3.6.13. Digital output control (digOutUser)

In UTCOMP-PRO there is possibility to control digital output bases on selected signal source. As signal source you can choose any temperature or
vehicle speed. Digital output state may be switched between two states: +5V and Hi-Z (disconnected). Recommended load is <50mA (maximum
100mA), so in most cases it will be used to control monostable relay switch with 5V coil.
Tutorial is available on forum:

3.6.14. Support for additional sensors: pressure, temperature, AFR, EGT etc.

There is possibility to connect additional sensors, such as:
•
boost pressure (turbo)
•
oil pressure
•
afr or lambda
•
EGT (exhaust gas temperature)
•
oil temperature
•
coolant temperature
•
etc.
There is possibility to set custom alerts for all these measurements. In PRO version there is available also data-logger.
Please check tutorial on forum:
http://www.reveltronics.com/forum/viewtopic.php?f=28&t=172
http://www.reveltronics.com/forum/viewtopic.php?f=28&t=127
