SPECIFICATIONS AND OPTIONS

Specifications
General
• Frequency coverage
Transmit
Receive
• Mode
• Channel spacing
• Current drain (at 13.8 V) : TX high
• Power supply requirement: 13.8 V DC ±15%
• Frequency stability
• Dimensions
(Projection not included)
• Weight
Transmitter
• Output power
• Modulation system
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions
42
:
156.025–157.425 MHz
156.050–163.275 MHz
: FM (16K0G3E)
DSC (16K0G2B)
: 25 kHz
6.0 A max.
Max. audio 1.2 A max.
: ±10 ppm
(–20°C to +60°C; –4°F to
+140°F)
: 165(W) 110(H) 109.4(D) mm
1 11 5
6 ⁄ (W) 4 ⁄ (H) 4 ⁄ (D) in
2 32 16
: 1130 g; 2 lb 8 oz
: 25 W and 1 W
: Variable reactance phase
modulation
: –70 dB
Receiver
• Receive system : Double conversion
• Sensitivity (12 dB SINAD) : Less than 0.25 µV (typical)
• Squelch sensitivity : Less than 0.3 µV
• Intermodulation rejection ratio: More than 80 dB (typical)
• Spurious response : More than 80 dB (typical)
rejection ratio
• Adjacent channel selectivity : More than 80 dB (typical)
• Audio output power : More than 3.5 W at 10% distor-
All stated specifications are subject to change without
notice or obligation.
superheterodyne
tion with a 4 Ω load
