REVELTRONICS UTCOMP-3 User & Assembly Manual page 9

Features & Requirements:
To activate following features of the UTCOMP some signals have to be connected. What kind of signal for each function is required shows the table
below. You should connect only what are you interested with. You do not have to connect all signals.
Group
•
date and time
•
battery voltage (voltmeter) + alerts
•
travel time
•
I service & inspection with reminder (x2 for motohours + x2 for
date)
•
customizable user screen(s)
•
splash screen (text or bitmap)
•
temperatures (inside, outside, oil, engine, user-1, user-2)
•
II alerts for temperatures (customizable, e.g. black ice alert,
engine/oil temperature warnings etc.)
•
vehicle speed (real-time velocity, average, maximum)
•
distance travelled
•
mileage
•
acceleration (and deceleration) measurement with user defined
III
ranges
•
trip meter for off-road (normal/reverse/freeze modes)
•
service & inspections with reminder (x4 for milage)
•
speed limit alert
•
current fuel consumption for PB/ON
•
average fuel consumption for PB/ON
IV
•
travel cost
•
trip summary
•
V full support for vehicles with LPG system
Example features Requirements
power supply
temperature sensor
(analog NTC or digital DS18B20)
vehicle speed signal (VSS)
(ref. to section 2.4.6)
fuel consumption signal
(ref. to section 2.4.5)
+ req. from group III
signal from LPG electrovalve or injector
- 9 -
No of wires
3
3 - for each digital sensor
1 - for each analog sensor
1
1 (2)
1
