- Page 1 SHELTER ASSEMBLY MANUAL Model # W10xL12xH 3.6m C3340 Back wall & frame of Container Shelter C3340 Back wall & frame...
- Page 2 SPECIFICATION Width:10m Length:12m Height:3.6m IMPORTANT ----- READ MANUAL FIRST Improper site preparation, Assembly and Maintenance may invalidate warranty and cause unnecessary and costly mistake. If you have any questions contact your local dealer. For User Friendly assembly we have identified each individual component with the part code as indicated in the parts list.
- Page 3 PartsList Part Code Description Base plate with tie down ratchet Lateral base plate with tie down ratchet Added legs φ76*42cm Lower standpipe of back wallφ76*2.49m Middle standpipe of back wallφ76*2.49m Upper standpipe of back wallφ76*92cm Upper standpipe of lateral back wall φ60*74cm Middle Horizontal Tube for End Wall Middle Horizontal Tube for End Wall...
- Page 4 SPECIFICATION Width: 10m Length: 12m Height: 3.6m IMPORTANT ---- READ MANUAL FIRST Improper site preparation, Assembly and Maintenance may invalidate warranty and cause unnecessary and costly mistake. If you have any questions contact your local dealer. For User Friendly assembly we have identified each individual component with the part code as indicated in the parts list.
- Page 5 EQUIPEMNT AND TOOLS FOR INSTALIATION 1. Measuring tape 2. String for alignment 3. Step ladder 4. Welder 5. Sledge hammer 6. Wrench 7. Scissors INSTALLATION PROCESS A—FRAME INSTALLATION Please refer to the diagram (Figure 1) to install the Frame. Figure 1...
- Page 6 Figure 2 1. The measure is from center to center of the tubes. Referring to the above diagram. As the Figure 1 Shown, assembly the frame for end wall according to above drawing, No.1 is the Base plate needs to be fixed with stake peg (No.21). 3.
- Page 7 C- INSTRUCTION FOR COVER ATTACHED Install the Roof Cover NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A slight breeze is the most advantageous for cover installation. To take advantage of the breeze, pull the cover up over the arches with the breeze blowing in the cover like a sail filled with air.
