- Page 1 SHELTER ASSEMBLY MANUAL Model # C3340 Back wall & frame of Container Shelter C3340 Back wall & frame...
- Page 2 SPECIFICATION Width:33ft Length:40ft Height:15ft IMPORTANT ----- READ MANUAL FIRST Improper site preparation, Assembly and Maintenance may invalidate warranty and cause unnecessary and costly mistake. If you have any questions contact your local dealer. For User Friendly assembly we have identified each individual component with the part code as indicated in the parts list.
- Page 3 Parts List Part Code Description Base plates for winch door Eccentric base plates Standing leg at left Standing leg at right Side leg on the top for front and back endwall Lower standing leg at left Lower standing leg at right Upper standing leg for winch door Door beam 1 Group...
- Page 4 Rope for pull door Front cover Added legs Added door frame...
- Page 5 SPECIFICATION Width: 10m Length: 12m Height: 3.6m IMPORTANT ----- READ MANUAL FIRST Improper site preparation, Assembly and Maintenance may invalidate warranty and cause unnecessary and costly mistake. If you have any questions contact your local dealer. For User Friendly assembly we have identified each individual component with the part code as indicated in the parts list.
- Page 6 Be aware of personal safety during assembly and use. Be carful not to pinch fingers with clips and tubes when assembling: when using makes sure there is adequate ventilation for exhaust and other dangerous fumes. EQUIPEMNT AND TOOLS FOR INSTALIATION 1.
- Page 7 Figure 2 C--INSTRUCTION FOR COVER ATTACHED Assembly the end cover first. NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A slight breeze is the most advantageous for cover installation. To take advantage of the breeze, pull the cover up over the arches with the breeze blowing in the cover like a sail filled with air.
- Page 8 Figure 3 The process is quite easy. But some tightening adjustments will be necessary to produce a flat. Please adjust the cover timely.
