Class I (IEC 825 Class I) This is the lowest power IEC laser classification. Conformi- ty is ensured through a software restriction of 120 seconds SE 1223 Scanner User’s Guide...

  • Page 15: Intercharacter Gap

    SECTION 1 General Information of laser operation within any 1000 second window and an automatic laser shutdown if the scanner’s oscillating mirror fails. Intercharacter Gap The space between two adjacent bar code characters in a discrete code. Interleaved Bar Code...

  • Page 16: Laser Indicator

    The primary application for the MSI Ples- sey code is marking of retail shelves and subsequent scan- ning with portable devices for inventory purposes. SE 1223 Scanner User’s Guide...

  • Page 17: Nominal

    -- R ) /R , where R is the reflectance factor of the background and R the reflectance factor of the dark bars. Programming Mode The state in which a scanner is configured for parameter values. SE 1223 Scanner User’s Guide...

  • Page 18: Quiet Zone

    (more light reflected from spaces). 3. Signal conditioning circuit, transforms optical detector output into a digitized bar pattern. Scanning Mode The scanner is energized, programmed, and ready to read a bar code. 1-10 SE 1223 Scanner User’s Guide SECTION 1...

  • Page 19: Scanning Sequence

    The mirror-like reflection of light from a surface which can “blind” a scanner. Start/Stop Character A pattern of bars and spaces that provides the scanner with start and stop reading instructions and scanning direction. The start and stop characters are normally to the left and right margins of a horizontal code.

  • Page 20: Symbol Aspect Ratio

    United States. Visible Laser Diode (VLD) A solid state device which produces visible laser light. Laser light emitted from the diode has a wavelength of 670 to 680 nanometers. 1-12 SE 1223 Scanner User’s Guide...

  • Page 21: Laser Hazard Classifications

    These products emit less than one milliwatt of laser light from the output window. The visible laser beam from a class II scanner by its very bright nature will be too dazzling to stare into. Momentary viewing is not considered hazardous since the...
  • Page 22 General Information SECTION 1 1-14 SE 1223 Scanner User’s Guide...

  • Page 23: Scanner Parameters

    " " Introduction The SE 1223 Scanner is programmed to operate by scan- ning appropriate bar codes based on your needs. This sec- tion contains the bar codes necessary to program the scan- ner for each parameter selection. The default settings for your SE 1223 scanner are shown on page 2-4.

  • Page 24: Identifying The Default Settings

    The scanner uses a power conservation method that causes it to power down after 1/2 to 1 second. Because of this, bar codes in a multiple bar code parameter sequence must be scanned within 1/2 second of each other.

  • Page 25: Errors While Scanning

    Scanner Parameters " NOTE: Tip: After reading a bar code, aim the scanner away from the bar codes and press the SCAN key within 1/2 second, to get the laser beam back on. While the laser beam is on, you have five seconds to find and scan the next bar code.

  • Page 26: Reset To Default Settings

    Decode Data Packet Format Select this option after you scan Reset To Default Settings bar code. This is necessary for your terminal to receive any decodes. SE 1223 Scanner User’s Guide RESET TO DEFAULT SETTINGS SEND PACKETED DECODE DATA SECTION 2...

  • Page 27: Table 2-1 Scanner Default Settings

    2-12 2-16 Disable 2-18 Enable 2-18 Enable 2-18 Disable 2-21 Enable 2-21 Enable 2-21 Disable 2-24 Ignore 2-26 2-27 Enable 2-27 Enable 2-29 Enable 2-30 System Character 2-31 System Character 2-32 System Character 2-33 Disable SE 1223 Scanner User’s Guide...
  • Page 28 Code 93 Set Length(s) for Code 93 Interleaved 2 of 5 Interleaved 2 of 5 Set Length(s) for I 2 of 5 I 2 of 5 Check Digit Verification SE 1223 Scanner User’s Guide Page Default Setting Number 2-34 Disable...

  • Page 29: Default Setting

    Number 2-61 Disable 2-62 Disable 2-63 Disable 2-64 2-67 Disable 2-68 5--55 2-71 Disable 2-72 Disable 2-73 Disable 2-74 6--55 2-77 2-78 Disable 2-79 Mod 10/Mod 10 2-80 None 2-82 NULL 2-84 Data as is SE 1223 Scanner User’s Guide...

  • Page 30: Laser On Time

    To set On Time of 0.5 seconds, scan the bar code below, then scan the 0 and 5 bar codes. If you make an error, or wish to change your selection, scan the CANCEL bar code on page 2-88. SE 1223 Scanner User’s Guide SECTION 2 LASER ON TIME...

  • Page 31: Aim Duration

    SECTION 2 Aim Duration When a scanner with an aim mode is triggered either by a trigger pull, or a START_DECODE command, this parame- ter sets the duration the aiming pattern is seen before a scan attempt begins. It does not apply to the aim signal or the AIM_ON command.

  • Page 32: Transmit "No Read" Message

    Any prefix or suffixes which have been embedded are appended around this message. When disabled, if a symbol does not read, nothing is sent to the host. 2-10 SE 1223 Scanner User’s Guide ENABLE NO READ DISABLE NO READ SECTION 2...

  • Page 33: Parameter Scanning

    The Reset to Default Settings bar code will still be decoded. To enable decoding of parameter bar codes, either scan ENABLE PARAMETER SCANNING, RESET TO DEFAULT SETTINGS. Scanner Parameters ENABLE PARAMETER SCANNING DISABLE PARAMETER SCANNING SE 1223 Scanner User’s Guide 2-11...

  • Page 34: Linear Code Type Security Levels

    The SE 1223 offers four levels of decode security for linear code types (e.g. Code 39, Interleaved 2 of 5). Higher security levels are selected for decreasing levels of bar code quality. As security levels increase, the scanner’s aggressiveness decreases. Select the security level appropriate for your bar code quali-...

  • Page 35: Linear Security Level 2

    SECTION 2 Scanner Parameters Linear Security Level 2 The following code types must be successfully read twice before being decoded. Code Type Length LINEAR SECURITY LEVEL 2 SE 1223 Scanner User’s Guide 2-13...

  • Page 36: Linear Security Level 3

    The following must be read three times. MSI Plessey Discrete 2 of 5 Interleaved 2 of 5 2-14 SE 1223 Scanner User’s Guide Code Type 4 or fewer 8 or fewer 8 or fewer LINEAR SECURITY LEVEL 3...

  • Page 37: Linear Security Level 4

    SECTION 2 Scanner Parameters Linear Security Level 4 The following code types must be successfully read three times before being decoded. Code Type Length LINEAR SECURITY LEVEL 4 SE 1223 Scanner User’s Guide 2-15...

  • Page 38: Bidirectional Redundancy

    Security Level has been enabled (see page 2-12). When this parameter is enabled, a bar code must be successfully scanned in both directions (forward and reverse) before be- ing decoded. 2-16 SE 1223 Scanner User’s Guide ENABLE BIDIRECTIONAL REDUNDANCY DISABLE BIDIRECTIONAL REDUNDANCY SECTION 2...

  • Page 39: Symbology Types

    SECTION 2 Symbology Types The bar code selections enable the scanner to decode any or all of the following symbologies. UPC Versions A, E, and E1 (EAN 8 and 13) " Codabar " Code 39 " Code 93 " Interleaved and Discrete 2 of 5 "...

  • Page 40: Upc/Ean

    Scanner Parameters UPC/EAN Enable/Disable UPC-A To enable or disable UPC-A, scan the appropriate bar code. 2-18 SE 1223 Scanner User’s Guide SECTION 2 ENABLE UPC-A DISABLE UPC-A...

  • Page 41: Enable/Disable Upc-E

    SECTION 2 Scanner Parameters Enable/Disable UPC-E To enable or disable UPC-E, scan the appropriate bar code. ENABLE UPC-E DISABLE UPC-E SE 1223 Scanner User’s Guide 2-19...

  • Page 42: Enable/Disable Upc-E1

    Scanner Parameters SECTION 2 Enable/Disable UPC-E1 To enable or disable UPC-E1, scan the appropriate bar code. ENABLE UPC-E1 DISABLE UPC-E1 2-20 SE 1223 Scanner User’s Guide...

  • Page 43: Enable/Disable Ean-8

    SECTION 2 Scanner Parameters Enable/Disable EAN-8 To enable or disable EAN-8, scan the appropriate bar code. ENABLE EAN-8 DISABLE EAN-8 SE 1223 Scanner User’s Guide 2-21...

  • Page 44: Enable/Disable Ean-13

    Scanner Parameters SECTION 2 Enable/Disable EAN-13 To enable or disable EAN-13, scan the appropriate bar code. ENABLE EAN-13 DISABLE EAN-13 2-22 SE 1223 Scanner User’s Guide...

  • Page 45: Enable/Disable Bookland Ean

    SECTION 2 Scanner Parameters Enable/Disable Bookland EAN To enable or disable Bookland EAN, scan the appropriate bar code. ENABLE BOOKLAND EAN DISABLE BOOKLAND EAN SE 1223 Scanner User’s Guide 2-23...

  • Page 46: Decode Upc/Ean Supplementals

    In order to minimize the risk of invalid data transmission, we recom- mend that you select whether to read or ignore supplemental charac- ters. Select the desired option by scanning one of the following UPC/EAN Supplemental bar codes. 2-24 SE 1223 Scanner User’s Guide SECTION 2...
  • Page 47 SECTION 2 Scanner Parameters DECODE UPC/EAN WITH SUPPLEMENTALS IGNORE UPC/EAN WITH SUPPLEMENTALS AUTODISCRIMINATE UPC/EAN SUPPLEMENTALS SE 1223 Scanner User’s Guide 2-25...

  • Page 48: Decode Upc/Ean Supplemental Redundancy

    Next scan two numeric bar codes beginning on page 4-87. Single digit numbers must have a leading zero. If you make an error, or wish to change your selection, scan CANCEL on page 2-88. DECODE UPC/EAN SUPPLEMENTAL REDUNDANCY 2-26 SE 1223 Scanner User’s Guide...

  • Page 49: Transmit Upc-A Check Digit

    SECTION 2 Transmit UPC-A Check Digit Scan the appropriate bar code to transmit the symbol with or without the UPC-A check digit. ENABLE TRANSMIT UPC-A CHECK DIGIT DO NOT TRANSMIT UPC-A CHECK DIGIT SE 1223 Scanner User’s Guide Scanner Parameters 2-27...

  • Page 50: Transmit Upc-E Check Digit

    Scanner Parameters Transmit UPC-E Check Digit Scan the appropriate bar code to transmit the symbol with or without the UPC-E check digit. 2-28 SE 1223 Scanner User’s Guide ENABLE TRANSMIT UPC-E CHECK DIGIT DO NOT TRANSMIT UPC-E CHECK DIGIT SECTION 2...

  • Page 51: Transmit Upc-E1 Check Digit

    SECTION 2 Transmit UPC-E1 Check Digit Scan the appropriate bar code to transmit the symbol with or without the UPC-E1 check digit. ENABLE TRANSMIT UPC-E1 CHECK DIGIT DO NOT TRANSMIT UPC-E1 CHECK DIGIT SE 1223 Scanner User’s Guide Scanner Parameters 2-29...

  • Page 52: Upc-A Preamble

    No preamble required " System character only " System character and country code " SYSTEM CHARACTER (<SYSTEM CHARACTER><DATA>) SYSTEM CHARACTER & COUNTRY CODE (<COUNTRY CODE> <SYSTEM CHARACTER><DATA>) 2-30 SE 1223 Scanner User’s Guide SECTION 2 NO PREAMBLE...

  • Page 53: Upc-E Preamble

    No preamble required " System character only " System character and country code " SYSTEM CHARACTER (<SYSTEM CHARACTER><DATA>) SYSTEM CHARACTER & COUNTRY CODE (<COUNTRY CODE> <SYSTEM CHARACTER><DATA>) Scanner Parameters NO PREAMBLE SE 1223 Scanner User’s Guide 2-31...

  • Page 54: Upc-E1 Preamble

    No preamble required " System character only " System character and country code " SYSTEM CHARACTER (<SYSTEM CHARACTER><DATA>) SYSTEM CHARACTER & COUNTRY CODE (<COUNTRY CODE> <SYSTEM CHARACTER><DATA>) 2-32 SE 1223 Scanner User’s Guide SECTION 2 NO PREAMBLE...

  • Page 55: Convert Upc-E To Upc-A

    Scanning the DO NOT CONVERT UPC-E TO UPC-A bar code, allows you to transmit UPC-E1 (zero suppressed) de- coded data. DO NOT CONVERT UPC-E TO UPC-A (DISABLE) CONVERT UPC-E TO UPC-A (ENABLE) SE 1223 Scanner User’s Guide Scanner Parameters 2-33...

  • Page 56: Convert Upc-E1 To Upc-A

    (e.g., Preamble, Check Digit). Scanning the DO NOT CONVERT UPC-E1 TO UPC-A bar code, allows you to transmit UPC-E1 (zero suppressed) decoded data. CONVERT UPC-E1 TO UPC-A (ENABLE) DO NOT CONVERT UPC-E1 TO UPC-A (DISABLE) 2-34 SE 1223 Scanner User’s Guide...

  • Page 57: Ean Zero Extend

    EAN-8 symbols to make them compatible in format to EAN-13 symbols. Disabling this parameter returns EAN-8 symbols to their normal format. Scanner Parameters ENABLE EAN ZERO EXTEND DISABLE EAN ZERO EXTEND SE 1223 Scanner User’s Guide 2-35...

  • Page 58: Convert Ean-8 To Ean-13 Type

    ID Character and DECODE_DATA message. This parameter has no effect unless EAN Zero Extend is enabled. Furthermore, when EAN Zero Extend is disabled, bar code data is not effected. TYPE IS EAN-13 TYPE IS EAN-8 2-36 SE 1223 Scanner User’s Guide...

  • Page 59: Upc/Ean Security Level 0

    UPC/EAN Security Level 0 This is the default setting which allows the scanner to oper- ate in its most aggressive state, while providing sufficient security in decoding “in-spec” UPC/EAN bar codes.

  • Page 60: Upc/Ean Security Level 1

    UPC/EAN Security Level 2 If you are experiencing misdecodes of poorly printed bar codes, and the misdecodes are not limited to 1, 2, 7, and 8, select this security level. UPC/EAN SECURITY LEVEL 2 2-38 SE 1223 Scanner User’s Guide...

  • Page 61: Upc/Ean Security Level 3

    Selection of this level of securi- ty significantly impairs the decoding ability of the scanner. If this level of security is necessary, you should try to im- prove the quality of your bar codes.

  • Page 62: Upc/Ean Coupon Code

    When enabled, this parameter decodes UPC-A, UPC-A with 2 supplemental characters, UPC-A with 5 supplemental characters, and UPC-A/EAN 128 bar codes. Autodiscrimi- nate UPC/EAN Supplementals must be enabled. 2-40 SE 1223 Scanner User’s Guide ENABLE UPC/EAN COUPON CODE DISABLE UPC/EAN COUPON CODE SECTION 2...

  • Page 63: Code 128

    SECTION 2 Code 128 Enable/Disable USS-128 To enable or disable Code 128, scan the appropriate bar code. Scanner Parameters ENABLE USS-128 DISABLE USS-128 SE 1223 Scanner User’s Guide 2-41...

  • Page 64: Enable/Disable Ucc/Ean-128

    Scanner Parameters SECTION 2 Enable/Disable UCC/EAN-128 To enable or disable UCC/EAN-128, scan the appropriate bar code. ENABLE UCC/EAN-128 DISABLE UCC/EAN-128 2-42 SE 1223 Scanner User’s Guide...

  • Page 65: Enable/Disable Isbt 128

    SECTION 2 Scanner Parameters Enable/Disable ISBT 128 To enable or disable ISBT 128, scan the appropriate bar code. ENABLE ISBT 128 DISABLE ISBT 128 SE 1223 Scanner User’s Guide 2-43...

  • Page 66: Code 39

    Scanner Parameters Code 39 Enable/Disable Code 39 To enable or disable Code 39, scan the appropriate bar code. 2-44 SE 1223 Scanner User’s Guide ENABLE CODE 39 DISABLE CODE 39 SECTION 2...

  • Page 67: Enable/Disable Trioptic Code 39

    Trioptic Code 39 and Code 39 Full ASCII should not be en- abled simultaneously. To enable or disable Trioptic Code 39, scan the appropriate bar code. ENABLE TRIOPTIC CODE 39 DISABLE TRIOPTIC CODE 39 SE 1223 Scanner User’s Guide 2-45...

  • Page 68: Convert Code 39 To Code 32

    If you do not want to convert a Code 39 bar code to a Code 32 bar code, scan the following bar code. DO NOT CONVERT CODE 39 TO CODE 32 (DISABLE) 2-46 SE 1223 Scanner User’s Guide CONVERT CODE 39 TO CODE 32 (ENABLE) SECTION 2...

  • Page 69: Code 39 Prefix

    Enable this parameter to add the prefix character “A” to all Code 39 bar codes. " NOTE: Convert Code 39 to Code 32 must be enabled for this parameter to function. ENABLE CODE 39 PREFIX DISABLE CODE 39 PREFIX SE 1223 Scanner User’s Guide 2-47...

  • Page 70: Set Lengths For Code 39

    Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. 2-48 SE 1223 Scanner User’s Guide CODE 39- -ONE DISCRETE LENGTH SECTION 2...
  • Page 71 Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. CODE 39- -TWO DISCRETE LENGTHS CODE 39- -LENGTH WITHIN RANGE SE 1223 Scanner User’s Guide Scanner Parameters 2-49...

  • Page 72: Code 39 Check Digit Verification

    Code 39 symbol to ensure it complies with specified algo- rithms. Only those Code 39 symbols which include a modulo 43 check digit are decoded when this parameter is enabled. ENABLE CODE 39 CHECK DIGIT DISABLE CODE 39 CHECK DIGIT 2-50 SE 1223 Scanner User’s Guide...

  • Page 73: Transmit Code 39 Check Digit

    SPACE and DELETE produce visible characters. Code 39 Full ASCII interprets the bar code special charac- ter ($ + % /) preceding a Code 39 character and assigns an ASCII character value to the pair. SE 1223 Scanner User’s Guide 2-51...
  • Page 74 Scanning ABC$M outputs the keystrokes equivalent of ABC ENTER. Code 39 Full ASCII and Trioptic Code 39 should not be en- abled simultaneously. The scanner will not autodiscriminate between Code 39 and Code 39 Full ASCII. 2-52 SE 1223 Scanner User’s Guide...

  • Page 75: Code 93

    SECTION 2 Code 93 Enable/Disable Code 93 To enable or disable Code 93, scan the appropriate bar code below. Scanner Parameters ENABLE CODE 93 DISABLE CODE 93 SE 1223 Scanner User’s Guide 2-53...

  • Page 76: Set Lengths For Code 93

    Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. 2-54 SE 1223 Scanner User’s Guide CODE 93- -ONE DISCRETE LENGTH SECTION 2...
  • Page 77 Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. CODE 93- -TWO DISCRETE LENGTHS CODE 93- -LENGTH WITHIN RANGE SE 1223 Scanner User’s Guide Scanner Parameters 2-55...

  • Page 78: Interleaved 2 Of 5

    Enable/Disable Interleaved 2 of 5 To enable or disable Interleaved 2 of 5, scan the appropriate bar code below. 2-56 SE 1223 Scanner User’s Guide CODE 93- -ANY LENGTH ENABLE INTERLEAVED 2 OF 5 DISABLE INTERLEAVED 2 OF 5 SECTION 2...

  • Page 79: Set Lengths For Interleaved 2 Of 5

    Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. Scanner Parameters I 2 OF 5- -ONE DISCRETE LENGTH SE 1223 Scanner User’s Guide 2-57...
  • Page 80 Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. 2-58 SE 1223 Scanner User’s Guide I 2 OF 5- -TWO DISCRETE LENGTHS I 2 OF 5- -LENGTH WITHIN RANGE SECTION 2...
  • Page 81 Any Length: Scanning this option allows you to decode I 2 of 5 symbols containing any number of characters. " NOTE: Selecting this option may lead to misdecodes for I 2 of 5 bar codes. I 2 OF 5- -ANY LENGTH SE 1223 Scanner User’s Guide 2-59...

  • Page 82: I 2 Of 5 Check Digit Verification

    When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification), or OPCC (Optical Product Code Council). DISABLE USS CHECK DIGIT OPCC CHECK DIGIT 2-60 SE 1223 Scanner User’s Guide...

  • Page 83: Transmit I 2 Of 5 Check Digit

    TRANSMIT I 2 OF 5 CHECK DIGIT (ENABLE) Scan this symbol if you want to transmit the data without the check digit. DO NOT TRANSMIT I 2 OF 5 CHECK DIGIT (DISABLE) SE 1223 Scanner User’s Guide 2-61...

  • Page 84: Convert I 2 Of 5 To Ean-13

    14, and the code must have a leading zero and a valid EAN-13 check digit. DO NOT CONVERT I 2 OF 5 to EAN-13 (DISABLE) 2-62 SE 1223 Scanner User’s Guide CONVERT I 2 OF 5 to EAN-13 (ENABLE) SECTION 2...

  • Page 85: Discrete 2 Of 5

    Discrete 2 of 5 Enable/Disable Discrete 2 of 5 To enable or disable Discrete 2 of 5, scan the appropriate bar code below. Scanner Parameters ENABLE DISCRETE 2 OF 5 DISABLE DISCRETE 2 OF 5 SE 1223 Scanner User’s Guide 2-63...

  • Page 86: Set Lengths For Discrete 2 Of 5

    Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. 2-64 SE 1223 Scanner User’s Guide D 2 OF 5- -ONE DISCRETE LENGTH SECTION 2...
  • Page 87 Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. Scanner Parameters D 2 OF 5- -TWO DISCRETE LENGTHS D 2 OF 5- -LENGTH WITHIN RANGE SE 1223 Scanner User’s Guide 2-65...
  • Page 88 Any Length: Scanning this option allows you to decode I 2 of 5 symbols containing any number of characters. " NOTE: Selecting this option may lead to misdecodes for D 2 of 5 bar codes. 2-66 SE 1223 Scanner User’s Guide D 2 OF 5- -ANY LENGTH SECTION 2...

  • Page 89: Codabar

    SECTION 2 Codabar Enable/Disable Codabar To enable or disable Codabar, scan the appropriate bar code below. Scanner Parameters ENABLE CODABAR DISABLE CODABAR SE 1223 Scanner User’s Guide 2-67...

  • Page 90: Set Lengths For Codabar

    Codabar symbols containing 14 characters are decoded. Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. 2-68 SE 1223 Scanner User’s Guide CODABAR- -ONE DISCRETE LENGTH SECTION 2...
  • Page 91 Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. CODABAR- -TWO DISCRETE LENGTHS CODABAR- -LENGTH WITHIN RANGE SE 1223 Scanner User’s Guide Scanner Parameters 2-69...
  • Page 92 Scanner Parameters SECTION 2 Any Length: Scanning this option allows you to decode Co- dabar symbols containing any number of characters. CODABAR- -ANY LENGTH 2-70 SE 1223 Scanner User’s Guide...

  • Page 93: Clsi Editing

    14-character Codabar symbol. " NOTE: Symbol length does not include start and stop characters. ENABLE CLSI EDITING DISABLE CLSI EDITING SE 1223 Scanner User’s Guide 2-71...

  • Page 94: Notis Editing

    Scanner Parameters SECTION 2 NOTIS Editing When enabled, this parameter strips the start and stop characters from decoded Codabar symbol. ENABLE NOTIS EDITING DISABLE NOTIS EDITING 2-72 SE 1223 Scanner User’s Guide...

  • Page 95: Msi Plessey

    SECTION 2 MSI Plessey Enable/Disable MSI/Plessey To enable or disable MSI Plessey, scan the appropriate bar code. Scanner Parameters ENABLE MSI Plessey DISABLE MSI Plessey SE 1223 Scanner User’s Guide 2-73...

  • Page 96: Set Lengths For Msi Plessey

    Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. 2-74 SE 1223 Scanner User’s Guide MSI Plessey- -ONE DISCRETE LENGTH SECTION 2...
  • Page 97 Numeric bar codes begin on page 4-87. If you make an er- ror, or wish to change your selection, scan the CANCEL bar code on page 2-88. MSI Plessey- -TWO DISCRETE LENGTHS MSI Plessey- -LENGTH WITHIN RANGE SE 1223 Scanner User’s Guide Scanner Parameters 2-75...
  • Page 98 Any Length: Scanning this option allows you to decode Co- dabar symbols containing any number of characters. " NOTE: Selecting this option may lead to misdecodes for MSI Plessey bar codes. 2-76 SE 1223 Scanner User’s Guide MSI Plessey- -ANY LENGTH SECTION 2...

  • Page 99: Msi Plessey Check Digit

    Check digits are not automatically transmitted with the data. If two check digits is selected, an MSI Plessey Check Digit Algorithm must also be selected. See Page 2-79. Scanner Parameters ONE MSI Plessey CHECK DIGIT TWO MSI Plessey CHECK DIGITS SE 1223 Scanner User’s Guide 2-77...

  • Page 100: Transmit Msi Plessey Check Digit

    Scan this symbol if you want to transmit the check digit with the data. TRANSMIT MSI Plessey CHECK DIGIT (ENABLE) Scan this symbol if you want to transmit the data without the check digit. DO NOT TRANSMIT MSI Plessey CHECK DIGITS (DISABLE) 2-78 SE 1223 Scanner User’s Guide...

  • Page 101: Msi Plessey Check Digit Algorithm

    MSI Plessey Check Digit Algorithm If TWO MSI Plessey CHECK DIGITS is selected, an additional verification is required to ensure integrity. One of the following check digit combinations must be selected. MOD 10/MOD11 MOD 10/MOD 10 SE 1223 Scanner User’s Guide 2-79...

  • Page 102: Transmit Code Id Character

    Transmit Code ID Character A code ID character identifies the code type of a scanned bar code. This may be useful when the scanner is decoding more than one code type. In addition to any single character prefix already selected, the code ID character is inserted between the prefix and the decoded symbol.
  • Page 103 SECTION 2 Scanner Parameters SYMBOL CODE ID CHARACTER AIM CODE ID CHARACTER NONE SE 1223 Scanner User’s Guide 2-81...

  • Page 104: Prefix/Suffix Values

    CANCEL bar code on page 2-88. " NOTE: In order to use Prefix/Suffix values, the Scan Data Transmission For- mat must be set (see page 2-84). 2-82 SE 1223 Scanner User’s Guide SECTION 2...
  • Page 105 SECTION 2 Scanner Parameters SCAN PREFIX SCAN SUFFIX 1 SCAN SUFFIX 2 DATA FORMAT CANCEL SE 1223 Scanner User’s Guide 2-83...

  • Page 106: Scan Data Transmission Format

    Scanner Parameters Scan Data Transmission Format To change the Scan Data Transmission Format, scan one of the eight bar codes below or on the following page corre- sponding to the desired format. 2-84 SE 1223 Scanner User’s Guide SECTION 2...
  • Page 107 SECTION 2 Scanner Parameters DATA AS IS <DATA>< SUFFIX 1> <DATA>< SUFFIX 2> <DATA><SUFFIX 1><SUFFIX 2> SE 1223 Scanner User’s Guide 2-85...
  • Page 108 Scanner Parameters SECTION 2 <PREFIX><DATA> <PREFIX><DATA><SUFFIX 1> <PREFIX><DATA><SUFFIX 2> <PREFIX><DATA><SUFFIX 1> <SUFFIX 2> 2-86 SE 1223 Scanner User’s Guide...

  • Page 109: Numeric Bar Codes

    SECTION 2 Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriate bar code(s) on this foldout page. Scanner Parameters SE 1223 Scanner User’s Guide 2-87...

  • Page 110: Cancel

    Scanner Parameters Cancel If you make an error, or wish to change your selection, scan the bar code below. 2-88 SE 1223 Scanner User’s Guide SECTION 2 CANCEL...

  • Page 111: Scanner Specifications

    " " " " " " " " This section details the specifications for the following ver- sions of the SE 1223 Scanner: Standard " Wide Angle " Very High Density (VHD) " Long Range (LR) " SE 1223 Standard Scanner...
  • Page 112 Scanner Specifications SE 1223 Standard Scanner Technical Specifications Item Laser Power Scan Angle Pitch Angle Skew Tolerance Roll Ambient Light Immunity Sunlight Artifical Light Shock Vibration Laser Class Operating Temperature Storage Temperature Humidity Height Width Depth Weight SE 1223 Scanner User’s Guide...

  • Page 113: Se 1223 Standard Scanner Decode Zone

    SECTION 3 SE 1223 Standard Scanner Decode Zone The standard SE 1223 scanner decodes the symbols as de- scribed in Table 3-2. The numbers shown are typical values as well as guaranteed values. The minimum element width (or symbol density) is the width in mils of the narrowest element (bar or space) in the symbol.

  • Page 114: Se 1223 Wide Angle Scanner

    Scanner Specifications d = The housing’s internal optical path (in inches) from the edge of the housing to the front of the scanner. A = Scan angle in degrees (42°). L = 1.8 x (D + d) x Tan 21°) "...
  • Page 115 SECTION 3 SE 1223 Wide Angle Scanner Technical Specifications Item Roll Ambient Light Immunity Sunlight Artifical Light Shock Vibration Laser Class Operating Temperature Storage Temperature Humidity Height Width Depth Weight Table 3-3 (continued) Description ±20° from vertical 8000 ft candles 86,112 lux with correct exposure 450 ft candles 4844 lux 2000 G applied via any mounting surface @ 23°C...

  • Page 116: Se 1223 Wide Angle Scanner Decode Zone

    Scanner Specifications SE 1223 Wide Angle Scanner Decode Zone The wide angle SE 1223 scanner decodes the symbols as described in Table 3-4. The numbers shown are typical val- ues as well as guaranteed values. The minimum element width (or symbol density) is the width in mils of the nar- rowest element (bar or space) in the symbol.

  • Page 117: Se 1223 Very High Density (Vhd) Scanner

    SECTION 3 d = The housing’s internal optical path (in inches) from the edge of the housing to the front of the scanner. A = Scan angle in degrees (53°). L = 1.8 x (D + d) x Tan 26.5°) "...
  • Page 118 Scanner Specifications SE 1223 VHD Scanner Technical Specifications Item Skew Tolerance Roll Ambient Light Immunity Sunlight Artifical Light Shock Vibration Laser Class Operating Temperature Storage Temperature Humidity Height Width Depth Weight SE 1223 Scanner User’s Guide Table 3-5 (continued) Description ±60°...

  • Page 119: Se 1223 Very High Density (Vhd) Scanner Decode Zone

    SECTION 3 SE 1223 Very High Density (VHD) Scanner Decode Zone The SE 1223 VHD scanner decodes the symbols as de- scribed in Table 3-6. The numbers shown are typical values as well as guaranteed values. The minimum element width (or symbol density) is the width in mils of the narrowest element (bar or space) in the symbol.

  • Page 120: Se 1223 Long Range (Lr) Scanner

    D = Distance (in inches) from the front edge of the housing. d = The housing’s internal optical path (in inches) from the edge of the housing to the front of the scanner. A = Scan angle in degrees (37°). L = 1.8 x (D + d) x Tan 18.5°) "...
  • Page 121 SECTION 3 SE 1223 LR Scanner Technical Specifications Item Pitch Angle Skew Tolerance Roll Ambient Light Immunity Sunlight Artifical Light Shock Vibration Laser Class Operating Temperature Storage Temperature Humidity Height Width Depth Weight Table 3-7 (continued) Description ±65° from normal straight out ±60°...

  • Page 122: Se 1223 Long Range (Lr) Scanner Decode Zone

    Scanner Specifications SE 1223 Long Range (LR) Scanner Decode Zone The SE 1223 LR scanner decodes the symbols as described in Table 3-8. The numbers shown are typical values as well as guaranteed values. The minimum element width (or symbol density) is the width in mils of the narrowest ele- ment (bar or space) in the symbol.
  • Page 123 D = Distance (in inches) from the front edge of the housing. d = The housing’s internal optical path (in inches) from the edge of the housing to the front of the scanner. A = Scan angle in degrees (23°). L = 1.8 x (D + d) x Tan 11.5°...
  • Page 124 Scanner Specifications SECTION 3 3-14 SE 1223 Scanner User’s Guide...

  • Page 125: Prefix And Suffix Character Equivalent Table

    CTRL H CTRL H CTRL I CTRL J CTRL J CTRL K CTRL K CTRL L CTRL L CTRL M CTRL M CTRL N CTRL N SE 1223 Scanner User’s Guide Appendix A " " " " " " " "...
  • Page 126 1033 1033 1034 1034 1035 1035 1036 1036 1037 1037 1038 1038 SE 1223 Scanner User’s Guide APPENDIX A Keystroke CTRL O CTRL P CTRL P CTRL Q CTRL Q CTRL R CTRL R CTRL S CTRL S CTRL T...
  • Page 127 1051 1052 1052 1053 1053 1054 1054 1055 1055 1056 1056 1057 1057 1058 1059 1059 1060 1060 1061 1061 1062 1062 Prefix and Suffix Character Equivalent Table Keystroke ’ ’ < < > > SE 1223 Scanner User’s Guide...
  • Page 128 1070 1070 1071 1071 1072 1072 1073 1073 1074 1074 1075 1076 1076 1077 1077 1078 1078 1079 1079 1080 1080 1081 1081 1082 1082 1083 1083 1084 1084 1085 1086 1086 SE 1223 Scanner User’s Guide APPENDIX A Keystroke...
  • Page 129 1097 1097 1098 1098 1099 1099 1100 1100 1101 1101 1102 1103 1103 1104 1104 1105 1105 1106 1106 1107 1107 1108 1108 1109 1109 1110 Prefix and Suffix Character Equivalent Table Keystroke ‘ ‘ SE 1223 Scanner User’s Guide...
  • Page 130 Values from 1128 through 1255 (hex values 80h through FFh for SSI) may also be set. But the conversion of those characters to printable characters is not standarized. Therefore, they are not included in this table. SE 1223 Scanner User’s Guide APPENDIX A Keystroke undefined...

Table of Contents
