Table of Contents

IN CASE OF EMERGENCY ..................................................i

TABLE OF CONTENTS ...................................................... ii

IMPORTANT ...................................................................... iii

CAUTIONS.......................................................................... iii

1 OPERATING RULES ..................................................... 1

2 PANEL DESCRIPTION ............................................ 2 - 5

I Front panel ................................................................. 2

I Microphone ................................................................. 3

I Function display .......................................................... 4

3 BASIC OPERATION .............................................. 6 - 11

I Power ON ................................................................... 6

I Channel selection ....................................................... 6

I Receiving .................................................................... 8

I Transmitting ................................................................ 9

I Scan function ............................................................ 10

I Call channel programming ........................................ 11

I Display backlighting .................................................. 11

4 DIGITAL SELECTIVE CALLING ......................... 12 - 18

I General ..................................................................... 12

I Distress call transmission ......................................... 13

I All ships call transmission ......................................... 14

I Individual call transmission ....................................... 15

I Receiving DSC calls ................................................. 16

5 SET MODE ........................................................... 19 - 21

I Entering SET mode .................................................. 19

I SET mode items ....................................................... 19

6 CONNECTIONS AND MAINTENANCE .............. 22 - 27

I Unpacking ................................................................ 22

I Additional requirements ............................................ 22

I Connections .............................................................. 23

I Mounting the transceiver .......................................... 24

I Dimensions ............................................................... 25

I Antenna .................................................................... 26

I Fuse replacement ..................................................... 26

I Cleaning ................................................................... 26

I Optional unit installations .......................................... 26

7 TROUBLESHOOTING ................................................ 28

8 VHF MARINE CHANNEL LIST ................................... 29

9 SPECIFICATIONS ....................................................... 30

10 OPTIONS ................................................................... 31
