1. Technical data and requirements

Universal Trip Computer (UTCOMP) developed and manufactured by REVELTRONICS is an on-board computer designed for wide range of
vehicles. It takes information from main sensors then process data and sends to LCD or OLED screen with user friendly interface.
Technical parameters
•
power supply from 12V or 24V installation (safe range: +8... +32V DC),
•
power consumption in standby mode: 4-12mA@12V (typ. 8mA@12V),
•
power consumption in idle mode: 40-500mA@12V (depends on used display, brightness, connected sensors etc.),
•
operating temperature: -40C...+85C,
•
LCD operating temperature: -20C...+70C (recommended +10C...+40C),
•
OLED operating temperature: -40C...+85C,
•
digital temperature sensors measurement range: -55C...+125C, accuracy 0,5C, resolution 0,1C,
•
vehicle speed accuracy: +/- 1km/h or mph (calibration possible),
•
acceleration measurement accuracy: +/- 0,1s (for VSS constant < 0.2 [m/imp]),
•
fuel consumption accuracy: 1% for petrol engines, 2% for petrol + gas engines, 1-3% for diesel engines (calibration possible),
•
sampling time of real-time fuel consumption: average from 1s, 2s or 3s,
•
sampling frequency from analog sensors (measurements and alerts): 50Hz,
•
analog sensors measurement accuracy: +/- 0,05V for UTCOMP-3 and +/- 0,02V for UTCOMP-PRO [V],
•
voltmeter accuracy: +/- 2% range +/- 0,05V (calibration possible),
•
supported units: km, km/h, l/100km, l/h, km/l, mil, mph, mpg, Celsius, Farentheit, bar, psi, volt,
•
communication with PC and Android devices via USB 2.0 (HID).
