MENU

Under the [MENU] button there are a few parameters and settings which can be used for special
circumstances. If you press that button, "PARAMETERS" blinks on the display. With the [+]/[-] but-
tons, you can jump between "LOG", "LANGUAGE", and "RESET" (see funktions diagram).

PARAMETERS

Here you can change the parameters of the filling machine's
20 programs (these parameters are saved for each program
number individually).
Press [ENTER], P(1-20) is shown. Tha last used program number blinks.
Press [+]/[-] to change the program number, then press [ENTER] to see
the parameters for the chosen program number.
Special program speed (use for containers where you would like an automatic
change of speed during filling, typically for substances that foam a lot).
.
Speed
26
START 2 START 3
27
Speed 1 - (can be set from 10% to 100% in steps of 5% (Factory setting is 100%)).
This parameter determines the motor's speed during filling if parameters START 2
and START 3 are set to 100%, otherwise this parameter only determines the start
speed until parameter START 2 or START 3 amount are reached.
This parameter can also be set directly by using the [SPEED] button.
Start 2 - Determines when the motor's speed should be changed
to parameter SPEED 2. START 2 can be set from 1% to 100% of the
entire filing amount in steps of 1% (Factory setting is 100%).
Speed 2 - Determines the motor's speed after amount START 2
has been reached.
Start 3 - Determines when the motor's speed should be
changed to parameter SPEED 3. Only use for containers where
you would like an automatic change of speed during filling.
START 3 can be set from 1% to 100% of the total filling amount
in steps of 1% (Factory setting is 100%).
Speed 3 - Determines the motor's speed after amount START 3
has been reached.
