Appendix A— Specifications

3600 Specifications

76

Dimensions (no options installed)

Height 27.9 cm (11 in)
Width 30.5 cm (12 in)
Length 43.2 cm (17 in)
Weight 20.3 kg (45 lbs)

Character Sets

US ASCII Norwegian/Danish
UK ASCII Swedish/Finnish
German Italian
French Spanish
Swiss

Memory

Base 512K of DRAM
128K of SRAM standard, 60K default allocated for storage
Optional 512K of SRAM expanded

Printhead

Printed dot size 0.13 mm (0.00492 in) square
Width 171 mm (6.6 in) maximum
Resolution 8 dots per mm (203 dots per in)
Number of elements 1,344 per printhead
"X" dimensions 10 mil to 50 mil (0.25 mm to 1.27 mm); 5 mil (0.13 mm)
in drag mode only (specified media only)

Ribbon

Roll 152 m (6,000 linear in)
Widths 80 mm (3.15 in)
107 mm (4.21 in)
128 mm (5.04 in)
168 mm (6.60 in)
Diameter 57 mm (2.25 in) maximum

Printing Speed

Maximum 127 mm (5 in) per second
Minimum 50.8 mm (2 in) per second
You can change the print speed in 1 ips increments only: 2, 3, 4, or 5.
3400, 3440, and 3600 Bar Code Label Printer User's Manual
