Appendix D — Setup Parameters (IPL)

Setup Description

Printing Test Labels With IPL Commands

Navigating the Setup Tree

100
The printer's setup parameters control the way the printer
operates. The setup parameters can be accessed and changed in a
variety of ways, see "Changing Configuration Settings" on
page 31 for more information.
Note: The recommended way to set your printer's configuration
parameters is to use the PrintSet 4 program, which is included on
the PrinterCompanion CD. PrintSet 4 can communicate with
your printer either via a serial cable or a network connection.
Test labels that give detailed information about the printer's
software, hardware and network settings can be printed in
testmode or extended testmode, but also by sending commands
through the terminal window. For example, the following
commands print a software configuration label, and then returns
the printer to print mode:
<STX><ESC>T;s;R;<ETX>
Please refer to the IPL Programmer's Reference Manual (P/N
066396-xxx) for more information on how to print test labels.
This section provides an overview of the branches and nodes in
the setup tree, as it is presented in the display window.
Note: The setup tree is shown as it exists in IPL 10.2.0.
Dotted boxes indicate features that are only available on printers
equipped with optional equipment.
Boxes with thick frames indicate default settings.
Values inside brackets can be modified to any value specified by
the user.
EasyCoder PD42 Printer User's Guide
