Icom IC-756PRO Instruction Manual page 74

9
SET MODE
Miscellaneous (others) set mode
This item sets the rate at which frequencies are
scanned when the microphone [UP]/[DN] switches
are pushed and held. High or low can be selected.
This item sets the data transfer rate. 300, 1200, 4800,
9600, 19200 bps and "AUTO" are available.
When "AUTO" is selected, the baud rate is automati-
cally set according to the connected controller or re-
mote controller.
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-756PRO's address is 5Ch.
When 2 or more IC-756PRO's are connected to an
optional CT-17 -
CI
ing dial to select a different address for each
IC-756PRO in the range 01h to 7Fh.
Transceive operation is possible with the IC-756PRO
connected to other Icom HF transceivers or receivers.
When "ON" is selected, changing the frequency, op-
erating mode, etc. on the IC-756PRO automatically
changes those of connected transceivers (or re-
ceivers) and vice versa.
When connecting the IC-756PRO to the IC-735 for
transceive operation, you must change the operating
frequency data length to 4 bytes.
• This item must be set to "ON" only when operating trans-
ceiver with the IC-735.
72
, rotate the tun-
V LEVEL CONVERTER
(continued)
High speed (default,
50 tuning steps/sec.)
Auto baud rate
(default)
Address of 5Ch
(default)
Transceive ON
(default)
4 bytes of frequency data
Low speed
(25 tuning steps/sec.)
19200 bps
Address of 7Fh
Transceive OFF
5 bytes of frequency data
(default)
