Printing the Hardware Configuration Test Label

3400, 3440, and 3600 Bar Code Label Printer User's Manual
7 Release the lower media guide and adjust the edge guide to position the
media firmly against the inside wall of the printer.
8 Slide the supply roll retainer up to the edge of the fanfold media and
turn the supply roll retainer clockwise until it locks firmly in place
securing the media against the inside wall of the printer.
9 Engage the printhead by rotating the head lift lever counterclockwise
until it locks.
10 Close the printer by reversing the directions for removing the cover.
11 Press Feed/Pause to advance one label through the printer and out the
label opening in the front cover. The printer is now ready to print the
configuration test label. The yellow Empty/Pause LED goes out.
If the yellow Empty/Pause LED does not go out, press Feed/Pause a
second time and then reload the media and try again if the Empty/Pause
LED still does not go out.
Note: For your convenience, refer to the label with directions for loading
media. This label is located on the inside of the media cover.
You can print the hardware configuration test label to test the printer and
make sure it is operating correctly. The hardware configuration test label
lists the printer's configuration. Use this label for reference when installing
your printer and for verification of proper printer operation.
To print the hardware configuration test label
1 Turn the On/Off switch to the off position.
2 Press and hold the Feed/Pause button while you turn the On/Off switch
to the on position. The Alert and Empty/Pause LEDs blink during the
printer self-test.
3 Release the Feed/Pause button when the media starts moving. The
printer feeds out one or two blank labels and then prints the hardware
configuration test label.
Note: This is only an example of a hardware configuration label. Your
label may not be exactly the same.
Chapter 1— Getting Started
7
