Installation Kit

EasyCoder XP- & F-Series
Double Serial Interface Board
Installation Instructions
Edition 2, January 2001
Part No. 1-960472-01
EasyCoder XP- & F-Series Double Serial Interface Board – Installation Instructions Ed. 2
The Double Serial Interface Board is an optional device for
EasyCoder 501 XP, EasyCoder 601 XP, EasyCoder F2, and
EasyCoder F4, that provides the printer with two extra inter-
faces, "uart2:" and "uart3:". The printer must be fi tted with the
Intermec Fingerprint v7.xx fi rmware.
This interface can be fi tted with straps and circuits for one of
the following alternatives:
• RS-232
• RS-422 non isolated
• RS-422 isolated
• RS-485
This interface can be fi tted with straps and circuits for one of
the following alternatives:
• RS-232
• RS-422 non isolated
• 20 mA Current Loop
The Double Serial Interface Kit contains:
• One interface board fi tted for RS-232 on both interfaces.
• One cover plate (for EasyCoder XP-series printers only.)
• One fl at cable (for EasyCoder F-series printers only.)
• This Installation Instruction booklet.
Circuits for RS-422 non-isolated, RS-422 isolated, RS-485,
and 20 mA current loop can be bought separately from Inter-
mec.
