Table 2–1. Model 2701-B Keypad Functions
KEY
〈STORE〉
〈STATUS〉
〈RECALL〉
〈PROJ〉
〈SETUP〉
〈TARGET〉
〈MODE〉
〈OFFSET〉
〈REF〉
〈SPACE〉
〈LIGHT〉
〈YES〉
〈NO〉
〈ESC〉
〈0〉 .. 〈9〉
〈.〉
〈ALPHA LOCK〉
〈BACK SPACE〉
〈↑〉, 〈↓〉
〈ENTER/START〉
〈A〉 .. 〈Z〉
Model 2701-B
FUNCTION
Store the most recent data in the current
project file.
Displays gauge status information.
Display the most recent data.
Select or create a project file and view,
output, or erase project data file.
Displays the gauge Setup menu.
Select, enter, or disable a Gmb (Marshall)
or Gmm (Voidless density) value.
Select the measurement mode,
Averaging, Continuous, or Segregation.
Enable, disable, or change a density
offset.
Take a reference reading.
Enter a space.
Manually toggle the keypad and LCD
backlights on and off.
Respond yes to yes/no questions.
Respond no to yes/no questions.
Return the display to the Ready screen
without storing or updating the data.
Enter numbers and access menu options.
Enter a decimal point.
Access the letters.
Moves cursor back one space.
Scroll through menu options or view
screens.
Accept data entry or begin a
measurement.
Enter letters. Access these keys by first
pressing 〈ALPHA LOCK〉.
PAGE
5–8
2–6
4–12
5–2
2–7
2–14
2–16
3–3
4–2
2–5
2–3
