  • Page 1 Assembly and Operating Instructions TF-RB99 TFRB99.01.02 Ergometer RB9.9...
  • Page 2 RB9.9...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console display Button functions Powering on the crosstrainer Standby mode MANUAL (Manual programs) 3.5.1 Quick-Start program 3.5.2 Target programs PROGRAM (Profile programs) USER (User defined program) H.R.C.
  • Page 4 RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT RB9.9...
  • Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
  • Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. RB9.9...

  • Page 7: General Information

    GENERAL INFORMATION Technical Data LCD Display: Training duration in min. Speed in km/h Training distance in km Calories in kcal Heart rate (using the hand pulse sensors or a chest strap) Watts Brake system: Electro-magnetic induction brake Resistance levels: Watt range: 20 - 300W Flywheel mass: 10kg...

  • Page 8: Personal Safety

    Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. RB9.9...

  • Page 9: Electrical Safety

    Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 10: Set-Up Place

    (over 70%) like swimming pools. A floor protective mat/equipment underlay can help to protect high-quality floor coverings (parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. RB9.9...

  • Page 11: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 12: Scope Of Delivery

    In the event of complaints, the contractual partner must be contacted directly. ⚠ CAUTION If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. RB9.9...
  • Page 13 114 & 115 51L & 51R STEP 1 7A M8*1.25*110L 4PCS 16 D16*D8.5*1.2T 8PCS 7 M8*1.25*70L 4PCS 9 D15.4*D8.2*2T 8PCS STEP 2 9 D15.4*D8.2*2T 4PCS 16 D16*D8.5*1.2T 4PCS 15 M8*1.25*15L 4PCS STEP 3 39 M5*12L 8PCS STEP 4 8 D22*D8.5*1.5T 4PCS 9 D15.4*D8.2*2T 3PCS 41 M8*1.25*50L 4PCS 15 M8*1.25*15L 3PCS...

  • Page 14: Assembly

    Remove and dispose of the mounting kit along with the two screws - they are not part of the mounting kit (see fig. 1-3). Mount the front stabiliser (4) to the main frame (1) using two screws (7 & 7A), four washers (16) and four spring washers (9) (see fig. 1-4). Now tighten all screws tightly. RB9.9...
  • Page 15 M8x1.25x70L M8x1.25x110L D15.4xD8.2x2T D16xD8.5x1.2T 7 16 7 16...
  • Page 16 Lift the equipment on the desired side and rotate the adjustable screws under the main frame. Rotate the screws clockwise in order to unscrew them, therefore raising the equipment. Rotate the screws counterclockwise in order to lower the equipment. RB9.9...
  • Page 17 M8x1.25x15L D15.4xD8.2x2T D16xD8.5x1.2T...
  • Page 18 Place the console (76) on the front post (17). Attach the console (76) to the front post (17) with four screws (39) (see fig. 3-2). Fix the cover (40) to the console (76) with four screws (39) (see fig. 3-3). RB9.9...
  • Page 19 M5*12L 40 39 Step-3...
  • Page 20 Place the bottle holders (20) in the holders of the handles with the hand pulse sensors (36). Attach the front handlebar (72) to the front post (17) with two screws (41) and two curved washers (8). Place the cover (42) on the front handlebar (72) on the screw connection. RB9.9...
  • Page 21 M8x1.25x50L D22*D8.5*1.5T M8x1.25x15L D15.4xD8.2x2T D16xD8.5x1.2T 8 41 Step-4...
  • Page 22 Technical errors can result. Connect the power cable (66) to the unit and then plug the power cable (66) into a wall socket that complies with the specifications in the chapter on electrical safety. RB9.9...
  • Page 23 M8x1.25x35L D16xD8.5x1.2T M5*12L ST4.2*15L Step-5...

  • Page 24: Operating Instructions

    Display of the current revolutions per minute (RPM) (0-999) LEVEL Display of the current resistance level WATTS Display of the Watt value (0 -999) Display of your heart rate (0-230) PULSE Set a heart rate target with the rotary knob (0-30-230) in singluar increments RB9.9...

  • Page 25: Button Functions

    Button functions BUTTON DESCRIPTION Increasing the setting value or resistance level Rotary knob Decreasing the setting value or resistance level Setting confirmation BODY FAT Body fat test RECOVERY Heart rate test on your recovery condition Returns you to the previous training mode while making settings or RESET selecting an option.

  • Page 26: Powering On The Crosstrainer

    USER PROGRAM (user defined program) H.R.C (Heart rate controlled programs) WATT (Watt program) Standby mode The console goes into standby mode after four mintues without inputs or movement- The console will exit standby mode as soon as it registers movement. RB9.9...

  • Page 27: Manual (Manual Programs)

    MANUAL (Manual programs) Under MANUAL you can choose between the Quick-Start program and one of the target programs. For target programs, settings for time (TIME), distance (DISTANCE), caloires (CALORIES) or heart rate (PULSE) are possible. 3.5.1 Quick-Start program In the main menu, select MANUAL and confirm your choice with a single push of the rotary knob.

  • Page 28: Program (Profile Programs)

    During training it is possible to change the resistance level with the rotary knob. To pause the program, press the START/STOP button again. NOTICE While the program is paused it is possible to change the training time. To end the program, press the RESET button. RB9.9...

  • Page 30: User (User Defined Program)

    START/STOP button to directly start your training. NOTICE During training it is possible to change the resistance level with the rotary knob. To pause the program, press the START/STOP button again. To end the program, press the RESET button. RB9.9...

  • Page 31: Heart Rate Controlled Programs)

    H.R.C. (Heart rate controlled programs) ⚠ WARNING This crosstrainer is not medical equipment. The heart rate measurement of the crosstrainer can be unprecise. Different factors can influence the heart rate reading. The heart rate readings are only meant as a guide for training. There are three heart rate programs available to choose from.

  • Page 32: Watt (Watt Program)

    If you wish to prematurely end the recovery function, press the RECOVERY button again. Based on the final pulse readings, once the countdown ends you'll receive a fitness grade from F1 to Very good Good Average Adequate Very bad RB9.9...

  • Page 33: Body Fat (Body Fat Analysis)

    3.11 BODY FAT (Body fat analysis) Choose your user profile (U1-U4). To start the body fat analysis, in the main menu press the BODY FAT button and hold on to the hand pulse sensors. NOTICE Should you not properly grip the hand pulse sensors, the display will show the error code E-1. NOTICE If you wish to prematurley end the body fat analysis and return to the previous program, press the BODY FAT button again.

  • Page 34: Bluetooth And Fitness Apps

    Training apps can be found on the App Store or on GooglePlay. For example you can find the apps "Kinomap" or "iconsole+". Please note that these apps are offered from a third party developer. Sport- Tiedje is not responsible for the availability, functionality or the contents of these programs. Example: Kinomap RB9.9...

  • Page 35: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 5°C and 45°C. WARNING ⚠...

  • Page 36: Troubleshooting, Care And Maintenance

    (e.g. Mobile, Speakers, etc.) Chest strap Use a compatible chest strap (see compatible recommended accessories) No pulse displayed Position of the chest Re-position the chest strap and/or strap is incorrect moisten the electrode(s) Batteries are empty Change the batteries RB9.9...

  • Page 37: Error Codes And Troubleshooting

    Error codes and troubleshooting The electronics of the crosstrainer are continually running tests. In case of deviations, an error code is shown on the display and normal operation is stopped for your safety. No values were received during the body fat analysis. Make sure that, during the analysis, you hold on to the hand pulse sensors with both hands.

  • Page 38: Recommended Accessories

    We will be happy to advise you! chest strap floor mat chest strap contact gel silicone spray towels RB9.9...

  • Page 39: Ordering Spare Parts

    Sport-Tiedje GmbH, Flensburger Str. 55, 24837 Schleswig MADE IN Serial nº.: The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / recumbent bike Model Name: RB9.9 Article Number: TF-RB99...

  • Page 40: Parts List

    Front post 744S0-3-2000-J0 Handpulse cable 744S0-6-2479-00 2400L Support of bottle 744S0-6-2292-B0 168.6*168.6*45 holder Bottle holder 26100-6-1578-B0 D134*115 Bearing 58006-6-1040-01 #6004-2RS(C0) GCr15 Waved washer 55120-5-2705-DA D27*D20.3*0.5T 65Mn Cross screw 54203-2-0030-F0 M3*0.5*30L Q235A C ring 55519-1-2312-DA D22.5*D18.5*1.2T 65Mn Screw 54203-2-0012-F0 M3*0.5*12L Q235A RB9.9...
  • Page 41 Crank axle 734S0-3-2903-00 Pulley 58008-6-1037-D0 D260*25*3T Q235A Nylon nut 55206-1-2006-FA M6*1.0*6T Q235A Bolt 50106-5-0015-C0 M6x1.0x15L Belt 58004-6-1116-00 430 PJ8 Round magnet 174R4-6-2574-00 Upper cable for quick 734S0-6-2539-00 400L button (2) Upper cable for quick 734S0-6-2542-00 400L button (1) Upper cover for 747S0-6-2517-B0 184.5*20.8*50 handpulse...
  • Page 42 Left rear chaincover 744S0-6-4512-B0 775.4*101.8*578.2 Right rear chaincover 744S0-6-4513-B0 775.4*98.3*578.2 Front Handlebar 744S0-3-2425-J0 Sensor cable 802S0-6-2576-00 300L Power delivery cable 747S0-6-2552-00 900L External cable of 832S0-6-3177-02 500L system Console 744S0-6-2501-B0 SE-8627-31 C ring 55517-1-0010-00 S-17(1T) 65Mn Waved washer 55117-5-2203-DA D17*D22*0.3T 65Mn RB9.9...
  • Page 43 Bearing 58006-6-1026-01 6203-2RS GCr15 Flat washer 55110-1-5030-NA D50*D10*3T Q235A Allen bolt 50308-5-0030-C0 M8x1.25x30L Flat washer 55108-1-2830-NA D28*D8.5*3T Q235A Plastic cover 803K0-6-1082-00 D3*30L Spring 58003-6-1055-N0 D2.6*15*82L 72A# Idle fixing plate 734S0-3-1600-00 Plastic flat washer 55110-1-2404-BF D10*D24*0.4T NL66 55208-2-2006-NA M8*1.25*6T Q235A Nylon nut 55208-1-2008-FA M8*1.25*8T Q235A...
  • Page 44 Bolt 50108-5-0025-F0 M8*1.25*25L Back pad 744S0-6-1145-B0 440*400*92 Decorative cover for 807S0-6-1075-B0 back pad Round end cap 553D6-1-0017-B8 6/8"x17 Bolt 52606-2-0025-N0 Q235A M6*1.0*25L Pad for bottle holder 261D8-6-1754-B0 D81*3T Hex cross wrench 58030-6-1031-N1 Opening spanner 58030-6-1035-N1 Q235A 155*30*5T RB9.9...

  • Page 45: Exploded Drawing

    Exploded Drawing...

  • Page 46: Warranty

    WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 47 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.

  • Page 48: Contact

    �� Mo - Fr 08:00 - 18:00 09:00 - 18:00 09:00 - 18:00 Please find a detailed overview including address and opening hours for all stores of the Sport-Tiedje Group in Germany and abroad on the following website: www.sport-tiedje.com/en/stores RB9.9...
  • Page 49 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store for www.sport-tiedje.co.uk home fitness equipment with currently 80 stores www.sport-tiedje.de/blog and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 web shops www.facebook.com/SportTiedje in the respective national language or have their desired equpiment assembled on site.
  • Page 50 Notes RB9.9...
  • Page 51 Notes...
