O. Thompson Microflite Ultra 2000 Installation & Adjustment Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

flite
TM
Micro
Ultra 2000
by O. Thompson
Installation & Adjustment Manual
for the
Magnetek DSD 412 DC Drive
Magnetek HPV 900 AC Vector Drive
Amicon Regulator
Revision AA 2.2
Printed 03 - 15 - 03
Copyright © 2003 O. Thompson Co.
This document and its contents are the property of O. Thompson Co. and are not to be
copied or used directly or indirectly without the written consent of O. Thompson Company.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Microflite Ultra 2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for O. Thompson Microflite Ultra 2000

  • Page 1 Printed 03 - 15 - 03 Copyright © 2003 O. Thompson Co. This document and its contents are the property of O. Thompson Co. and are not to be copied or used directly or indirectly without the written consent of O. Thompson Company.
  • Page 2 (Backside of cover page)

  • Page 3: Table Of Contents

    Table of Contents Section 1 General Information................... 1-1 Technical Support.................. 1-1 Training ....................1-1 Testing..................... 1-1 Code Compliance ................... 1-1 Documentation ..................1-1 Warranty....................1-1 Section 2 Personnel Safety....................2-1 Section 3 Equipment Safety....................3-1 Section 4 Installation Considerations................4-1 Piping and Wiring...................
  • Page 4 Table of Contents Section 7a High Speed Adjustment - Magnetek DSD 412..........7a-1 7a.1 Final System Checks to High Speed Adjustment ......7a-1 7a.2 Initial Set Up ..................7a-2 7.2.1 One Floor Up & Down ............. 7a-3 7.2.2 Two Floor Up & Down .............. 7a-3 7.2.3 Multi-Floor Up &...
  • Page 5 Table of Contents Section 6 Start Up Procedures - Amicon Regulator (cont.) 6c.8 Encoder ………………………………………………………………………6c-12 6c.8.1 Encoder - Preparation For Learn Trip ......... 6c-12 6c.8.2 Performing the Learn Trip............. 6c-12 Section 7c High Speed Adjustment - Amicon Regulator ..........7c-1 7c.1 Final System Checks to High Speed Adjustment ......
  • Page 6 Table of Contents Section 10 Testing....................... 10-1 10.1 Terminal Limit Test - Top ..............10-1 10.2 Terminal Limit Test - Bottom............... 10-1 10.3 Counterweight Buffer Test ..............10-2 10.4 Car Buffer Test ..................10-2 10.5 Car Governor Overspeed Test ............10-3 10.6 Counterweight Governor Overspeed Test ........
  • Page 7 13.1.4 Car Top Encoder ..............13-7 12.1.4.1 Encoder Diagnostics ..........13-8 13.1.5 Digital Pattern Generation with ACurve Correction@ ... 13-9 13.1.6 O. Thompson Pretorquing............13-9 13.2 Inspection Sequence of Operations ..........13-10 13.2.1 Inspection Operation - Magnetek DSD 412......13-10 13.2.2 Inspection Operation - Amicon Generator Regulator ..
  • Page 8 Table of Contents THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 9: General Information

    (718) 417-9075 fax Warranty O. Thompson warranties its control systems for a period of one year from the date that the elevator has been placed in operation. This warranty period cannot exceed 16 months from the date of controller shipment. If any part of the control system fails due to a defect in material or workmanship O.
  • Page 10 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 1 - 2...

  • Page 11: Personnel Safety

    Microflite Ultra 2000 Section 2 Personnel Safety There are certain fundamental warnings that must be kept in mind at all times. If these fundamental warnings are not kept in mind, personal injury and/or death may occur. These Warnings include, but are not limited to: •...
  • Page 12 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 2 - 2...

  • Page 13: Equipment Safety

    O. Thompson Engineering. • Circuit boards that are determined to be defective should be sent to O. Thompson for repair and subsequent testing. Field repairs may leave the board with undetected problems that may affect other parts of the control.
  • Page 14 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 3 - 2...

  • Page 15: Installation Considerations

    Once the problem relay is pinpointed, add arc suppression around the coil. Note: Standard arc suppressors (resistor/capacitor networks) are used on AC relays, and diode/resistor combinations work well for DC relays. Consult O. Thompson engineering for proper component sizing. Piping and Wiring Proper routing of the signal and power wires for the car and dispatcher is essential to a trouble free installation with any microprocessor based equipment.

  • Page 16: How To Avoid Electrical Noise Problems

    Microflite Ultra 2000 The low level conductor, in the case of Ultra 2000, may be a 24 volt input that really only needs to see 12 volts to turn on. If the voltage induced from the high power conductor is large enough to induce a 12 volt spike, the input can falsely turn on.

  • Page 17: Tach Generator Wiring

    Microflite Ultra 2000 Continuous wire from the isolation transformer frame to the single ground stud (SCR jobs only) Continuous wire from the DC choke frame to the single ground stud (SCR drive only) Continuous wire from the line filter frame to the single point ground stud (AC Vector jobs only) Jumper the “N”...

  • Page 18: Car Top Encoder Wiring

    Microflite Ultra 2000 4.1.8 Car Top Encoder Wiring The car top encoder communicates to the car MPU (Micro Processor Unit) via a neuron network at an extremely high frequency. The devices at both ends of the network are extremely intelligent in that they check for errors in the message every time the information is sent.

  • Page 19: Wiring Connections For Properly Grounded System

    Microflite Ultra 2000 on concrete beam pockets, and the earth connection is inadequate. A sprinkler system water pipe is not adequate because the sprinkler system is, in most cases, isolated from a free flowing earth water source. If either of the two methods above are chosen for ground, and a true electrical ground is later introduced to the system, a difference in potential can occur between the assumed ground and the actual earth ground.

  • Page 20: Proper Encoder Mounting Procedures

    Microflite Ultra 2000 Sometimes referred to as: A is pronounced A not B is pronounced B not Three twisted pairs, each with an overall shield is used to wire the encoder. A and A are wired with a single twisted pair with an overall shield wire.

  • Page 21: Tach Generator Mounting

    Microflite Ultra 2000 WE RECOMMEND that the encoder for gearless applications be driven from the motor shaft. This will give the best speed feedback signal, and reduce the possibility of vibration in the signal leading to vibration in the ride of the car.
  • Page 22 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 4 - 8...

  • Page 23: Hoistway Equipment Installation

    Section 5 Hoistway Equipment Installation Tape Installation Microflite Ultra 2000 uses a perforated steel tape in the hoistway. The tape and car top encoder provide position, speed, and direction feedback to the control system. Prior to the installation of the perforated tape, insure the location you choose will have adequate clearance from shaft way beams, walls, counterweights, cabs, and terminal limit devices.
  • Page 24 Microflite Ultra 2000 Revision: AA 2.2 Printed 03 - 15 - 03 5 - 2...

  • Page 25: Stick Alignment

    Microflite Ultra 2000 Stick Alignment After the tape has been installed, adjust the stick front to back slightly so it does not ride hard on one side of the unistrut bracket during any part of the travel through the hoistway. In high rise buildings, the rails may vary in and out substantially.
  • Page 26 Microflite Ultra 2000 Revision: AA 2.2 Printed 03 - 15 - 03 5 - 4...

  • Page 27: Section 6A

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Section 6a Start Up Procedures - Magnetek DSD 412 DC Drive 6a.1 Controller Inspection WARNING: Read Section 2 and 3 on Personal and Equipment Safety completely before starting this procedure. Read Section 4 on Piping & Wiring completely before starting this procedure.

  • Page 28: 6A.2 Power Up The Controller

    Magnetek Technical Manual CS 0274 - enclosed with the project shipment. The drive has been modified to meet O. Thompson’s specifications. The Magnetek Technical Manual CS 0274 that is shipped with the elevator control panel(s) can be used, with the exceptions listed below.

  • Page 29: 6A.3.1 Hardware Modifications

    Once the controller is powered up, the drive needs to be programmed to interface correctly with the equipment on the job site. O. Thompson has pre-programmed the drive based on the information provided in the survey, but it is important to confirm it before attempting to run the car.

  • Page 30: 6A.3.4 Self Tune

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Access parameter #11. Enter the motor nameplate RPM. Press enter to save. Access parameter #16. This parameter is the gearless ratio of the encoder. If the encoder is mounted to the motor shaft, set this value to 1.000. If the encoder is driven by a wheel...
  • Page 31 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive The Magnetek DSD 412 digital DC drive has a self tuning feature that dynamically calculates the armature resistance and inductance. This includes the choke and filter used in series with the armature.

  • Page 32: 6A.3.5 Attempt To Run The Car

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Access parameter 4. Change the value to that recorded from parameter 613. Access parameter 6. Change the value to that recorded from parameter 614. Access parameter 51. Change the value to that recorded from parameter 615.

  • Page 33: 6A.4 Brake Adjustment

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Place the car somewhere near the center of the hoistway. On the Limit board, LED D9 should be turned off. It will come on when the car is on Automatic operation with the doors closed.
  • Page 34 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Turn the V/I-3 pot 10 turns counterclockwise, and then 2 turns clockwise. Run the car on inspection and slowly turn the V/I-3 pot clockwise until the car runs through the brake.

  • Page 35: 6A.5 Mpu Power

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Using the up and down inspections switch on the relay board, adjust pot PXT so that the MA contactor drops approximately 1 to 2 seconds after releasing the switch and the brake sets.

  • Page 36: 6A.6.2 Performing The Learn Trip

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive 6a.6.2 Performing the Learn Trip Move the car on inspection into the bottom floor door zone. The DZ relay on the controller will pick up. On the main parameter screen, move the cursor to “Learn Trip, Floor Names, Pre- Torque”.

  • Page 37: Section 7A

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Section 7a High Speed Adjustment - Magnetek DSD 412 7a.1 Final System Checks Prior to High Speed Adjusting Verify that all safety circuits are operative and that each device in the string will prevent the car from starting or continuing to run.
  • Page 38 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive If the controller is not set up for seismic operation, go to step 5. On the monitor, observe the encoder position on the diagnostic screen. Write this value down. Access the car parameters menu. Open the “VIP, MEDICAL, EARTHQUAKE PARAMETERS”...

  • Page 39: One Floor Up & Down

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Install a TEMPORARY jumper from J3-1 to J7-1. Install a TEMPORARY jumper from J3-2 to J7-2. 7a.2.1 One Floor Up & Down Make a one floor run up and a one floor run down in the middle of the hoistway.

  • Page 40: 7A.4 Ride Quality And Performance Adjustments

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Run the car to a floor near the bottom of the hoistway. Place full load in the car. Disable the car doors. On the drive, access parameter 610 (Motor Armature Voltage).
  • Page 41 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive 7a.4.1 Drive Tracking Drive tracking is the control system’s most critical adjustment to get a high quality ride and superior performance. If the drive does not track the speed command well the ride quality will not be acceptable.

  • Page 42: 7A.5 Drive Reference Information

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive armature voltage is high, reduce parameter 11 until nameplate armature voltage is obtained while running in the up direction. Remove weights so balanced load is in the car. Access drive parameter 611, “Motor Armature Current.”...
  • Page 43 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Press ENT to clear all the errors in the list. Use arrow keys to scroll past the “ALL” entry to view the error list. The first error after “ALL”, is the latest error.
  • Page 44 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Fault Number Fault Name Corrective Action Loss of 115 VAC power to drive. Check fuses and AC input voltage at P.L. TB3-1 to TB3-7. - - - Open Amptrap fuse or fuses. Check fuses and AC connections at TB3.
  • Page 45 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Fault Number Fault Name Corrective Action Check power supply board, main control card, software and ribbon F112 Bad PCDU Pointer cables. Check power supply board, main control card, software and ribbon...
  • Page 46 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Fault Number Fault Name Corrective Action Excessive CEMF. Check motor armature voltage and current while car is F408 PCU CEMF Fault lifting full load and adjust motor field to obtain correct values.

  • Page 47: 7A.5.2 Drive Parameters

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Fault Number Fault Name Corrective Action Measured value of Armature Interface board resistor R5 not correct. Indicates incompatible hardware, or connector J14 missing or F921 Bridge Rating Fault unplugged. Also could be caused by bad Armature Interface PCB or Main Control card.
  • Page 48 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Parameter Name Units Value Description This parameter sets the minimum voltage level at which Percentage of Voltage Sense the tach loss and tach reverse connection faults will be Arm. Voltage detected.
  • Page 49 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Parameter Name Units Value Description This parameter controls the point at which the field Percentage of See Section current will be increased from the weakened value to the Field Strengthening Speed Rated Speed 7a.3...
  • Page 50 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive Parameter Name Units Value Description This parameter allows the magnitude of the analog output at TB1-44 to be modified. A value of 0.7 sets the Test Point 1 Multiplier None output to be equal to the + 7 volt speed reference signal given the drive.

  • Page 51: 7A.5.3 Display Parameters

    Microflite Ultra 2000 - Magnetek DSD 412 DC Drive 7a.5.3 Display Parameters The following parameters are used to display data in the drive. They can be useful for troubleshooting the drive to determine what signals the drive is seeing and the magnitude of the signals.
  • Page 52 Microflite Ultra 2000 - Magnetek DSD 412 DC Drive THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 7a - 16...

  • Page 53: Section 6B

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Section 6b Start Up Procedure - Magnetek HPV 900 AC Vector Drive 6b.1 Controller Inspection WARNING: Read Section 2 and 3 on Personal and Equipment Safety completely before starting this procedure.

  • Page 54: 6B.2 Power Up The Controller

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Verify the following connections between the 15 volt power of the motor drive, the MPU board, and the relay board: On Motor Drive On MPU Board Relay Board + 15 volts...

  • Page 55: 6B.3.1 Software Modifications

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive 6b.3.1 Software Modifications The following software modifications to the standard MagneTek HPV 900 AC Vector drive are unique to the O. Thompson Microflite Ultra 2000 control. The major change in the software is the normal speed reference and speed feedback input and output signals.
  • Page 56 Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Skip down to the SPD COMMAND MULT parameter. This parameter sets the magnitude of analog speed reference used on the drive. The drive is set up to accept a 10 volt command, so a value of 1.42 must be entered here so the car will do contract speed when the speed command is at 7.0 volts.

  • Page 57: 6B.3.4 Moving Car On Inspection

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive The final setting can be calculated by the drive by performing an adaptive tune. NOTE: This value must be less than 900 RPM on 8 pole motors, 1200 RPM on 6 pole motors, and 1800 RPM on 4 pole motors or a drive set up fault will occur.

  • Page 58: 6B.3.5 Drive Faults

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive On the Limit board, press S3 and then press and release S1. Release S3. LED D25 will be blinking rapidly (on 1/8 second, off 1/8 second). Also, the D10, D11, and D17 LED’s will be lit.
  • Page 59 Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Turn the main line power ON. Run the car on inspection and adjust the V/I-1 pot until brake pick voltage required for the job is obtained. Turn the main line power OFF. Remove the jumper from the brake driver.

  • Page 60: 6B.5 Mpu Power

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Turn the ACC1 pot fully clockwise. This will allow for a rapid response of the brake regulator from a lower voltage level to a higher voltage level. Turn the DEC1 pot fully clockwise. This will allow for a rapid response of the brake regulator from a higher voltage level to a lower voltage level.
  • Page 61 Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Move the car into the bottom floor door zone. On the main parameter screen, move the cursor to “Learn Trip, Floor Names, Pre- Torque”. Press the 0 key. Switch the INS switch on the controller up. The I, IX, & IY relays should pick.
  • Page 62 Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03- 15 - 03 6b - 10...

  • Page 63: Section 7B

    Microflite Ultra 2000 -Magnetek HPV 900 AC Vector Drive Section 7b High Speed Adjustment - Magnetek HPV 900 7b.1 Final System Checks Prior to High Speed Adjusting Verify that all safety circuits are operative and that each device in the string will prevent the car from starting or continuing to run.

  • Page 64: 7B.2 Initial Set

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Verify that the terminal slowdown limit switches are set according to the tables in Section 8. On the car top, verify that all encoder and pretorque cables are securely plugged in inside the encoder electronics box.

  • Page 65: 7B.2.1 One Floor Up & Down

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive car’s rated capacity. If the car is too light, weight needs to be removed from the counterweight to get it balanced between 40 and 50% of the car’s rated capacity.

  • Page 66: 7B.4 Hpv 900 Adaptive Tune

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Run the car from the top floor to the bottom floor. Observe the meter. The voltage should be -7.00 volts. If not, adjust MPU pot R28 to obtain an equal voltage, but of opposite polarity, while the car is running up and down.

  • Page 67: 7B.5 Ride Quality Adjustments

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Verify that the FLUX REFERENCE (found under Display Menu – Power Data D2) is 100%. If not, reduce the car speed until it is. With the car running from top to bottom and back, observe EST NO LOAD CURR (found under Display Menu –...

  • Page 68: 7B.6 Drive Reference Information

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive – Drive A1). Ride the car up and down, staying away from the terminal floors. Observe the ride. There should be no vibration at any point. If vibration is present, try adjusting the RESPONSE parameter under ADJUST A0, DRIVE A1 to a slightly lower value.

  • Page 69: 7B.6.2 Drive Parameters

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive 7b.6.2 Drive Parameters The following is a list of the parameters in the drive. Also included are an explanation of the parameter and how it should be set. Refer to Section 6b.3.3 for the initial programming of the drive.
  • Page 70 Used to multiply the speed command. Drive is configured for a Spd Command Mult None 1.43 standard +10 volt reference, Microflite Ultra 2000 uses + 7 volts, so speed command needs to be multiplied. This parameter subtracts a voltage from the pretorque signal. Not Pre Torque Bias Volts 0.00...
  • Page 71 Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Parameter Units Value Description When the drive is set for automatic resets, this parameter sets the Fault Reset/Hour Faults maximum amount of times in a one hour period the drive will reset a fault.
  • Page 72 Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Adjust A0 Motor A5 Parameter Units Value Description This parameter programs specific values for various motor Motor ID None Default Motor parameters. The Default Motor selection requires various values to be entered for these parameters.
  • Page 73 This parameter allows the drive to hold the car stopped through the Brake Hold Src Logic Internal Brake Pick output. It must be set to “Internal” for Microflite Ultra 2000 controllers. This parameter allows the drive to use torque ramp down based on Ramped Stop Sel...
  • Page 74 Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Configure C0 Logic Inputs C2 Parameter Units Value Description Logic In 1 TB1-1 Logic Drive Enable Sets this input to turn on drive enable. Logic In 2 TB1-2 Logic Sets this input enable the run command.
  • Page 75 Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Display D0 Elevator Data D1 Parameter Units Description Feet per Speed Command This parameter displays the command before the speed reference generator. Minute Feet per Speed Reference This parameter displays the speed reference after the speed reference generator.

  • Page 76: 7B.6.3 Drive Faults

    Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Parameter Units Description Percentage of Flux Current This parameter displays the measured flux producing current. Rated Current Percentage of Torque Current This parameter displays the measured torque producing current. Rated Current...
  • Page 77 Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive Fault Description Corrective Action Check encoder connections. If drive has been running, replace encoder. If The drive is in a run condition Encoder Fault this fault occurs on initial start up of drive, swap A and A- connections to and encoder is not operating.
  • Page 78 Microflite Ultra 2000 - Magnetek HPV 900 AC Vector Drive THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 7b - 16...

  • Page 79: Section 6C

    Microflite Ultra 2000 - Amicon Regulator Section 6c Start Up Procedures Amicon Regulator 6c.1 Controller Inspection WARNING: Read Section 2 and 3 on Personal and Equipment Safety completely before starting this procedure. Read Section 4 on Installation Considerations - completely before starting this procedure.

  • Page 80: 6C.2 Power Up The Controller

    Microflite Ultra 2000 - Amicon Regulator Verify the following connections between the 15 volt power of the motor drive, the MPU board, and the relay board: On Motor Drive On MPU Board Relay Board + 15 volts J9-2 J20-1 - 15 volts...

  • Page 81: 6C.3 Motor Generator Start

    Microflite Ultra 2000 - Amicon Regulator 6c.3 Motor Generator Start Up After applying power to the controller, verify that the reverse phase monitor is on. The reverse phase monitor is O.K. if the red light is on. If the red light is not on, shut the main line power off, and swap 2 of the 3 phase connections to the controller.
  • Page 82 Microflite Ultra 2000 - Amicon Regulator Revision: AA 2.2 Printed 03 - 15 - 03 6c - 4...

  • Page 83: 6C.4 Initial Hoist Motor Field Adjustment

    Microflite Ultra 2000 - Amicon Regulator 6c.4 Initial Hoist Motor Field Adjustment Note: The following settings will need to be touched up during the high speed adjustment. We will refer to Standing Field as the field current when the car is sitting at the floor with the doors fully open, or when it is parked.
  • Page 84 Microflite Ultra 2000 - Amicon Regulator Revision: AA 2.2 Printed 03 - 15 - 03 6c - 6...
  • Page 85 Microflite Ultra 2000 - Amicon Regulator Note: The field weakening point is set via a FFB parameter on Page 1 of the parameters on the Ultra 2000 MPU. This is typically set from 70% to 90% of contract speed. Turn the main line power OFF. Remove one end of the jumper from the J1-2 end.
  • Page 86 Microflite Ultra 2000 - Amicon Regulator Note: The S3 switch must be on the RUN position when the car is placed on automatic. If the switch is on TEST, tach feedback is ignored and the regulator will output constant voltage. Speed will vary, depending on the load.
  • Page 87 Microflite Ultra 2000 - Amicon Regulator Note 2: If the car being adjusted is a high speed car - Set reference +.35 volts and adjust for 5% of contract speed. Move the red meter lead to the XY6 test point on the regulator. While the car runs at 1/10 of contract speed, adjust the ACAL pot until you see .75 volts on the meter.

  • Page 88: 6C.6 Brake Adjustment

    Microflite Ultra 2000 - Amicon Regulator 6c.6 Brake Adjustment Note: The brake assembly and all pins should be cleaned thoroughly and all spring tensions set properly to hold 125% of car capacity prior to adjusting the brake driver. Brake shoes should be checked to insure at least 95% surface contact. If spring tensions are changed after this adjustment, the brake driver will need to be completely re-adjusted.
  • Page 89 Microflite Ultra 2000 - Amicon Regulator Using the up and down inspections switch on the relay board, adjust pot PXT so that the MA contactor drops approximately 1 to 2 seconds after releasing the switch and the brake sets. Too much time will cause the car to take too long to re-level on automatic operation.

  • Page 90: 6C.7 Mpu Power

    Microflite Ultra 2000 - Amicon Regulator 6c.7 MPU Power Up Power Up the MPU. While the MPU is powering up, press the Number 1 button. (Refer to Section 8 of this manual.) Go through all parameter screens to set all parameters applicable to the car. Only enable and set parameters that are applicable to the job.
  • Page 91 Microflite Ultra 2000 - Amicon Regulator The screen will say “LEARN TRIP (IF YOU ARE SURE PRESS ENTER FOR LEARN TRIP !!!!)”. Press 0. The car will start the learn trip and move up the hoistway at about 24 fpm. It should stop as soon as it reaches the top floor door zone magnet.
  • Page 92 Microflite Ultra 2000 - Amicon Regulator THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 6c - 14...

  • Page 93: High Speed Adjustment - Amicon Regulator

    Microflite Ultra 2000 - Amicon Regulator Section 7c High Speed Adjustment - Amicon Regulator 7c.1 Final System Checks Prior to High Speed Adjustment Verify that all safety circuits are operative and that each device in the string will prevent the car from starting or continuing to run.

  • Page 94: 7C.2 Initial Set

    Microflite Ultra 2000 - Amicon Regulator 7c.2 Initial Set Up Place the car in the center of the hoistway. Mark the cables with chalk when the car crosshead and the counterweight crosshead are exactly adjacent to each other. If the controller is not set up for seismic operation, go to step 5.

  • Page 95: 7C.2.1 One Floor Up & Down

    Microflite Ultra 2000 - Amicon Regulator Unplug Limit board connectors J3 and J7 from the board. Install a TEMPORARY jumper from J3-1 to J7-1. Install a TEMPORARY jumper from J3-2 to J7-2. 7c.2.1 One Floor Up & Down Make a one floor run up and a one floor run down in the middle of the hoistway.
  • Page 96 If the modifications have not been made, contact O. Thompson Engineering prior to making any board revisions. On the Power Board (R2 & R3 resistors are located on the top left corner of the board) For Field Current up to 5 amps R2 &...
  • Page 97 Microflite Ultra 2000 - Amicon Regulator NOTE: If the car has a geared machine, field weakening may not be required on this particular motor. Increase pot V/I-2 until motor nameplate armature voltage is obtained while the car is running up at contract speed with full load. If the setting of pot V/I-2 is equal to that of V/I-1, disable field weakening by accessing the Motion Parameters and setting the FFB speed to value above contract speed in both Accel and Decel.

  • Page 98: 7C.4 Ride Quality Adjustments

    Microflite Ultra 2000 - Amicon Regulator If vibration occurs while the car is accelerating or decelerating, turn the PN pot counterclockwise in small increments until the vibration is decreased. If this does not remedy the vibration, turn the PN pot back to its original setting and turn the ACMP pot clockwise or counterclockwise to reduce the vibration felt in the car.

  • Page 99: 7C.5 Amicon Regulator Reference Information

    Microflite Ultra 2000 - Amicon Regulator To adjust the regulator for optimum ride quality and performance the following step should be taken. Place an oscilloscope on drive terminal XY8. The common lead should be placed on XY3. While running the car, observe the scope. If the generator field current is unstable, turn the ACMP pot clockwise to improve regulator stability and reduce vibration.

  • Page 100: 7C5.2 Potentiometer Functions

    Microflite Ultra 2000 - Amicon Regulator 7c5.2 Potentiometer Functions PN (Speed Loop Gain) - Sets the gain of the speed feedback loop. The gain should be adjusted for good regulation and stability of the system. NMAX (Contract Speed) - Fine adjustment for setting contract speed with the maximum speed reference input to the control.
  • Page 101 Microflite Ultra 2000 - Amicon Regulator XY5 (TACH) This test point monitors tach feedback. The polarity on this test point should be positive when the car is traveling in the up direction. XY6 (ARM FB) This test point monitors armature voltage feedback. The polarity on this test point should be negative when the car is traveling in the up direction.
  • Page 102 Microflite Ultra 2000 - Amicon Regulator THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 7c - 10...

  • Page 103: Limit Board And Etsl System

    Limit Board & ETSL System Limit Board Version 2 Software O. Thompson has released an enhanced version of Limit board software for use on the Microflite Ultra 2000 Control System. This new software utilizes a rotary encoder to monitor the position of the car in the hoistway.

  • Page 104: Limit Switch Distances

    Microflite Ultra 2000 Limit Switch Distances After the board is installed and wired, it may be desirable to relocate the existing limit switches in the hoistway. Leaving the switches in their present position may cause the Limit board to limit the car’s maximum speed if power is removed or if the board is reset at a position away from a...
  • Page 105 Microflite Ultra 2000 Table 2 - Acceleration Rate m3.0 but [ 3.5 ft/s Car Speed 1SU / 1SD 2SU / 2SD 3SU / 3SD 4SU / 4SD 3’ 1’ 6” 5’ 6” 3’ 8’ 6” 3’ 12’ 7’ 3’ 16’ 6”...

  • Page 106: Limit Board Set Up

    Microflite Ultra 2000 Table 4 - Acceleration Rate m 4.0 ft/s Car Speed 1SU / 1SD 2SU / 2SD 3SU / 3SD 4SU / 4SD 2’ 6” 1’ 6” 4’ 6” 2’ 7’ 3’ 10’ 6” 7’ 3’ 14’ 9’...

  • Page 107: Learn Procedure Faults

    Microflite Ultra 2000 The Limit board requires a learn procedure for calibration. With the car on inspection, place it somewhere near the center of the hoistway, away from all terminal floor slowdown switches. Verify that all of the limit switches are turned on by checking the LED’s on the board. Use the chart below to determine which LED corresponds to which limit.

  • Page 108: Limit Board Testing

    Microflite Ultra 2000 Limit Board Testing After the learn procedure has been performed, run the car on automatic operation. The car should run at contract speed and decelerate normally. Run the car to the top and bottom floor and confirm that LED D25 on the board stays on continuously. If it starts to flash at any time, the board has detected the car was approaching a terminal floor too fast, and has brought the car into the floor.

  • Page 109: Etsl Set Up Procedures

    8.8.1 ETSL Wiring The O. Thompson ETSL board will accept 18 -24 volts AC or DC. Power must be wired to terminal J3-8 and J3-9. The memory reed switches are wired to terminal J1. Switch 1 is wired to J1-1 and J1-2. Switch 2 is wired to J1-3 and J1-4.

  • Page 110: Bracket Mounting And Set Up

    Microflite Ultra 2000 When power is applied to the board the green LED should flash slowly. This indicates that the board is functioning correctly. There are two red LED’s on the board, one indicating that the board has tripped and one indicating a malfunction.
  • Page 111 Microflite Ultra 2000 Revision AA2.2 Printed 03 - 15 - 03 8- 9...
  • Page 112 If the deceleration rate is greater than 3.5 ft/s , then the brackets may need to be relocated closer to the terminal floors. Contact O. Thompson Technical Support for assistance. Assuming the system does not trip, move the magnets on the top terminal bracket closer together, approximately half of the correct distance.
  • Page 113 Microflite Ultra 2000 safety circuit and stopping the car. After the board trips, it should automatically reset after 15 seconds. Return the magnets to their correct position and repeat this procedure for the bottom bracket. Revision AA2.2 Printed 03 - 15 - 03...
  • Page 114 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision AA2.2 Printed 03 - 15 - 03 8- 12...

  • Page 115: K-Tech Load Weigh System

    Microflite Ultra 2000 Section 9 K-Tech Load Weigh System (Pretorque only) Controllers with pretorque use the K-Tech Load Weigh System. Proper installation and adjustment of this device is essential to the operation of the control system. Failure to follow the procedures outlined in this section can result in poor ride quality and improper operation of the control system.

  • Page 116: Electronics Box Mounting

    Microflite Ultra 2000 File, sand or lightly grind the area where the sensor will be located to remove any paint. Lay the sensor on the cleaned area of the crosshead about ½” away from the edge. Shine a light behind the sensor to ensure that it lays flat on the crosshead. If light can be seen under the sensor, file the area until the sensor lies perfectly flat.

  • Page 117: Sensor Calibration

    The output of the amplifier board, “SET POINTCONNECT” terminals T4 & T5 will be connected to the O. Thompson Encoder power supply board terminals J3-1 and J3-2. Route the cable through the knockout in the K-Tech electronics box to the Encoder.

  • Page 118: Amplifier Board Calibration

    Microflite Ultra 2000 opposite polarity. For example, if the meter read +10 mV with you off the car, step back on the car and adjust the meter for –10 mV. Step off the car. The meter should read zero. If not, adjust the “SENSOR ADJUST” pot until it does.
  • Page 119 Microflite Ultra 2000 Connect the positive (red) lead of a Digital Volt Meter (DVM) to test point T4 and the negative lead (black) to test point T5. Set the meter to the millivolt scale. While standing on the car, turn the “ZERO ADJUST” pot until the meter reads one hundred millivolts, plus or minus five millivolts.

  • Page 120: K-Tech Lw4200

    Microflite Ultra 2000 K-Tech LW4200 Preparation 9.3.1 Before beginning the installation of the unit, the car should be adjusted and running at contract speed. The cab should be complete, with all walls, ceiling panels, and flooring installed. If not, do not install the unit until the cab is complete! 9.1.2...

  • Page 121: Electronics Box Mounting

    (IPX) and AC RET (IP). Ground the electronics box to controller ground. The output of the K-Tech unit will be connected to the O. Thompson Encoder power supply board terminals J3-1 and J3-2. A twisted - shielded cable must be run from terminals LW+ and Revision: AA 2.2...

  • Page 122: Calibration

    Connect the terminal “Input 1" (J4) on the K-Tech electronics board to terminal “CAL” on the O. Thompson Car Station board. Refer to the O. Thompson wiring diagrams for the exact terminal location, as it will vary on job to job basis. This signal will be activated periodically by the Car Station board, energizing the relay on the K-Tech board to re-calibrate the crosshead sensor.

  • Page 123: Controller Pretorque Set Up Procedure

    Microflite Ultra 2000 Switch “S3" to the “+” position. One or more of the red and green LED’s on the left hand edge of the board will be illuminated. If the “-” LED is not on, Slowly turn the “COARSE” pot counter-clockwise until it does.
  • Page 124 Microflite Ultra 2000 Using the MPU key pad, access the car parameter menu. Go to “LEARN TRIP, FLOOR NAMES, PRETORQUE.” Access the “PRETORQUE” screen. The screen should look something like this: RELEASE BRAKE AND CHECK FOR ROLLBACK POWER N BRAKE N GENERATOR N...
  • Page 125 Microflite Ultra 2000 key and observe the drive sheave. Edit the “PULSE HEIGHT” value until the car holds zero speed when the brake lifts. Move the cursor to the bottom section of the screen. Enter the value that held the car at zero speed into “PULSE HEIGHT: TOP EMPTY.”...
  • Page 126 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 9 - 12...

  • Page 127: Testing

    Microflite Ultra 2000 Section 10 Testing Terminal Limit Test - Top 10.1 NTS Test Place the car 3 - 5 floors below the top landing. Go to Page 12 of the Parameters (Floor Landing Values). Move the cursor to the top floor position and write down the current value.

  • Page 128: Counterweight Buffer Test

    Microflite Ultra 2000 10.3 Counterweight Buffer Test Note: On higher speed cars (700 fpm or higher), it is sometimes best to tie down the car safety arm for this test as the car may bounce in the overhead and set the car safeties and become lodged in the overhead.

  • Page 129: Car Governor Overspeed Test

    Microflite Ultra 2000 buffer. Immediately place the car on inspection. Remove the temporary jumpers from the limit board. Check that the compensating sheave has not come out of its rails if applicable. Go back to the Floor Landing Values Screen and put the original floor count for the bottom floor in the bottom floor position (should be 2000).

  • Page 130: Counterweight Governor Overspeed Test

    Microflite Ultra 2000 Inch the car up until the governor jaw can be reset. Untie the car governor jaw and reset the latch. Remove the temporary jumper placed across the governor overspeed switch. Remove the temporary jumpers from the Limit board.

  • Page 131: Car Diagnostic Screen

    Microflite Ultra 2000 Section 11 Diagnostic Screen Display / Parameter Entry 11.1 Car Diagnostic Screen Example: 15:49:48 01/08/03 WEDNESDAY 018R 266 PARK AVENUE CAR 12 INDC DOB REG SAF MGSH DDSH DOBH IDN LMGS OSPD CWSW CWL UDAC DDAC FRLC FPC...
  • Page 132 Microflite Ultra 2000 The signal may be reversed by the Car Station software so it interfaces correctly with the CPU software. Lines 7, 8, and 9 on the diagnostic screen are inputs that are mapped to the controller. These inputs may be on the Relay board or one or more of the I/O cards.

  • Page 133: Comprehensive Fault Listing

    • When the car is stopped, it displays the current floor. The remaining numbers on line 19 are values used for software diagnostic purposes. O. Thompson personnel use these values for developmental purposes. The first information on line 20 is the percentage of full load presently in the car. 022 indicates that the car is at 22% of full load.
  • Page 134 Microflite Ultra 2000 Standard Inputs attendant brake released attendant bypass buzzer inhibit/floor passing chime disable car gate nCF or nC front car call at n floor rear car call at n floor DCBF or DCB door close button front DCBR...
  • Page 135 Microflite Ultra 2000 OPTIONAL INPUTS IN ALPHABETICAL ORDER alarm bell alternate dispatcher/swing car AREC first alternate recall (simplex cars only) BREC second alternate recall (simplex cars only) in car medical emergency switch counterweight latch CWSW counterweight switch dynamic brake DHLF or DHL...

  • Page 136: Diagnostic Screen Display - Outputs

    Microflite Ultra 2000 11.4 Diagnostic Screen Display - Outputs Outputs such as position indicators, signals for lanterns, buzzers, lights, motion control outputs, etc are displayed on the main screen and will vary somewhat from job to job. The following is a listing in...

  • Page 137: Using The Keypad & Accessing Diagnostic Screens

    Microflite Ultra 2000 next car up other car next out of service light PI flash (indicates car delayed at a floor) SECL security/access active light this car down TCU/TCN this car up/next advanced up direction front gong and/or lantern UPGR...

  • Page 138: Acceleration/Deceleration Curves

    Microflite Ultra 2000 When the 0 button is pressed while on 'View previous events', the event previous to the one presently shown is displayed, until the least current fault is on the screen. Pressing 0 while on 'View next event' brings the next event to the screen, until the most current event is displayed.

  • Page 139: Accessing Parameter Screens

    Microflite Ultra 2000 11.5.5 Accessing Parameter Screens Any time the parameter screens are accessed, the car is not capable of running. Therefore, the car should be halted and removed from group service prior to attempting to switch from the diagnostic mode to the parameter mode of operation.
  • Page 140 Microflite Ultra 2000 11.7 PARAMETERS 11.7.1 Motion Parameters Menu NOTE 1:The S -Curve parameters have HIGH PERFORMANCE and ENERGY CONSERVATION settings. This allows for the adjustment of 2 independent S-Curves for peak and off peak traffic times. NOTE 2: There are two sets of values for HIGH PERFORMANCE, one for long runs and one for short runs.
  • Page 141 Microflite Ultra 2000 MAX FLOOR DISTANCE FOR HPS (COUNTS) This parameter sets the distance in counts (16 per inch) to switch from the short run values (HPS) to the long run values (HPL) when in the High Performance mode of operation. A value of 2500 (approximately 13 feet) is recommended.
  • Page 142 Microflite Ultra 2000 Higher values make the system initiate changes in the profile sooner since the car will not follow the demanded profile closely. Setting this value too large will lengthen the slow down and adversely impact floor-to-floor times. Reasonable values range from 15 to 50. Try an initial setting of 25 and monitor the scope screen to determine if adjustments are required.
  • Page 143 Microflite Ultra 2000 car will travel at a constant speed before initiating the slow down into the target floor. This parameter is generally not used on jobs with AC or DC drives, but only on jobs with MG sets. This is because some MG sets have a relatively large time constant for the field pieces.
  • Page 144 Microflite Ultra 2000 to the main menu by pressing the reset button (S1 button on CPU card). Values entered are not permanently stored in memory until the “W ” option is selected. RITE ALUES TO OLATILE EMORY Revision AA 2.2...
  • Page 145 Microflite Ultra 2000 11.7.2 Hoistway Device and Brake Parameters Menu BRAKE SWITCH NORMALLY OPEN? Y/N - When set to “Yes” the BKR input goes high when brake is lifted. When set to “No” the BKR input turns off when the brake is lifted.
  • Page 146 Microflite Ultra 2000 ADVANCED PI’S AND HALL LANTERNS? Y/N - If set to “Yes” the position indicators will advance out to the internal position of the microprocessor and hall lanterns will ring in advance of the car decelerating into the floor. It is recommended that this feature be enabled, as it provides additional time on the hall lanterns.
  • Page 147 Microflite Ultra 2000 11.7.3 Car Operating Devices Parameters Menu BINARY PI START AT 0 OR 1 - A zero (0) will set all binary position indicator outputs off for the first floor. A one (1) will set binary position indicator output one (1) on, and all other position outputs off for the first floor.
  • Page 148 Microflite Ultra 2000 % FULL LOAD WEIGHT DISP 000 - (Used on Pre-torque jobs only). Enter the weight at which the selected car should dispatch from the lobby only. BYP 000 - (Used on Pre-torque jobs only). Enter the percentage load at which the car should bypass hall calls as measured by the strain gauge on the crosshead.

  • Page 149: Door Parameters

    Microflite Ultra 2000 11.7.4 Door Parameters Menu DOOR TIME (0.1 SEC) CAR CALL HALL CALL NUDGING 0000 FREIGHT REOPEN RECYCLE LOBBY LOBBY AFTER CALL 000 DOOR TIME - CAR CALL - is the door open dwell time when answering a car call only. If the electric eye is broken, the door time is reduced to the parameter value, DOOR REOPEN TIME.
  • Page 150 Microflite Ultra 2000 DCL / DOL CLOSED AT LIMITS? Y/N - “Yes” = DCL input is energized when doors are fully closed and door open limit is energized when doors are fully open. “No” = DCL input is de-energized when doors are fully closed and door open limit is de-energized when doors are fully open.
  • Page 151 Microflite Ultra 2000 11.7.5 Fire and Emergency Power Parameters Menu FIRE CODE – Selects the proper fire code operation. Pressing the ‘0’ key toggles between the available options. Options are: CHICAGO, NATIONAL, WHITE PLAINS, CALIFORNIA, CANADA, NEW YORK CITY, AUSTRALIA, NEW ZEALAND...
  • Page 152 Microflite Ultra 2000 ANSI/ASME 2000 Code required the FBY input will not be present, but will be replaced by FRST. This input acts similar to the FBY input in that it will allow the cars to return to service if the AREC, BREC, or CREC inputs are off, but if any of them are on the cars will remain on Fire Recall.

  • Page 153: Vip, Medical & Earthquake Parameters

    Microflite Ultra 2000 11.7.6 VIP, Medical, Earthquake Parameters Menu VIP SERVICE ENABLED - When set to “Yes” the car will treat medical calls from the dispatcher as VIP calls. Upon assignment of a VIP call the car will be removed from group service, complete answering any car calls and then proceeds to the VIP call floor.
  • Page 154 Microflite Ultra 2000 MED BUZZ REMAINS ON UNTIL CME ENABLED? When set to “Yes” the in-car buzzer will remain on until the car is placed on Medical Emergency Phase II or the car is removed from Medical Emergency Phase I.
  • Page 155 Microflite Ultra 2000 Return to the main menu by pressing the ‘0’ key when the cursor is on “RETURN TO MAIN MENU”. You can leave the parameter entry screen without saving your data at any time and return to the main menu by pressing the reset button (S1 button on CPU card). Values entered are not permanently stored in memory until the “W...

  • Page 156: Miscellaneous Parameters

    Microflite Ultra 2000 11.7.7 Miscellaneous Parameters Menu SECURITY CODE ENTRY TIMEOUT SEC Applies to jobs with security lock out feature only. It sets the allowable time to enter the following sequence: start of code button, desired floor button, up to a maximum of 8 code buttons and the end of code button.
  • Page 157 Microflite Ultra 2000 GATE/DOOR LOCK BYPASS PERMISSIVE? This parameter sets if the gate and door lock bypass switches are present. MAIN CONTACTOR HOLD TIME (0.1 SEC) This parameter sets the amount of time (in 1/10 of a second) that the main contactor will remain picked after the brake contactors are dropped.
  • Page 158 Microflite Ultra 2000 11.7.8 Simplex / Inconspicuous Riser Parameters Menu NOTE: These parameters are for simplex cars only. On group cars they are not accessible. DOOR OPEN TIME LOBBY - SEC 00 - Lobby door open time for a simplex or inconspicuous riser car.
  • Page 159 Microflite Ultra 2000 To MANUALLY use the energy conservation feature, select the days for which you would like to feature to be active, by entering a Y for the day. Set the time period for the feature to be active, in military format, and set a 0 to keep the system on high performance and a 1 to switch to energy conservation.

  • Page 160: Event Disable Parameters

    Microflite Ultra 2000 11.7.10 Event Disable Parameters Menu This menu allows the user to disable certain events from registering in the event log. The controller will still behave the same way if the event occur, but the event will not be noted in the event log.

  • Page 161: Binary Pi Outputs Menu

    Microflite Ultra 2000 11.7.15 Binary PI Outputs Menu BINARY PI OUTPUTS: LD PI# LD PI# LD PI# LD PI# 1 __ 17 __ 33 __ 49 __ 2 __ 18 __ 34 __ 50 __ 3 __ 19 __ 35 __...

  • Page 162: Floor Names Entry Menu

    Microflite Ultra 2000 11.7.16.2 Floor Names Entry Menu LD# NAME LD# NAME LD# NAME LD# NAME 1 __ 17 __ 33 __ 49 __ 2 __ 18 __ 34 __ 50 __ 3 __ 19 __ 35 __ 51 __...

  • Page 163: Modem Parameters

    Microflite Ultra 2000 11.7.17 Modem Parameters Menu MODEM PARAMETER ENTRY PHONE # ______________ JOB ID # ____________ CONNECT VOLUME (0=Off 3=Loudest) Revision AA 2.2 Printed 03 - 15 - 03 11 - 33...
  • Page 164 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision AA 2.2 Printed 03 - 15 - 03 11 - 34...

  • Page 165: Dispatch

    Microflite Ultra 2000 Section 12 Dispatch 12.1 Dispatcher Diagnostic Screen Shown below in Figure 12.1 is an example of a typical dispatcher diagnostic screen. The numbers at the left are for reference only, and would not be visible on the screen.

  • Page 166: Car-Dispatcher Communication / Hall Button Failure

    Microflite Ultra 2000 Line 13 shows the status of the cars in the group. Cars 9, 11, and 12 show a status of “NOR”. This indicates that they are on normal operation. Car 10 shows a status of “MLF”. This indicates that the car is malfunctioning and the dispatcher cannot communicate with it.

  • Page 167: Outputs From The Dispatcher

    Microflite Ultra 2000 CREC Third (C) smoke detector nD or nDF Front down hall calls (F is shown only if there are any rear calls in the system) Rear down hall calls Energy conservation Emergency power input Emergency power manual car select switch (followed by car number)

  • Page 168: Dispatcher Programming

    Microflite Ultra 2000 12.5 Dispatcher Programming 12.5.1 Entering & Saving Parameters Just as with the car display card, the bottom three buttons on the dispatch display card are used to move the cursor around the screen and change parameters. To move the cursor to the left, press the “*”...

  • Page 169: Parameters

    Microflite Ultra 2000 12.6 Dispatcher Parameters 12.6.1 Parameter Menu One Description LONG WAIT PRIORITY: This should be set to a value that is at least twice as large as the average wait time. When a call has been in longer than the long wait time, it will be given priority by the dispatcher.

  • Page 170: Parameters Menu Two Description

    Microflite Ultra 2000 12.6.2 Parameter Menu Two Description PENALTIES: GENERATOR OFF: This value is a disadvantage given to a car that is parked with its MG set turned off when the dispatcher is assigning hall calls. This should be set to "0" for SCR drive systems. In general, the more cars that are available to dispatch the higher this penalty should be set (less need to turn on the generator in a car with its generator off).
  • Page 171 Microflite Ultra 2000 the Fire Recall (Phase I) operation. Setting this to a “Yes” will cause cars on Medical Emergency Phase I to remain standing at the floor even though the has been a Fire Recall initiated. RET ATT/IND CARS ON MEDICAL RECALL: If this parameter is set to “No”...
  • Page 172 This parameter is used only for O. Thompson development personnel. The only purpose that could be used outside of O. Thompson’s development lab would be to re-set all parameters to their default values. Entering “721” sets all dispatcher parameters to their default values.

  • Page 173: Parame Ters Menu Four Description

    Microflite Ultra 2000 prefixes). The Central Station will need to identify this caller with an ID (each node calling the Central Station needs a unique ID). 12.6.4 Parameter Menu Four Description LOBBY FLOOR: This parameter sets the floor the dispatcher will consider to be the Lobby floor for dispatching and zoning.
  • Page 174 Microflite Ultra 2000 CARS LBY OFF PK: GP1: __ GP2: __ CARS LBY UP PK: GP1: __ GP2: __ CARS LBY DN PK: GP1: __ GP2: __ These parameters set the number of cars to park in the Lobby during each mode of service. These can be set from 0 to 10 and group one has a default value of 0 for DOWN PEAK, 1 for UP PEAK, and 1 for OFF PEAK.

  • Page 175: Parameters Menu Five Descriptions

    Microflite Ultra 2000 12.6.5 Parameter Menu Five Description EMERGENCY POWER: RET ATT/IND CARS EM PWR PH I This only applies to cars that are on attendant or independent at a floor with their doors open when the Emergency Power signal is activated. If the door is not open the car will do a Phase I recall to the recall floor.

  • Page 176: Lock Screens

    Microflite Ultra 2000 EMG SWITCH NORMALLY OPEN: This parameter sets the polarity of the EMG input. 12.6.6 Lock Screens After the dispatcher parameter menus there are additional screens to allow hall calls to be locked and unlocked for each car by floor and direction. Car calls can be locked and unlocked through these screens on the dispatcher for each car.
  • Page 177 Microflite Ultra 2000 RET2 output. This will allow the master to again try to place its car(s) in service. There will only be one re-try attempt. If the RET2 input does go from on to off the master will go on Emergency Power Phase I. Losing the RET1 input during Emergency Power Phase II has no effect.
  • Page 178 Microflite Ultra 2000 THIS PAGE INTENTIONALLY LEFT BLANK Revision: AA 2.2 Printed 03 - 15 - 03 12 - 14...

  • Page 179: Car Controller

    Microflite Ultra 2000 Section 13 Sequence of Operation & Troubleshooting 13.1 Car Controller Distributed Processor Control The car controller is a distributed microprocessor-based system. The primary advantages of a distributed microprocessor system are a reduction in traveling cable wires and redundant processors working together to decrease processing time.

  • Page 180: Relay Board

    Microflite Ultra 2000 13.1.1 Relay Board The relay board is connected to the MPU board via two 50 pin ribbon cables. Inputs are sent to the MPU via the left hand ribbon cable, and outputs are connected through the right hand cable.

  • Page 181: The Mpu

    Microflite Ultra 2000 INS UP/DN Sw. The inspection UP/DN switch allows the car to be moved at inspection speed from the controller. This switch is overridden by In Car and Top of Car Inspection. NON/RESET Sw. This switch should normally be in UP, or RESET position to allow the car microprocessor to reset t h e motor drive system in the event of a fault.

  • Page 182: The Intelligent Car Station Board

    Microflite Ultra 2000 Speed Curve Generation The MPU handles the digital speed pattern generation. It takes in information from the remote processors and then outputs an analog speed demand to the motor drive system. D/A Ports Two D/A (Digital to Analog Converter) ports are provided on the MPU board. The first D/A port is used to output an analog pattern to the motor drive system.
  • Page 183 Microflite Ultra 2000 can be plugged into the car station board to give up to 112 inputs and 112 outputs in the cab. The expansion boards plug into the intelligent car station board with a 26 pin ribbon cable and multiple boards can be plugged together to accommodate a wide variety of inputs and outputs at the car.
  • Page 184 Microflite Ultra 2000 Revision: AA 2.2 Printed 03 - 15 - 03 13 - 6...

  • Page 185: Car Top Encoder

    Microflite Ultra 2000 Inputs The inputs are wired to the side of the board that does not have the blue relays. Inputs can be either 24 VDC or 110 VAC. The inputs use a current limiting resistor in conjunction with bi-directional optocouplers so AC or DC inputs can be used on the same board.

  • Page 186: Encoder Diagnostics

    Microflite Ultra 2000 sliding through the brake in the event of a sudden power loss. When normal power is restored, in this case, there is no need for the encoder to re-synchronize to a floor because the car position is known within 1/16".

  • Page 187: Thompson Pretorquing

    13.1.5 Digital Speed Profile with “Curve Correction” The MicroFlite Ultra 2000 develops an ideal pattern that is continuously corrected throughout the duration of the run. The curve is corrected based on the encoder feedback received and plotted over time to give the microprocessor a speed feedback of its own. The car stops based solely on the encoder position, and does not need to transfer to an approach or leveling curve based on a leveling magnet as with most other systems.

  • Page 188: Inspection Sequence Of Operations

    Microflite Ultra 2000 13.2 Inspection Sequence of Operation The system will run on inspection without the microprocessor circuitry or any associated electronic devices being active. It is suggested that the MPU switch be left in the "off" position during construction.
  • Page 189 AC1 at line 117. If voltage is missing, drive not enabling. Reset drive and retry. If drive still not enabling, possible bad drive. Contact O. Thompson Technical Support. If voltage is present at TB3-5 then LPR relay is faulty.
  • Page 190 Microflite Ultra 2000 13.2.2 Inspection Operation - Amicon Generator Shunt Field Regulator On MG jobs, the EMGI switch can be turned off and the generator can be excited through a rectifier / resistor circuit provided on the controller if the generator field regulator continually trips on start up.
  • Page 191 Microflite Ultra 2000 Does the regulator “RUN” signal (Amicon pin 21) turn on? -Check for contact failure in regulator RUN circuit, line 101. Does the Regulator 208 VAC Supply turn on? -Check for power at terminals U & V, line 118. Regulator will trip on an “SCR” fault if voltage is not present.

  • Page 192: Inspection Operation - Magnetek Hpv 900

    SR relay. If present, check drive terminal TB2-55 to AC1 at line 117. If voltage is missing, drive is not enabling. Reset drive and retry. If the drive still not enabling, possible bad drive. Contact O. Thompson Technical Support. If voltage is present at TB2-55 then LPR relay is faulty.
  • Page 193 Microflite Ultra 2000 Does the car start to move slowly? -Check for proper drive signaling. -Is contact auxiliary signal to drive at TB1-9 on? -Check for contact failure on MB relay, line 104. -Is speed reference signal to drive present at terminals TB1-28 to TB1-27? -Check for contact failure or faulty relay board component in pattern generation circuit, line 105.

  • Page 194: High Speed Troubleshooting/Sequence Of Operations

    Microflite Ultra 2000 13.3 High Speed Troubleshooting / Sequence of Operations At this time it will be necessary to run the microprocessor. The status of inputs represented on the screen typically coincide with the status of the redundant relay associated with it. In other words, if the DG relay is energized, the DG input is highlighted on the screen.
  • Page 195 Microflite Ultra 2000 Is the DCL input on the monitor turned on? -DCL input signal not functioning correctly. -Faulty DCL input opto-isolator at line 231. Is the DOL input on the monitor turned off? -DOL input signal not functioning correctly -Faulty DOL input opto-isolator at line 231.
  • Page 196 Microflite Ultra 2000 Does the car start to move toward the floor? -Improper speed reference signal. -Check speed reference output from MPU at MJ7-1 and MJ7-2. If speed reference present at MPU, check speed reference at drive or regulator terminals. Faulty IY contact at line 107.

  • Page 197: A1 Blank Parameter Sheets

    Microflite Ultra 2000 Section A1 – Blank Parameter Sheets A1.1 Blank Car Parameter Sheets Parameter Entry Menu Selection Screen: 1-Motion Parameters 2-Brake and Hoistway Devices Parameters 3-Car operating devices Parameters 4-Door parameters 5-Fire, Emergency Power Parameters: 6-VIP, Medical, Earthquake Parameters...
  • Page 198 Microflite Ultra 2000 PARAMETER MENU 1: Motions Parameters: Speed (fpm) Relevel:__ Max:____ Min:___ Energy conserv switch: HIGH PERFORMANCE, ENERGY CONSERVATION, DYNAMIC SPEED CURVES: HP-High Perfomance L-Long S-Short Runs EC-Energy Conserve Max floor distance for HPS (counts) :00000 Init jerk rate (ft/s3): _._...
  • Page 199 Microflite Ultra 2000 PARAMETER MENU 3: CAR OPERATING DEVICES PARAMETERS: Binary pi start at 0 or 1? Ring down car lantern and gong once? Car lantern timeout(99 = no timeout) Floor pass chime(FPC) 1 down? Disabled code -(FPC) latched? BZI norm closed?
  • Page 200 Microflite Ultra 2000 PARAMETER MENU 5: FIRE and EMERGENCY POWER PARAMETERS: Fire code: CHICAGO, NATIONAL, WHITE PLAINS, CALIFORNIA, CANADA, NEW YORK CITY, AUSTRALIA, NEW ZEALAND NYC/White Plains Gate/Door contact faults detected AT ALL TIMES, AT NO TIMES, EXCEPT ON FIRE SERVICE...
  • Page 201 Microflite Ultra 2000 PARAMETER MENU 7: MISCELLANEOUS PARAMETERS: Security code entry timeout (sec) Alarm status trigger time (sec) FAN output normally open? Gen / fan shutdown time (sec) Alternate odd and even car calls for hall button or dispatcher comm failure Y N Stop at floor 00 in up dir.? Y N Down? Y N...
  • Page 202 Microflite Ultra 2000 CE VOICE ANNUNCIATOR MESSAGES: See message description at the bottom. MSG# LD# CE# LD# CE# LD# CE# LD# CE# Descr: EVENT DISABLE PARAMETERS: See event description at the bottom of this screen. 2 Y N 77 Y N...
  • Page 203 Microflite Ultra 2000 CAR CALL LOCK ENTRY: CAR CALL LOCKS FRONT AND REAR: ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______...
  • Page 204 Microflite Ultra 2000 FLOOR LANDING VALUES: FLOOR LANDING VALUES ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______ ______...
  • Page 205 Microflite Ultra 2000 FLOOR NAME ENTRY SCREEN: LD# NAME LD# NAME LD# NAME LD# NAME MODEM PARAMETERS: MODEM PARAMETER ENTRY Phone #____________ Job id #________ Init #____________________________ Connect volume(0=off 3=loudest): _ PASSWORD/JOB CONFIG/TIME/CLEAR EVENTS PARAMETERS: Parameter password protection enabled: Y N...
  • Page 206 Microflite Ultra 2000 Section A1 – Blank Parameter Sheets A1.2 Blank Dispatcher Parameter Sheets MAIN MENU: - RETURN TO DISPATCHER SCREEN - EDIT PARAMETERS - CHANGE / DISABLE PASSWORD - WRITE PARAMETERS TO EEPROM PASSWORD MENU: PARAMETER PASSWORD PROTECTION ENABLED: Y N...
  • Page 207 Microflite Ultra 2000 PARAMETER MENU 2: PENALTIES: GENERATOR OFF __ THIS CAR UP __ NEXT CAR UP __ HALTED TIME __ ADVANTAGES: IN LINE CALL CALL COINCIDENCE DOORS OPEN SIMULTANEOUSLY DOOR OPEN TIME LOBBY UP SEC (99 DOOR OPEN ALL THE TIME)
  • Page 208 Microflite Ultra 2000 PARAMETER MENU 4: LOBBY FLOOR ZONING RETARDATION (seconds): ZONE TO FULLY LOCKED FLOORS? PRIORITY PARK FLRS (0 NONE ZONE) FLR CAR TIME ON:HR:MN OFF:HR:MN ON __:__ OFF __:__ ON __:__ OFF __:__ ON __:__ OFF __:__ ON __:__...

  • Page 209: A2 Controller Event Descriptions

    Microflite Ultra 2000 Section A2 - Controller Event Descriptions While all of the faults listed below refer to Ultra 2000 cars, some of them may not be detected, depending on the job's hardware configuration. The following is a list of events detected by the car and/or the Building Management System.
  • Page 210 Microflite Ultra 2000 # Event Name Event Conditions 18 Door Lock Open out of Door Zone Door Lock(s) open while car is in motion and out of the door zone (Clipped Door Lock). 19 Door Close Limit Open out of Door...
  • Page 211 Microflite Ultra 2000 # Event Name Event Conditions 44 Controller Stop Switch Controller stop switch is open. 45 - 52 Reserved 53 Hoist Motor Field Hoist motor field loss open. 54 Door Operator Overload Door operator overload input on. 55 Spare...
  • Page 212 Microflite Ultra 2000 # Event Name Event Conditions 72 Simplex/IR Hall Button Failure Simplex or Inconspicuous Riser’s hall button fuse or communication to hall station lost causing the HBF input to be off for 15 seconds. If this fault occurs while the car is on simplex or inconspicuous riser service the car will begin “wild call”...
  • Page 213 Microflite Ultra 2000 # Event Name Event Conditions 104 Spare 105 Invalid Door Zone Magnet Encoder reading indicates car is in door zone but the door zone input from the magnet is not seen. 106 Slowdown Failure Unexpected slowdown limit open. Event is not detected until the car doors have opened.
  • Page 214 Microflite Ultra 2000 # Event Name Event Conditions Lobby Button Fuse Disp. Open Lobby hall button fuse open on group riser. Hall Call Buttons Disp. Fuse Open Hall call button fuse open on group riser. Hall Call Button Ack. Lights Disp.
  • Page 215 Microflite Ultra 2000 FAULTS DETECTED VIA THE FAULT BOARD The following table shows the faults detected via the fault board with the associated combination of binary inputs SA0 - SA4, the fault board input number, and the fault number being displayed on the Ultra 2000 car screen :...
  • Page 216 Microflite Ultra 2000 FAULT# INPUT# FAULT NAME REAR GATE SWITCH OPEN OUT OF FRONT GATE SWITCH OPEN IN DZ FRONT GATE SWITCH FAILURE FRONT GATE SWITCH OPEN OUT OF DZ NO FAULTS DETECTED VIA FAULT BOARD SA0 - SA4 inputs are not considered valid unless the same combination is seen for at least 5 loop times.

Table of Contents

Save PDF
