I N S TRUC T IO N MAN UAL
DANA api Matic 1000
Prod. 110040
Swienty A/S
|
Hørtoftvej 16, Ragebøl
|
DK-6400 Sønderborg
|
Thank you for purchasing a Swienty product. For optimal
use and to ensure a long lifetime, please read this manual
carefully. Should you have furhter questions in regards
to this product, please contact us.
Technical Data
Type of machine:
Filling range:
Measuring units:
Pump capacity:
Precision:
Power:
Powerconsumption:
Soundlevel:
Weight:
Dimensions:
Connections:
Item#:
Tariff code:
Packaging:
Accessories included:
Accessories seperate:
Tel. +45 7448 6969
|
www.swienty.com
Computer controlled gear pump
10 g - ∞ g
ml/g/oz
Approx. 200 kg/h (honey)
+/- 1%
230V/50Hz
120V/60Hz model on request
115W
Bellow 70dB(A)
Approx. 12 kg
22 x 31.5 x 18 cm
1 1/2" BS -> 1 1/2" hose
110040
8422 3000
1 pcs
Fittings elbow 1
" BS, Foot
1/2
pedal, 1,5m hose 1
",
1/2
rubber feet, dosing syringe,
cut-off-cross complete.
Various fittings, various
nozzles, different tanks and
creamers, stand for the table
or floor, funnel,
switch for stand.
for better honey
|
shop@swienty.com
Vers.8.10
Advertisement
Table of Contents
Related Manuals for Swienty DANA api Matic 1000
Summary of Contents for Swienty DANA api Matic 1000
- Page 1 I N S TRUC T IO N MAN UAL DANA api Matic 1000 Prod. 110040 Thank you for purchasing a Swienty product. For optimal use and to ensure a long lifetime, please read this manual carefully. Should you have furhter questions in regards to this product, please contact us.
-
Page 2: Table Of Contents
Page 2 Contents Read before use ....................3 Description ......................4 Packing list DANA api MATIC 1000 ..............4 Operation ......................4 Key overview ....................5 The Display ..................... 5 Anti-drip operation ..................6 Speed regulation of the motor ................. 6 Pumping ...................... -
Page 3: Read Before Use
Page 3 Read before use This instruction manual is the original Swienty A/S instruction manual for DANA api Matic 1000. The purpose of this instruction manual is to ensure correct handling, use and maintenance of the filling machine. The instruction manual is to be placed in a place where it is easily accessible to the users of the ma- chine and the people entrusted to carry out maintenance work. -
Page 4: Description
Page 4 Description DANA api MATIC 1000 is a filling machine equipped with a gear pump. A gear pump is operated by a powerful direct current motor using a planetary gear. The motor is controlled by an electronic based microprocessor which ensures a perfect drip-free function. -
Page 5: Key Overview
Shows the speed of the motor in %. Shows the pumping direction. Shows the number of fillings. Starts a new at 0 when having switched the machine off and on again. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... -
Page 6: Anti-Drip Operation
[Stop]. The pumped amount is blinking on the display. If you wish to continue pumping, press [Start] and the amount continues to count. As soon as you want to start over again, press [Stop] again, afterwards [Start]. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. -
Page 7: Preparing The Machine
Attention never connect the power before the hose connections and anti-drip is attached. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 8: Preparation For Dosing
Page 8 Set the machine to pump by pushing the Tip: Swienty recommends that the contai- button [Pump/Fill]. Pump in 1-2 sec and fill ner is above the pump head for optimum up the pump head again. use. The funnel is recommended when filling small batches. - Page 9 Can be moun- to the amount you want to dose. Use the ted first but not with very viscous liquids. button [Progr.]. See page 16. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com...
-
Page 10: Calibration
Put the container on a scale and press Place the container under the pump head. [TARE] to reset the scale. Press [Start] or press the foot switch. Place the container onto the scale. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... -
Page 11: Cleaning
Only loosen it a little so the container and the hose. the liquid does not run out. Warning: Always unplug the machine before the pump case is dismantled. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... - Page 12 Pull the pump head off by grapping onto the sides and pull towards you. Go to rinsing station. Remove the fitting below (Nut for BS fit- ting). Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com...
- Page 13 Remove the big, black O ring. Push slowly on the axis on the cover until a hole appears between the axis and the cover. Rinse here. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com...
- Page 14 Reassemble the pump head. Remember to check that the clutch fits with the machine. Otherwise you cannot place the pump head right. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com...
-
Page 15: Possible Konfigurations
Also possible - Less accurate - Needs another cutoff - for antidrip mounting see page 16 Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... -
Page 16: Antidrip Mounting
When assembling, make sure the slots in the silicone washer are between and not in line with the holes in the three hole washer. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... -
Page 17: The Menu
N can be modified within a range of 0 to 100 impulses. The number for N is normally read directely when pushing [antidrip]. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... - Page 18 [calib]. The calibration results in a calibration factor which can be seen here. Swienty recommend that you do not change it here, but instead changes it by using the button [calib]. These data are valide for one program. To switch to another program, press [stop].
-
Page 19: Log
If you press [Enter] again the chosen program is resetting and the original data will be restored. To quit this option and get back to the menu press [stop] two times. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg... -
Page 20: Functional Diagram
Page 20 Functional Diagram Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 21: Programming Default Values
Program Quantity Unit Speed% Calibration- factor 0,25 1070 0,25 1070 0,25 1070 0,25 1070 0,25 1070 0,25 1070 0,25 1070 0,25 1070 0,25 1070 1000 0,25 1070 Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 22: Maintenance
Place the new seal with the opening down softly into the opening Place the blue plastic part on top of the Push the seal in place by pressing the seal blue part down Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 23: Plug Socket Connections
+24 V DC 0 V, Ground 4-pin connector mounted on the back of the machine. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 24: Fittings And Extra Parts
110064 110068 11/2” Fitting 11/2-2” 11/2-2” 2” Fitting 11/2” Fitting 11/2-2” bent Fitting bent Fitting bent/ bent straight Fitting 110110 110130 short 110131 110140a 110100 straight 110120 Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... - Page 25 Please contact us for more information. If we do not have the part you need for you filling station, we will produce them. Hoppers requires the use of 110044 tablestand for not to tip over Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel.
-
Page 26: Exploded View
Page 26 Exploded view Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 27: Faq
DISPLAY SHOWS ”ERROR TEMPERATUR”: The engine is overloaded. The liquid is very viscous and the speed is too high. Let the machine cool off or contact Swienty. DISPLAY SHOWS ”MOTOR OVERLOAD” 1. The pump head is mechanical blocked. Open the pump head to remove. -
Page 28: Conversion Table
1 oz (Honey) = 28,35 g (Honey) If you find mistakes or have suggestions www.swientyfilling.com for improvement please contact us at: shop@swienty.com Fax: +45 74 48 80 01 Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 29: Air In The Honey
Be sure the finger screws are the sealing or if the aligning is tight and take care to do it correct. equally so the house is perfectly aligning all the way around. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com shop@swienty.com... -
Page 30: Quick Start
Pump with the pump until there is no stable surface. air inside the hose Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com... -
Page 31: Set The Filling Weight
If you wish to continue pumping, press [Start] and the amount continues to count. As soon as you want to start over again, press [Stop] again, afterwards [Start]. Swienty A/S Hørtoftvej 16, Ragebøl DK-6400 Sønderborg Tel. +45 7448 6969 www.swienty.com...
