- Page 1 Sliding Door Operator ASSA ABLOY SL500 Resilience Owner’s Manual ASSA ABLOY, the global leader in door opening solutions...
-
Page 2: Table Of Contents
Other products from ASSA ABLOY ................ 23 © All rights in and to this material are the sole property of ASSA ABLOY Entrance Systems Inc. Copying, scanning, alterations or modifications are expressly forbidden without the prior written consent of the applicable company within ASSA ABLOY Entrance Systems Inc. -
Page 3: Congratulations On Your New Automatic Door
Congratulations on your new automatic door ASSA ABLOY has developed automatic doors for more than 50 years. State-of-the-art technology and carefully tested materials and components provide you with a superior product. As with all other technical products, your automatic door requires periodic maintenance and service. -
Page 4: Product Liability
Warranty ASSA ABLOY warrants its products to be free from defects in material and workmanship under intended use and service for a warranty time of 12 months, beginning at time of delivery. This warranty extends only to the original buyer of the equipment. -
Page 5: Service
• ASSA ABLOY -authorized resellers shall extend this warranty to end-users only but have no authority to extend a greater or different warranty on behalf of ASSA ABLOY. • A service agreement with ASSA ABLOY will help secure the availability of a fully operational system and will give priority at call-out, thus minimizing the time that the equipment is unusable. -
Page 6: How The Assa Abloy Sl500 Resilience Works
The closing starts when no OPENING IMPULSE is received and the HOLD OPEN TIME has expired, and no PRESENCE IMPULSE is activated. The ASSA ABLOY SL500 Resilience user can select five different modes of operation if an operator mode selector is installed. See Operation mode selectors on page 8. -
Page 7: Program Selectors And Functions
Program selectors and functions The functions of the door are selected with mechanical or key Program Selectors: 5 Position with Key uses 1/2" spacer or can be surface mounted 5 Position Mechanical Switch, flush or surface mounted. 3 Position Mechanical Switch, flush or surface mounted. -
Page 8: Integrated Safety
Integrated safety To permit a safe passage between closing doors, the doors reverse immediately if an obstruction is detected. They then resume their interrupted movement at low speed to check whether the obstruction has disappeared or not. If an obstruction is detected between opening doors and surrounding walls or interior fittings, the doors stop immediately, and then close after a time delay. -
Page 9: Technologically Advanced Sensors
Technologically advanced sensors The ASSA ABLOY sensors have been tested and approved by the ASSA ABLOY test laboratory for use on ASSA ABLOY's automatic sliding doors. These presence sensors further improve the already high obstruction detection obtained with the built in self- monitored reverse upon obstruction force limitation. -
Page 10: Safety System With Photocells
Open the door and move your hand from one side (right/left) into the inner door face presence field. Keep it motionless for several seconds at about 11.75" (30 cm) over the floor level. The door should remain open as long as you are within the detection area. Repeat the same procedure on the outer door face. -
Page 11: Emergency Escape
Emergency escape The operator can be fitted with emergency escape units to ensure a safe evacuation of the building. Break-out unit PSA The door leaves and the sidelites are swung outwards when a defined pressure is applied. The break-out function can also be used to create a wider opening. From the fully swung out position, the door leaves can be manually slid sideways, offering the possibility to transport wide objects through the opening, or to make a shop entrance more inviting during good weather. -
Page 12: Regular Safety Checks
Also ensure that the escape route is free for use. After the test, restore the door(s) to their normal mode of operation. = Take appropriate measures. = Contact your ASSA ABLOY representative. For contact information, see last page. Issue 2018-05-25 1018022-US-0.0... - Page 13 CLEANING The best way to remove dust and dirt from the ASSA ABLOY SL500 Resilience is to use water and a soft cloth or a sponge. A gentle detergent may be used. To maintain the quality of the enamel layer, the surfaces should be cleaned once/four months period.
-
Page 14: Identification
Identification No. Description No. Description Mains connection 1008184 SL500 Beam 1017783 Power supply unit (PSU 150) 1008147 Tooth belt 1701406 Drive unit 1007035 Tension wheel 1007118 Main control unit (MCU) 1007773 Jamb, Resilience US01-0931 Transmission bracket (low) 1007364 Resilience Door Stop Assembly... -
Page 15: Safety Accessories
Safety accessories Even though the ASSA ABLOY SL500 Resilience is installed to comply with all applicable safety regulations, it is possible to enhance safety/comfort with the following add-ons (please contact your local ASSA ABLOY company for detailed description). • Combined motion and presence sensors •... - Page 16 • I/O functions: Fire alarm connection Used to emergency open or fire close the door with mains power on. External error indication Obtained if a lamp or a buzzer is connected. Open / Close function A one button impulse, will alternate between Open and Close. The door will stand open until next impulse or can after an adjustable time delay automatically start to close even if a new impulse is not received.
- Page 17 • Bottom Guide Systems Resilience Pin Guide Assembly P/N: 1016658 Resilience Tee Block P/N: 1016649 The Full Break Out (FBO) pin guide has two options for guide tracks, including: Recessed threshold Surface threshold See Installation Requirements section for guide installation. 1018022-US-0.0 Issue 2018-05-25...
- Page 18 5 Operation Modes Switch (Key) P/N: US15-1500-06 Spacer Switch Kit P/N: US15-1500-03 Vinyl Decal (5 operation modes switch) P/N: US24-1500-51 Remote Switch Kit P/N: 1009342 Operation Mode Selector Extension Kit P/N: US15-1500-02 SL500 MSCB with Plastic Bracket P/N: 1013971 Issue 2018-05-25 1018022-US-0.0...
-
Page 19: Troubleshooting
Reset the operator by using the Program Selector. See page Allow the operator to control the closed position without interruption. If the problem continues, please contact your ASSA ABLOY representative. 1018022-US-0.0 Issue 2018-05-25... -
Page 20: Maintenance/Service
ASSA ABLOY-trained and qualified technician. This is especially important when the installation concerns a fire-approved door or a door with an emergency opening function. Refer to ASSA ABLOY Pro-Active Care option services to learn more about service possibilities! - Page 21 Floor Mat Activation Step on the "opening" (activating) mat in several places. Door should slide open smoothly and stop without impact. (See Figure 3) Step through the doorway onto the mat on the other side. Door should remain fully open without interruption.
- Page 22 Remove dust and dirt from the operator. Dirt on the sliding track should be removed with methylated spirits. If replacement is necessary, please contact your local ASSA ABLOY representative. Check if any of the parts need lubrication. Traffic Patterns. Observe traffic patterns. Plan routing so people enter and exit in a straight approach, directly towards the center of the door opening.
-
Page 23: Other Products From Assa Abloy
Check all panels for damaged or loose weather stripping. • Clean door, glass and header thoroughly. Note, on the Planned Maintenance Review, any recommendations to improve door performance and reliability and review with customer. Other products from ASSA ABLOY • Door Systems • Balance doors •... - Page 24 Tel: (704) 290 5520 • Fax: (704) 290 5544 Tel: (877) 237 2687 (service) • Tel: (866) 237 2687 (sale) www.ASSA ABLOY-usa.com • specdesk.na.entrance@assaabloy.com ASSA ABLOY is the global leader in door opening solutions, dedicated to satisfying end-user needs for security, safety and convenience.
