Overview

S&C products may be revised to add new features to an
existing assembly. The revision information is listed after
the catalog number with "R" and the revision number. Parts
required for a specific revision are also refered to with the
same Rx designation.
An existing R0 Communication Module can be upgraded
to R3 functionality by installing the R3 Wi-Fi/GPS
transceiver and harnesses.
• S&C Power Systems Solutions can train utility
personnel to do the R3 retrofit.
• The retrofit must be done indoors at an electrostatic-
discharge (ESD) protected workbench.
• The SCADA radio can be configured in the shop for a
installation at a specific site.
• The R3 Communication Module can be easily installed
at the site by a line crew.
Note: The IntelliRupter fault interrupter remains fully
operational during the communication module swap.
There will be no service interruption.
Note: When establishing a rotation procedure to swap
communication modules at the site, each SCADA radio
must be configured in the shop for the specific site at
which it will be installed.
NOTICE
These instructions are intended for use only by
personnel trained by S&C Power Systems Solutions .
Electrostatic-discharge procedures must be followed
because components are sensitive to electrostatic-
discharge damage .
Use of an SCS 8501 Static Dissipative Mat and
Wrist Groundstrap or a static protected workbench
is required .
NOTICE
The R3 retrofit must be done indoors in a laboratory or
shop environment on a static-controlled workbench .
NOTICE
Installation of the R3 retrofit kit without proper training
will void the warranty . Contact S&C to arrange for
training provided by S&C Power Systems Solutions .
