Instructions for Installation and Care of Honda Pioneer 1000 5 Full Cab Fits Lexan Windshield
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
1.
Check over the parts included in the carton with the parts list shown below:
2.
Adhesive Velcro Hook Strips:
"
"
"
"
Snap Studs ------------------------------ 11 each (1 extra )
---------------------------------------------------------------------------
"
"
"
Snap Studs ------------------------------ 9 each (1 extra)
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
---------------------------------------------------------------------------
Webbing Straps w/ Velcro
Webbing Straps w/ Grommets
Webbing Straps w/Loop
Adhesive Velcro Hook Strips:
If any parts are damaged or missing please contact customer service at (606) 845-7439.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
HO-P10005-FC05
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
Soft Front Doors
16 each------------3"
2 each------------5"
2 each------------6"
2 each------------8"
Soft Rear Doors
12 each------------3"
2 each------------2"
2 each------------9"
Middle Rear Window
8 each------------3"
1 each------------47"
Rear Rear Window
6 each------------3"
1 each------------64"
Top Cap
4 each
2 each
2 each
4 each-------------6"
Advertisement
Related Manuals for FALCON RIDGE HO-P10005-FC05
Summary of Contents for FALCON RIDGE HO-P10005-FC05
- Page 1 606-845-7439 Instructions for Installation and Care of Honda Pioneer 1000 5 Full Cab Fits Lexan Windshield HO-P10005-FC05 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
- Page 2 The cab for your Honda Pioneer 1000 5 is made up of 7 different components that work together to enclose your vehicle. Install the cab in the following order. 1) Soft Front Doors 2) Middle Rear Window 3) Soft Rear Doors 4) Rear Rear Window 5) Top Cap Soft Front Doors:...
- Page 3 Next hold the door up to the frame and attach these spots then continue attaching it using the double- sided Velcro strips sewn perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that the adhesive strip holds it firmly in place.
- Page 4 Once all the Velcro is attached securely take the snap studs and screw them into the plastic doors. NOTE: It helps to put the snap studs into the sockets in the canvas first. Then one at a time push the screw into the plastic hard enough so that a mark is left behind. Pull the snap stud back out of the door and screw it into the plastic where the mark was made.
- Page 5 Next attach the double-sided Velcro strips down the side bars. Start at the top and work your way down the tube. See photo below. Soft Rear Doors: Begin by placing the 2" adhesive Velcro strip in the top front corner on the flat surface shown in the photo below.
- Page 6 Then take the Rear Door and zip it to the Middle Rear Window. This ensures the door is properly placed. Then attach the top front corner to the Velcro. See photo below. Next use the 9" adhesive Velcro strip for the tab on the top rear section of the door. See photo below. Then attach the 3"...
- Page 7 Once all the Velcro is attached securely take the snap studs and screw them into the plastic doors. NOTE: It helps to put the snap studs into the sockets in the canvas first. Then one at a time push the screw into the plastic hard enough so that a mark is left behind. Pull the snap stud back out of the door and screw it into the plastic where the mark was made.
- Page 8 TOP CAP: After you have installed your Lexan windshield installed on your Honda you can take the straps with grommet holes in them and install it on the middle bolt of the windshield. Put the grommet through the bolt and reattach. The strap with loop should look like the following photo. Next take the other two straps with Velcro sewn on one end and wrap them around the roll cage in the rear just under the Rear Door.
- Page 9 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
-
