Intermec Trakker Antares 2420 Accessory Manual

P/N 064217-004
TRAKKER Antares 2400 Series Handstrap
Instruction Sheet
The handstrap is a convenient way to help you grasp and hold the
TRAKKER
grip the terminal. When you use the terminal for an extended
period of time, the handstrap helps relieve hand stress.

To install the handstrap

1. Using a Phillips screwdriver, unscrew and remove the screw located
®
Antares 2420 or 2425 terminal. It is designed to let you securely
™
on the bottom case of the terminal. Save and reuse this screw to attach
the handstrap.
Note: Unscrewing additional screws could void your warranty. For more
information, see your terminal user's manual.
T-bar
Elastic band
Bracket
Bracket
guides
(2 places)
Bracket
slots
(2 places)
Screw
T-bar
opening
242XI.003
