Insinger ADMIRAL 66-4 Specifications

Patented CrossFire ® Wash
System creates a fan shaped
spray to clean ware thoroughly
6245 State Road
Philadelphia, PA 19135-2996
215-624-4800
215-624-6966 FAX
800-344-4802
www.insingermachine.com
ADMIRAL 66-4
SINGLE TANK CONVEYOR
DISHWASHER WITH
RECIRCULATING PREWASH
DESIGN
Automatic conveyor, rack type single tank dishwasher with recir-
culating prewash and wash and fresh water final rinse. Capacity
is 233 - 20"X20" racks per hour, or 5,825 dishes per hour with a
conveyor speed of 6.4 ft. per minute. Designed for left or right
hand conveyor travel, as specified.

STANDARD EQUIPMENT

Exclusive CrossFire Wash System
®
●
(patented)
Tank heat: 15 KW electric
●
immersion heater or
steam injector
Capillary thermometers for
●
prewash and wash
In-line thermometer for final rinse
●
Vacuum breaker on all incoming
●
water lines
S/S vestibules
●
Manifold cleanout brush
●
Inspection doors
●
S/S frame, legs and feet
●
S/S front enclosure panel
●
Automatic tank fill
●
Low water protection
●
Single point electrical connection:
●
motor, controls, and heater
OPTIONAL ACCESSORY EQUIPMENT
Pressure reduction valve and
❏
line strainer
Stainless steel steam coil
❏
tank heat
Infrared tank heat—
❏
50,000 BTU natural gas
or propane
Steam booster
❏
Electric booster
❏
Vent and adjustable
❏
damper controls
Security package
❏
Item #_____________
Detergent connection provision
●
Elevated top mounted NEMA 12
●
control panel
Easily-cleaned crowned hood top
●
Simplified scrap screen design
●
Door safety switches
●
Standard frame drip proof motors
●
Energy saver
●
Detergent saver
●
Override switch for de-liming
●
SureFire Start-Up and
TM
●
Check-Out Service
Ventilation fan connection
●
provision
End caps/pipe plugs secured to
●
prevent loss
Color-coded curtains
●
Timing belt conveyor drive
●
Totally enclosed motors
❏
Rack limit switch
❏
Chemical sanitizer injector
❏
package for low temperature
operations
Insulated hood and doors
❏
Power loader
❏
Power unloader
❏
Door activated drain closers
❏
Plastic 20"X20" racks
❏
(plate or silver)
