- Page 1 ASSEMBLY INSTRUCTIONS juno nightstand a how-to guide that won’t leave you in tears...
- Page 2 parenting is hard. this is easy. no really, it is. MADE HERE™ MADE WELL™ MADE SAFE MADE SMART...
- Page 3 want to watch this assembly IRL? (acronym challenged? that means “in real life”.) open the camera on your phone and place it over the QR code below to see our NYC studio dream team do all the heavy lifting (just kidding, there is none!) or go to ducducnyc.com/pages/assembly-instructions...
- Page 4 thank you for selecting a studio duc product!
-
Page 5: Maintenance
please check contents against the components list in these instructions. also, please ensure there was no damage that may have occurred in shipping. if any components are missing or you find any damage, please contact ducduc before continuing. read all the instructions before use. pay close attention to the safety warnings in these instructions. -
Page 6: What's In The Box
WHAT’S IN THE BOX: R side panel L side panel back panel DB1 (x2) hammer cap stretcher drawer face DB2 (x2) drawer box back bottom DB3 (x2) DB4 (x2) L drawer box side R drawer box side DB5 (x2) drawer box bottom... -
Page 7: What You'll Need
WHAT YOU’LL NEED: household hammer or rubber mallet a soft surface to assemble on 15 minutes (like a rug or some of the corrugate (or less) box your piece arrived in) 2 people plus a dog for moral support (unless you’re a cat person) - Page 8 lean R side panel (A1) against a wall as shown. insert connectors of back panel (B) into slots on R side panel (A1). push down at the connection to lock into place. still confused? scan this code to watch the assembly video!
- Page 9 insert connectors of back panel (B) into slots on L side panel (A2). push down at the connection to lock into place. have a friend gently flare R + L side panels (A1 + A2) outward as shown. still confused? scan this code to watch the assembly video!
- Page 10 with the side panels flared outward, insert connectors of bottom panel (D) into slots on R side panel (A1). insert remaining connectors of bottom panel (D) into slots on L side panel (A2). still confused? scan this code to watch the assembly video!
- Page 11 once all connectors and slots are lined up and side panels are back to square position, apply hammer cap (F) to the head of a household hammer and tap bottom panel (D) until there is no gap at the connection to back panel (B). still confused? scan this code to watch the assembly video!
- Page 12 insert connectors of stretcher (C) into slots on both side panels (A1 + A2). tap with hammer and hammer cap (F) to lock into place. still confused? scan this code to watch the assembly video!
- Page 13 with a friend, flip partially assembled case into upright position. line up holes of top (E) and insert with the connectors of side panels (A1 + A2) and back panel (B). tap with hammer and hammer cap (F) to lock into place. still confused? scan this code to watch the assembly video!
- Page 14 now we build the drawers! starting with drawer face (DB1) facing down, insert connectors of both drawer box side panels (DB3 + DB4) into slots on drawer face (DB1). push down at the connections to lock into place. still confused? scan this code to watch the assembly video!
- Page 15 rotate the partially assembled drawer box as shown. slide drawer box bottom (DB5) into place using grooves on the drawer box side panels (DB3 + DB4) as guides. be sure glide hardware on bottom panel (DB5) is positioned outside the drawer interior and toward the drawer face (DB1) as shown.
- Page 16 build remaining drawer using steps 7a, 7b, and 7c. starting at the top, pull drawer glides out to extended position as shown. still confused? scan this code to watch the assembly video!
- Page 17 place one assembled drawer box onto extended glides as shown. from underside of drawer, use hands to pull each glide forward until it locks into connection with glide hardware attached to drawer box bottom (DB5). the drawer will be secure when you hear a click on each connection.
- Page 18 woohoo! you did it! give yourself a pat on the back, take a bow, or go house a pint of ice cream…we don’t judge.
- Page 19 prefer to talk to a human instead? we’re here for you! contact our customer advocate team below: 212.226.1868 quack@ducducnyc.com live chat at 200 lexington, no. 1201 ducducnyc.com ny, ny 10016...
