Insinger DEFENDER 17 Specifications

6245 State Road
Philadelphia, PA 19135-2996
215-624-4800
215-624-6966 FAX
800-344-4802
www.insingermachine.com
DEFENDER
AUTOMATIC DOUBLE TANK
RACKLESS CONVEYOR
DESIGN
Automatic conveyor, flight type two tank dishwasher with
recirculating prewash and wash zones and fresh hot water final
rinse. Capacity is 8,861 dishes per hour with a conveyor speed of
7.1ft. per minute. Designed for left or right hand conveyor travel,
as specified.
STANDARD EQUIPMENT
Exclusive CrossFire Wash
®
●
System (patented)
Wash tank heat: 40KW
●
electric immersion heaters or
steam injectors
Capillary thermometers for
●
prewash and wash tanks and
final rinse
Final rinse pressure gauge
●
Vacuum breakers on all
●
incoming water lines
Manifold cleanout brush
●
Inspection and cleanout doors
●
Polypropylene belt with
●
removable rack sections
SureFire Start-Up and
TM
●
Check-Out Service
Simplified scrap screen design
●
Exhaust connections with
●
OPTIONAL ACCESSORY EQUIPMENT
Stainless steel steam coil
❏
tank heat
Pressure reduction valve
❏
and line strainer
Electric booster
❏
Stainless steel belt with
❏
removable rack sections
Item #_____________
adjustable dampers
Steam booster
●
Interior work lights
●
S/S frame, legs and feet
●
S/S front enclosure panel
●
Provision for detergent dispenser
●
and rinse agent injector
connection
Top mounted NEMA 12
●
control panel
Automatic tank fill with
●
low water protection
Door safety switches
●
Energy saver override switch
●
for deliming
Conveyor reversing switch
●
Conveyor safety stop bar
●
Standard frame, drip proof motors
●
Color-coded curtains
●
Single electrical connection:
❏
motors, controls, and heaters
Security package
❏
S/S panels all sides
❏
Insulated hood and doors
❏
Totally enclosed motors
❏
Totally enclosed motors
❏
