Dana Api Matic 2000+ Og 3000 - Swienty DANA api MATIC Instruction Manual

DANA api MATIC 2000+ AND 3000
34
35
NO. DOC. NO. REV. NO. TITLE
1
dt-004-011-2
2
dt-074-012-2
3
dt-074-016
4
5
dt-004-010A
6
dt-004-009
7
dt-074-017
8
9
10
11
12
13
dt-004-008
14
dt-004-008
15
dt-074-024
16
17
dt-074-028
18
19
20
21
22
00 Pump housing
01 Pump cover
02 Drive shaft f/Crane seal
6002-B180_10_GL_1 Glas bearing
00 Fitting
00 Accelerator shaft
02 Clutch ø15
O-ring ø37x2
O-ring BS 1.5
O-ring ø96x3
Fitting spring acid-proof 5x5x40
Fitting spring acid-proof 5x5x16
00 Module 4 ø59,2x47 12T DC 51,2 Træk
00 Module 4 ø59,2x47 12T DC 51,2 Medløb
01 Bearing housing f/Crane seal
O-ring ø30x1
03 Cover plate
Lock ring ø 15
M5x35 submerged Allen A2
M6x10 Pinol A2
00 M5x10 Buttonhead A2
Shaft seal ø16
MATERIAL
Rialan petp white 90x120x150
TECAPET white FG
A304-polished-h8 ø16x116
Con no. 505170
Stainless steel, Skal ø60x72
Stainless steel, Blank ø16 h9x65
Con no. 504500
Con no. 508037
Con no. 500212
Con no. 508096
Con no. 502705
Nav no. 701013
Pom white
Pom white
Stainless steel, 304 Skal ø65x46
Con no. 508030
Stainless steel, 304 1mm B
Nav no. 701059C
Stainless steel, 304
Stainless steel, 304
Stainless steel, 304
Con no. 508301
ENGLISH
Qty. ITEM NO.
1 210038
1 210036
1 6074016
1 505170
2 6004010A9F
1 60040099F
1 6074017
2 508037
2 500212
1 508096
1 701019D
1 701013
1 60040081F
1 60040081F
1 60740249M0
1 508030
1 6074028F
1 701059C
4 700329
1 700433
2 700223
1 508301
