Connecting dc power
Hide thumbs
Also See for IMG 1010:
- Quick start manual (18 pages) ,
- Installation instructions manual (9 pages) ,
- Installation and setup manual (169 pages)
Table of Contents
Advertisement
Insert the plug into the DC power module and secure with screws.
Turn power ON at redundant power source.
Press the required circuit breaker on the DC power module to ON (I).
Warnings/Cautions
Failure to turn power OFF at the redundant power source may result in electrical shock.
Ensure that the wires are pushed into the plug far enough, so that none of the copper is visible.
The DC power module plugs are polarity sensitive. The unit will not operate if the plugs are not wired correctly. See wiring diagram above.
