- Page 1 Installation Instructions Trakker Antares 2455/2475 DC Power Supply ®...
- Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
- Page 3 This document assumes that you have already installed the 2455 or 2475 on your vehicle. For help, see the Trakker Antares 2455 Vehicle-Mount Terminal Getting Started Guide (Part No. 067359) or the Trakker Antares 2475 Vehicle-Mount Terminal Installation Instructions (Part No.
-
Page 4: Required Tools And Materials
Trakker Antares 2455/2475 DC Power Supply Installation Instructions Preparing to Install the 2455/2475 DC Power Supply You need certain tools and materials to install the 2455/2475 DC power supply. Make sure you follow the recommended installation guidelines. Required Tools and Materials... - Page 5 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Installing the 2455/2475 DC Power Supply and Cables The following illustration shows how the DC power supply and cables are installed with your vehicle battery and the 2455 or 2475 terminal. Fused...
- Page 6 DC power supply and the 2455 or 2475. Intermec recommends a switch that is rated to handle a minimum of 10A DC power. Any additional wiring must be a minimum of 16 AWG. If the total length of the switched (positive) lead exceeds 3.048 m (10 ft), the additional wiring must be a...
-
Page 7: Mounting The Power Supply
Trakker Antares 2455/2475 DC Power Supply Installation Instructions To wire a remote disconnect 1. Cut the positive (red) wire on the unterminated end of the fused power cable. 2. Wire the positive lead of the fused power cable through the ignition or to a remote switch. - Page 8 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Because the power supply produces heat while operating, Intermec recommends that you mount the power supply to a minimum of 838.5 to 1032 sq cm (130 to 160 sq in) of metallic surface to sink the heat generated by the power supply. This metallic mounting surface must be connected to the vehicle chassis electrically.
- Page 9 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Installing Terminators on the Power Supply Input Cable You need to trim the power supply input cable and then install terminators so that you can connect the cable to the fused power cable.
- Page 10 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Connecting the Power Supply Input Cable to the Power Supply The power supply input cable has either a 2-pin, high-input voltage (15 to 96 VDC) connector or a 4-pin, low-input voltage (10 to 36 VDC) connector on one end. Make sure your cable has the proper cable connector for your power supply.
- Page 11 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Attaching the 2455/2475 Power Cable to the DC Power Supply and to the Terminal The 2455/2475 power cable ships with the terminal. The cable is approximately 1.8 m (6 ft) long and has a durable 3-pin connector on the power supply end. The terminal end of the cable has a 4-socket connector that is environmentally protected.
-
Page 12: Troubleshooting Information
Reconnect the vehicle battery cables. You are now ready to begin using your 2455 or 2475. For help operating your 2455 or 2475, refer to the Trakker Antares 2455 Vehicle- Mount Terminal User’s Manual (Part No. 067358) or the Trakker Antares 2475 Vehicle-Mount Terminal User’s Manual (Part No. - Page 13 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Inspecting the Power Supply Components There are three components you can inspect: Power supply The power supply has a green LED near the output connector that lights when 12 VDC is present at the connector. If you suspect a power failure, check to see if the LED is lit.
- Page 14 Trakker Antares 2455/2475 DC Power Supply Installation Instructions Low-Input Voltage Power Supply Input Cable Connector Contact view Continuity An ohmmeter is sufficient to diagnose simple opens and shorts. Note: If fuses blow sporadically or power supply shutdown occurs at random, you may want to check cables for high-resistance shorts between wires or between a wire and the cable shield.
-
Page 15: Troubleshooting Table
Trakker Antares 2455/2475 DC Power Supply Installation Instructions Troubleshooting Table The following information assumes that your 2455 or 2475 does not work and that the problem is caused by the power supply or the power supply cables. You Observe Meaning Power supply LED is lit. -
Page 16: Dc Power Supply Specifications
Trakker Antares 2455/2475 DC Power Supply Installation Instructions DC Power Supply Specifications Use the specifications in this section to prepare a mounting location on the vehicle for the power supply. The low-input and high-input DC power supplies have the same dimensions.
