COUNTERFLOW VALVE (110059)

a.
b.
c.
If your honey container stands lower than the filling ma-
chine and/or you take breaks during the filling process,
honey can run back into the hose and this will lead
to air in the honey when you start filling again. In that
case, we recommend purchasing this counterflow valve.
The counterflow valve is placed on the pump housing's
inlet fitting.
a) Seal
b) Flow plate
24
c) Counter plate
25

RUBBER DIAPHRAGM WITH NOZZLE

a.
b.
c.
d.
ADDITIONAL EQUIPMENT (NOT INCLUDED)
This nozzle is used for filling into containers with a small
opening.
It is absolutely necessary that all parts are put in the depic-
ted order:
a) Disc with hole
b) Rubber diaphragm with three-sided notch
c) Nozzle
d) Nut
