Icom IC-756PRO Instruction Manual page 81

• Command table
Command Sub command
00 — Send frequency data
Same as Send mode data
01
command 06
02 — Read band edge frequencies
03 — Read operating frequency
04 — Read operating mode
05 — Set frequency data
00 Set LSB
01 Set USB
02 Set AM
03 Set CW
06
04 Set RTTY
05 Set FM
07 Set CW-R
08 Set RTTY-R
— Select VFO mode
B0 Exchange main and sub readouts
B1 Equalize main and sub readouts
07 C0 Turn the dualwatch OFF
C1 Turn the dualwatch ON
D0 Select main readout
D1 Select sub readout
— Select memory mode
1
08 0001 – 0101* Select memory channel
*
09 — Memory write
0A — Memory to VFO
0B — Memory clear
00 Scan stop
01 Programmed/memory scan start
02 Programmed scan start
03 ∂F scan start
12 Fine programmed scan start
Fine ∂F scan start
13
22 Memory scan start
23 Select memory scan start
0E
Set ∂F scan span
A1 – A7
(5 kHz, A2= 10 kHz, A3= 20
kHz, A4= 50 kHz, A5= 100 kHz,
A6= 500 kHz, A7= 1 MHz)
B0 Set as non-select channel
B1 Set as select channel
D0 Set scan resume OFF
D3 Set scan resume ON
00 Turn the split function OFF
0F
01 Turn the split function ON
00 10 Hz (1 Hz) tuning step
01 100 Hz tuning step
02 1 kHz tuning step
03 5 kHz tuning step
10 04 9 kHz tuning step
05 10 kHz tuning step
06 12.5 kHz tuning step
07 20 kHz tuning step
08 25 kHz tuning step
00 Attenuator OFF
06 Attenuator ON (6 dB)
11
12 Attenuator ON (12 dB)
18 Attenuator ON (18 dB)
00 Select [ANT1]
01 Select [ANT2]
12
(Add 0 or 1 to turn [RX ANT] OFF
or ON, respectively.)
00 Announce with voice synthesizer
13 01 (00=all data; 01=frequency and
02 S-meter level; 02=receive mode)
Description
1
P1=0100, P2=0101
CONTROL COMMAND
Command Sub command
01 + level data [AF] level setting (0=max. CCW
to 255=max. CW)
02 + level data [RF] level setting (0=max. CCW
to 255=11 o'clock)
03 + level data [SQL] level setting (0=11 o'clock
to 255=max. CW)
06 + level data [NR] level setting (0=min. to
255=max.)
07 + level data Inside [TWIN PBT] setting or
IF shift setting (0=max. CCW,
128=center, 255=max. CW)
08 + level data Outside [TWIN PBT] setting
(0=max. CCW, 128=center,
255=max. CW)
14 09 + level data [CW PITCH] setting (0=low pitch
to 255=high pitch)
0A + level data [RF POWER] setting (0=min. to
255=max.)
0B + level data [MIC GAIN] setting (0=min. to
255=max.)
0C + level data [KEY SPEED] setting (0=slow to
255=fast)
0D + level data [NOTCH] setting (0=low freq. to
255=high freq.)
0E + level data [COMP] setting (0=min. to
255=max.)
0F + level data [BK-IN DELAY] setting (0=short
delay to 255=long delay)
10 + level data [BAL] setting (0=max. CCW,
128=center, 255=max. CW)
01 Read squelch condition
15
02 Read S-meter level
02 Set preamp (0=OFF; 1=preamp 1;
2=preamp 2)
12 Set AGC time constant (1=FAST;
2=MID; 3=SLOW)
22 Set noise blanker (0=OFF; 1=ON)
40 Set noise reduction
(0=OFF; 1=ON)
41 Set auto notch (0=OFF; 1=ON)
42 Set repeater tone (0=OFF; 1=ON)
16
43 Set tone squelch (0=OFF; 1=ON)
44 Set speech compressor
(0=OFF; 1=ON)
45 Set monitor (0=OFF; 1=ON)
46 Set VOX function (0=OFF; 1=ON)
47 Set break-in (0=OFF; 1=ON)
48 Set manual notch (0=OFF; 1=ON)
49 Set RTTY filter notch
(0=OFF; 1=ON)
19 00 Read the transceiver ID
00 Send/read memory contents
01 Send/read band stacking register
1A
contents
02 Send/read CW keyer contents
00 Set repeater tone frequency
1B
01 Set tone squelch tone frequency
00 Set the transceiver to receive or
1C
transmit condition (0=Rx; 1=Tx)
13
