SPECIFICATIONS

General
• Frequency coverage
• Usable channels
• Mode
• Power supply requirement
• Current drain
(at 13.8 V DC)
• Frequency stability
• Usable temp. range
• Dimensions
(projections not included)
• Weight
30
: Transmit 156–157.5 MHz
Receive 156–163 MHz
: All U.S.A., International and
Canadian channels plus 10
weather channels
: 16K0G3E, (16K0G2B
when
)
optional DSC is in use
: 13.8 V DC ± 15%
: Transmit
high power 6.0 A
low power 1.5 A
Receive
standby 350 mA
max. audio output 1.2 A
: ± 10 ppm
: –20°C to +60°C;
–4°F to +140°F
: 140(W) x 55(H) x 155(D) mm
1 5 3
5 ⁄ (W) x 2 ⁄ (H) x 6 ⁄ (D) in
2 32 32
: 1.0 kg; 2.2 lb
Transmitter
• Output power : High 25 W
• Modulation system : Variable reactance phase
modulation
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –70 dB
• Microphone impedance : 600 Ω
Receiver
• Receive system : Double conversion
superheterodyne
• Intermediate frequencies : 1st 21.8 MHz
• Sensitivity : 0.22 µV (typical)
• Squelch sensitivity : 0.18 µV
• Adjacent channel : More than 70 dB
selectivity
• Spurious reponse : More than 70 dB
rejection
• Intermodulation rejection : More than 70 dB
• Audio output power : 3.5 W
• Audio output impedance : 4 Ω
All stated specifications are subject to change without notice or
obligation
Low 1 W
2nd 455 kHz
for 12 dB SINAD
at threshold
at 10% distortion
