Assembly and Operating Instructions

max. 150 kg

~ 300 Min.

241 kg

L 135 | B 158 | H 220

FSTFMS45.01.01

Art. No. TF-MS45

Taurus

TF-

MS45 Pro

Table of Contents

Need help?

Do you have a question about the MS45 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Taurus MS45 Pro

Page 1 Assembly and Operating Instructions max. 150 kg ~ 300 Min. 241 kg L 135 | B 158 | H 220 FSTFMS45.01.01 Art. No. TF-MS45 Taurus MS45 Pro...
Page 2 MS45...
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display 3.1.1 Concentric and Eccentric Movement 3.1.2 iConsole + 3.1.3 Training Programme 3.1.4 Training Modes 3.1.5 Training Diagram 3.1.6 Training Summary Menu 3.2.1 Login 3.2.2 WiFi-Connection...
Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT MS45...
Page 5 European VAT Number: DE813211547 Disclaimer © TAURUS is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
Page 8: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Packaging dimensions (L x W x H) and article weight (gross, incl. packaging): Box 1: 226 cm x 87.5 cm 38.5 cm 256 kg Box 2: 45 cm x 28 cm x 31 cm 20.5 kg Box 3: 49 cm x 36 cm x 13.5 cm...
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.
Page 10: Electrical Safety
Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...
Page 11: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.
Page 12: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.
Page 13: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠...
Page 14 MS45...
Page 16 MS45...
Page 18 MS45...
Page 20 Hardware pack MS45...
Page 21: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given.  NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so.
Page 22 Step 2: Assembly of the Connection Tubes Assemble the lower connection tube (6) between the pipes (1 & 2) with four screws (7), eight washers (9) and four lock nuts (8). Assemble the upper connection tube (5) between the pipes (1 & 2) with four screws (7), eight washers (9) and four lock nuts (8).
Page 23 Step 3: Assembly of the Bending Tubes Assemble the left lower bending tube (10) to the left pipe (2) with two screws (7), four washers (9) and two lock nuts (8). Assemble the left upper bending tube (13) to the left pipe (2) with two screws (7), four washers (9) and two lock nuts (8).
Page 24 Step 4: Assembly of the Upper Fixing Plates Assemble two upper fi xing plates (14) to one foot pad (15) with two screws (7), four washers (9) and two lock nuts (8). Assemble the two upper fi xing plates (14) to the right lower bending tube (11) with four screws (7), eight washers (9) and four lock nuts (8).
Page 25 Step 5: Assembly of the Tubes and Columns Attach the right sliding sleeve (19) to the right tube (17). Assemble the right tube (17) to the upper fi xing plates (14) with two screws (7), four washers (9) and two lock nuts (8). Attach the left sliding sleeve (20) to the left tube (18).
Page 26 Step 6: Assembly of the Fixing Plates Assemble one tube (22) between two fi xing plates (21) with one screw (7), two washers (9) and one lock nut (8). Assemble the two fi xing plates (21) and the left sliding sleeve (24) to the left upper bending tube (13) with eight screws (7), 16 washers (9) and eight lock nuts (8).
Page 27 Step 7: Assembly of the Upper Beam Assemble the upper beam (25) between the fi xing plates (21) with six screws (26), 12 washers (9) and six lock nuts (8).
Page 28 Step 8: Assembly of the Motor Assemble the guiding rod ﬁxing tube (27) to the lower connection tube (6) with two screws (28), two spring washers (29) and two washers (30). Assemble the wheel frame (32) to the guiding rod ﬁxing tube (27) with two screws (34), four washers (9) and two lock nuts (8).
Page 29 Step 9: Assembly of the Connection Tube Assemble the connection tube (39) to the upper connection tube (5) with one screw (38), two screws (28), one washer (9), two spring washers (29) and two washers (30).
Page 30 Step 10: Assembly of the Right Guiding Rod Slide one barbell rod rubber pad (45), the right safety hook (47), one cushion (46) and one sliding sleeve (44) over the guiding rod (42). Assemble one locking sleeve (43) to the guiding rod (42) with one screw (49). Attach the lower fi xing seat (40) to the guiding rod (42) and assemble it to the upper fi xing plates (14) with two screws (48), four washers (9) and two lock nuts (8).
Page 31 Step 11: Assembly of the Left Guiding Rod Slide one barbell rod rubber pad (45), the left safety hook (51), one cushion (46) and one sliding sleeve (44) over the guiding rod (42). Assemble one locking sleeve (43) to the guiding rod (42) with one screw (49). Attach the lower fi xing seat (40) to the guiding rod (42) and assemble it to the upper fi xing plates (14) with two screws (48), four washers (9) and two lock nuts (8).
Page 32 Step 12: Assembly of the Decorative Caps Assemble two decorative caps (52) to the barbell rod (50) with two screws (54) and two spring washers (53). MS45...
Page 33 Step 13: Assembly of the Wires and Pulleys Part 1  NOTICE The wire and pulleys must be assembled simultaneously. Assemble one pulley (55) to the pulley bracket with one screw (57), one pulley bar (56), two washers (9) and one lock nut (8) and route the wire (4) to the next pulley bracket. Assemble one pulley (55) to the pulley bracket with one screw (58) and one washer (9) and route the wire (4) to the next pulley bracket.
Page 34 Step 14: Assembly of the Wires and Pulleys Part 2 Assemble the end of the wire (59) to the fi xing plates (21) with one screw (31), two washers (9) and one lock nut (8). Route the wire (59) downwards and assemble one pulley (55) to the pulley bracket (60) with one screw (58), two washers (9) and one lock nut (8).
Page 35 Step 15: Assembly of the Wires and Pulleys Part 3 Attach one end of the wire (62) to the motor (35). Route the wire upwards and assemble two pulleys (55) to the pulley brackets with two screws (58), four washers (9) and two lock nuts (8). Route the wire downwards and assemble one pulley (55) to the pulley bracket (60) with one screw (58), two washers (9) and one lock nut (8).
Page 36 Step 16: Assembly of the Wires and Pulleys Part 4 Assemble one end of the wire (63) to the motor (35) with one screw (31), two washers (9) and one lock nut (8). Route the wire (63) upwards and assemble one pulley (55) to the pulley bracket with one screw (58), two washers (9) and one lock nut (8).
Page 38 Step 17: Assembly of the Wires and Pulleys Part 5 Assemble one screw (7), two washers (9) and one lock nut (8) to the upper fi xing plates (14) on each side. Attach one hook (67) and one end of the wire (66) to the left sliding sleeve (20). Route the wire (66) downwards and assemble one pulley (65) to the pulley bracket with one screw (26), two washers (9), two powder sleeves (61) and one lock nut (8).
Page 40 Step 18: Assembly of the Barbell Hanging Brackets and Barbell Rod Sleeve Assemble three barbell hanging brackets (69) and three butterfl y clips (68) to the right pipe (1) with six screws (70) and six washers (71). Repeat this step for the left pipe (2). Assemble the barbell rod sleeve (72) to the right pipe (1) with two screws (70) and two washers (71).
Page 41 Step 19: Assembly of the Electronic Watch and Leg Press Plates  NOTICE The bolts and nuts for the electronic watch (77) and cable (78) are pre-assembled. Remove them before assembly. Assemble the plate (73) to the upper and lower connection tube (5 & 6) with four screws (76) and four washers (75).
Page 42 Step 20: Assembly of the Attachments Assemble the bull stick (79) to the upper fi xing plates (14) with one screw (31), one washer (36) and two powder sleeves (80). Attach the leg curl adjusting bracket (82) to the right short safety block (83). Attach the right horizontal bar (87), right t short safety block (83) and right long safety block (85) to the right tube (17).
Page 43 Step 21: Assembly of the Accessories Attach the accessories if required.
Page 44 Step 22: Connection of the Cables and Connecting the Equipment to the Mains Supply Connect the cables like shown. (A, B, C) Loosen the screw, attach the earth cable and re-tighten the screw completely with the allen key. (D) ATTENTION The equipment must not be connected to a multiple socket, otherwise it cannot be guaranteed that the equipment will be supplied with suffi cient power.
Page 45 Step 23: Assembly of the Shield Support Plate ATTENTION Be careful not to pinch the cables in the following step. Assemble the shield support plate (98) to the plate (73) with two screws (97), four washers (71) and two lock nuts (96). Peel off the back tape of the trunking (99) and stick it to the plate (73).
Page 46 Adjustments To change the weights on the barbell rod and the cable pulley: lower the barbell rod and the sliding tube to the lowest position 17. Now you can change the weights. ⚠ CAUTION Make sure to connect the hook to the sliding tube before using the pull tower because otherwise the cable may slack and jump out of the track.
Page 47: Operating Instructions
OPERATING INSTRUCTIONS  NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Always start your training with low intensity and increase evenly and gently. End your training with a cool-down phase.
Page 48: Concentric And Eccentric Movement
Reps Displays the completed repetitions. Displays the completed sets. Weight Displays the training weight. Start Press Start to start the training session. Infographic Displays your training data in real time. 3.1.1 Concentric and Eccentric Movement To improve your training results, this device utilises concentric and eccentric movement amplifi cation. Concentric movement: In a concentric movement, the muscle contracts and shortens to overcome a load.
Page 49: Training Modes
How to pause training: Press ‘Pause’ to stop the timer. Press ‘Resume’ to continue training. Press ‘Stop’ for 3 seconds to end the training session. A summary is displayed, see chapter 3.1.6. 3.1.4 Training Modes The power station has three training modes. To select a mode: Press ‘Training Mode’...
Page 50: Training Diagram
3.1.5 Training Diagram The infographic displays your data in real time during training. The following data is displayed: Speed: Displays the pulling speed (cm/s) in the form of a bar chart. Force: Displays the joules per repetition in the form of a bar chart. The formula is joules*speed. Span: Displays the speed in wave form.
Page 51: Training Summary
3.1.6 Training Summary After the training you will receive the following overview: Display Meaning Total Time Displays the total duration of the training. Training Volume Shows the training volume. The sets are multiplied by the number of repetitions and the weight moved. Total Calories Displays the calories burned.
Page 52: Menu
Menu You will fi nd four subcategories in the menu. Display Meaning Login Click on the icon to log in to your iConsole user account. Home The main page where you can fi nd all the training overviews. Wi-Fi Click on ‘Wi-Fi’ to display the available networks. Settings You can fi nd the settings here.
Page 53: Wifi-Connection
3.2.2 WiFi-Connection How to connect to the Internet: Click on “Wi-Fi”. Click on your network. Enter your password if necessary. You have connected to the Internet. 3.2.3 Settings Various options are available in the settings. Dark mode To activate the dark mode: Move the slider to the right.
Page 54: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location.
Page 55: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.
Page 56: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specifi ed intervals: Part Weekly Monthly Quarterly Cables Screw connections...
Page 57: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. For training equipment like smith machines, weight benches or racks this could for example be a fl oor mat, which makes your fi tness equipment stand more securely and also protects the fl oor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes.
Page 58: Serial Number And Model Name
Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Taurus / multi gym Model Name: Taurus MS45 Pro Motorized Multi Functional Cable and Smith Machine Article Number: TF-MS45 MS45...
Page 59: Parts List
Parts List Name Supplier Parts No. Specifi cation Qty. 8301 Pipe Assembly Part 8301 Pipe-left Assembly Part 8301 Weight stack Assembly Part 3058 Weight stack steel wire rope Assembly Part 8301 Connection tube-upper Assembly Part 8301 Connection tube-lower Assembly Part Hexagon Head Screws M10×75 Lock nut...
Page 60 8301 Nut Assembly Part Hexagon Head Screws M10×55 Motor Assembly Part Washer φ30*φ10*3 Hexagon Head Screws M10×70 Hexagon Head Screws M10×95 8301 Connection tube Assembly Part 3058 Fixing seat-lower Welding Part 3058 Fixing seat-upper Welding Part 1850 Guiding rod φ25*1850 3010 Locking sleeve φ40*φ25.5*35 8301 Sliding sleeve...
Page 61 Butterﬂy Clip φ50 Barbell hanging bracket Assembly Part Hexagon Head Screws M8×20 Washer φ8 Barbell rod sleeve Welding Part 8301 Plate 3059D Leg press plate Assembly Part Washer φ6 Hexagon Head Screws M6×16 8301 Electronic watch Assembly Part 8301 Wire Assembly Part 3058 Bull stick Assembly Part...
Page 62: Exploded Drawing
Exploded Drawing MS45...
Page 63: Warranty
WARRANTY Products from TAURUS® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
Page 64 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
