8. The possible presence of residual quantities of aggressive or decomposed chemicals in the load may produce
damage to the machine and harmful fumes.
9. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust
ductwork, and inside the dryer. The frequency of inspection and cleaning can best be determined from
experience at each location.
WARNING: The collection of lint in the burner area and exhaust ductwork could create a fire hazard.
10. For personal safety, the dryer, when installed must be electrically grounded in accordance with local codes
or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian
Electrical Code, CSA C22.1.
NOTE: Failure to electrically ground the dryer properly will VOID THE WARRANTY.
11. UNDER NO CIRCUMSTANCES should the dryer door switch, lint door switch, or the heat safety
circuit ever be disabled.
WARNING: PERSONAL INJURY OR FIRE COULD RESULT SHOULD THE DRYER
DOOR SWITCH, LINT DOOR SWITCH, OR THE HEAT SAFETY CIRCUIT
EVER BE DISABLED.
12. This dryer is not to be used in the presence of dry cleaning solvents or fumes.
13. Remove articles from the dryer as soon as the drying cycle has been completed.
WARNING: Articles left in the dryer after the drying and cooling cycles have been completed could
create a fire hazard.
14. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE DRYER.
15. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less
than sixty-six percent (66%), 76 lb (34.5 kg), of its rated capacity.
WARNING: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND
THE GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR
GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS
FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY
EQUIPMENT PER OSHA (Occupational Safety and Health Administration)
STANDARD.
IMPORTANT: Dryer must be installed in a location/environment in which the ambient
temperature remains between 40° F (4.44° C) and 130° F (54.44° C).
WARNING: Disconnect power before resetting the hi-limit. The hi-limit is located on the left side of
the burner box, looking at the burner from the back of the dryer. Press and release and
the hi-limit will reset.
CE ONLY
IMPORTANT: This appliance must only be installed and operated in the country of destination
indicated on the dryer's data plate. If the appliance is to be installed and operated in a
country other than the one indicated on the data plate, a data plate amendment must
be obtained from American Dryer Corporation.
IEC335 applies.
