PANEL DESCRIPTION

I Front panel

–
CHANNEL SELECTOR [CHANNEL]
Selects an operating channel in the selected channel
group.
—
SCAN SWITCH [SCAN•
• Starts and stops normal or priority scan when tag chan-
nels are programmed. (p. 10)
• Push and hold for 1 sec. to toggle the tag setting for the
displayed channel. (p. 10)
˜
HIGH/LOW POWER SWITCH [HI/LO•
• Toggles between high and low output powers. (p. 9)
• While pushing, rotate the channel selector to adjust the
2
–
]
TAG
]
DIM
VHF MARINE
TAG TRI EMER
ALL
SCAN DUAL
16
/IND
DIM U / I / C
9
HI/LO CH/WX
š › œ
— ˜ ™
display and control/switch backlighting intensity. (p. 11)
™
CHANNEL/WEATHER CHANNEL SWITCH
[CH/WX• ]
U/I/C
• Selects and toggles between regular and weather chan-
nels.
• Selects one of 3 regular channels in sequence when
pushed for 1 sec. (p. 7)
➠ International, U.S.A. and Canadian channels are available for
regular channels.
š
DUAL/TRI-WATCH SWITCH [DUAL•
• Activates dualwatch for checking channel 16.
ž
PWR/VOL
OFF
SQUELCH

] (p. 8)
TRI
