INTRODUCTION DANA api MATIC 3000

DANA api MATIC 3000 is a filling machine with a gear pump. A powerful AC motor as well as a
frequency converter drive the gear pump using a planetary gear. The motor is controlled by com-
puter-based electronics, which also ensures a perfect anti-drip function. The filling machine has
20 filling programs with settings for weight, calibration factor and other filling parameters.
The machine works precisely and is easy to program for different substances. As a pump, the
machine works both ways and can be set to different speeds.
All parts that come into contact with the substance are made from food grade plastic or stainless
steel and are easy to take apart and to clean.
TECHNICAL DATA
Machine type:
Filling capacity:
Weight unit:
Precision:
Pump capacity:
Programs:
8
Power supply:
Power consumption:
9
Sound level:
Weight:
Dimensions:
Connections:
computer-controlled
gear pump
10 g - ∞ g (honey)
ml / g / oz
+/- 1g
approx. 950 kg/hour
20 + options to program
200-240VAC 50/60Hz
1500W
The sound pressure level
of the pump is less than
70 dB(A)
40 kg
62 x 42 x 18 cm
1½" BS hose connection
on both sides of the
pump (1½" or 2")
