Honda Pioneer 1000 5 Front and Rear Doors and Middle Rear Window Combo
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
1. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
2. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
"
"
Snap Studs ------------------------------ 11 each (1 extra)
---------------------------------------------------------------------------
"
"
"
Snap Studs ------------------------------ 9 each (1 extra)
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
If any parts are damaged or missing please contact customer service at (606) 845-7439.
The cab for your Honda Pioneer 1000 5 is made up of 5 different components that work together to enclose
your vehicle. Install the cab in the following order.
1) Soft Front Doors
2) Middle Rear Window
3) Soft Rear Doors
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
HO-P10005-FRDMRW01
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
Soft Front Doors
16 each------------3"
2 each------------5"
2 each------------6"
2 each------------8"
Soft Rear Doors
12 each------------3"
2 each------------2"
2 each------------9"
Middle Rear Window
8 each------------3"
1 each------------47"
Advertisement
Related Manuals for FALCON RIDGE HO-P10005-FRDMRW01
Summary of Contents for FALCON RIDGE HO-P10005-FRDMRW01
- Page 1 Instructions for Installation and Care of Honda Pioneer 1000 5 Front and Rear Doors and Middle Rear Window Combo HO-P10005-FRDMRW01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
- Page 2 Soft Front Doors: 1. Begin by placing the 5", 6" and 8" adhesive Velcro strips in their place. The following pictures show where they go.
- Page 3 2. Next hold the door up to the frame and attach these spots then continue attaching it using the double- sided Velcro strips sewn perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that the adhesive strip holds it firmly in place.
- Page 4 3. Once all the Velcro is attached securely take the snap studs and screw them into the plastic doors. NOTE: It helps to put the snap studs into the sockets in the canvas first. Then one at a time push the screw into the plastic hard enough so that a mark is left behind.
- Page 5 6. Next attach the double-sided Velcro strips down the side bars. Start at the top and work your way down the tube. See photo below. Soft Rear Doors: Begin by placing the 2" adhesive Velcro strip in the top front corner on the flat surface shown in the photo below.
- Page 6 2. Then take the Rear Door and zip it to the Middle Rear Window. This ensures the door is properly placed. Then attach the top front corner to the Velcro. See photo below. 3. Next use the 9" adhesive Velcro strip for the tab on the top rear section of the door. See photo on the next page.
- Page 7 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
-
Page 8: Return Policy
Any returns submitted to Falcon Ridge without a return authorization number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you must first call them and see what their return policy is. Once your item reaches our production facility, our customer satisfaction team will inspect your item to ensure unused, factory new condition.
