- Page 1 Installation Guide P/N 067363-002 TRAKKER Antares ® 2455 Keyboard...
- Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
- Page 3 TRAKKER Antares 2455 Keyboard Installation Guide This installation guide explains how to install your TRAKKER Antares keyboard. The T2455 keyboard assembly kit includes the following: Keyboard #8 straight-slot screws, ½-inch (12.7 mm) long (4) #8 straight-slot screws, ¼-inch (6.35 mm) long (4) #8 Phillips screws, .375-inch (9.52 mm) long, with cone washers (4)
-
Page 4: Mounting The Keyboard
You can mount your keyboard to the terminal using the hardware provided. If the terminal is already installed on the terminal mounting bracket, you need to remove the terminal from the bracket to install the keyboard. See the TRAKKER Antares 2455 Vehicle-Mount Terminal Getting Started Guide (Part No. 067359) for more information. - Page 5 Attaching the Hinges to the Keyboard 4. Repeat Steps 2 and 3 for the other hinge. 5. Position the T2455 so the four mounting holes in the bottom of the terminal are facing up. 6. Align the mounting holes in the bottom of the terminal with the remaining holes in the hinges.
- Page 6 T2455 Keyboard Installation Guide 9. Position one keyboard mounting bracket against the terminal as shown in the following illustration. Loosely secure the bracket to the terminal using the #8 Phillips screws with cone washers and the Phillips screwdriver. Slide the bracket to the outermost position.
- Page 7 To mount the keyboard to a remote location 1. Determine the mounting locations for the terminal and the keyboard. Mount the terminal as instructed in the TRAKKER Antares 2455 Vehicle-Mount Terminal Getting Started Guide (Part No. 067359). 2. Use a #1 Phillips screwdriver to remove the six screws that secure the back plate to the keyboard.
- Page 8 T2455 Keyboard Installation Guide Mounting the Keyboard to a Remote Location Back plate screw (6 places) Mounting screw (4 places) Connecting the Keyboard Cable to the Terminal Now that you have installed your keyboard, you need to connect it to the terminal. 1.
-
Page 9: Specifications
Connecting the Keyboard Cable to the Terminal 3. Use the straight-slot screwdriver to tighten the screws in the keyboard cable connector and secure the cable to the T2455. 4. Tuck any excess cable into the back of the keyboard. 5. If you attached the keyboard directly to the terminal, you need to mount the terminal and keyboard in the terminal mounting bracket. - Page 10 T2455 Keyboard Installation Guide Keyboard Back Plate Specifications .562 in 1.43 cm .21 in 5.334 mm 1.69 in 4.29 cm 1.063 in 2.7 cm Note: This keyboard back plate illustration is not shown to scale. Keyboard Specifications (Top View) Cable exit location Note: This keyboard illustration is not shown to scale.
- Page 11 Keyboard Specifications (Front View) 4.10 in 10.414 cm Note: This keyboard illustration is not shown to scale. Keyboard Specifications (Side View) 1.72 in 4.369 cm 1.00 in 2.54 cm Note: This keyboard illustration is not shown to scale. T2455 Keyboard Installation Guide 11.24 in 28.55 cm 2455I.010...
