- Page 1 Assembly and Operating Instructions max. 180 kg ~ 60 Min. 66 kg L 170 | W 75 | H 122 TFRB99TFT.01.08 Art. No. TF-RB99-TFT Upright Bike RB9.9 Touch...
- Page 2 RB9.9 Touch...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Programmes 3.3.1 Quick Start 3.3.2 Target programmes 3.3.3 Pre-set programmes 3.3.4 User-defined programmes 3.3.5 Heart rate-oriented programmes 3.3.6 Watt programme Fitness Test Media... - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT RB9.9 Touch...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data TFT Display of: Training time in min. Speed in km/h Traning distance in km Calories in kcal Resistance level Heart rate (using the hand pulse sensors or a chest strap) RPM (Rotations per minute) Watts Brake system: Electro-magnetic induction brake Resistance levels: Flywheel mass:... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Electrical Safety
Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION The training room should be well ventilated during training and not be exposed to any draughts. Choose the place in which to set up the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... - Page 13 114 & 115 51L & 51R STEP 1 7A M8*1.25*110L 4PCS 16 D16*D8.5*1.2T 8PCS 7 M8*1.25*70L 4PCS 9 D15.4*D8.2*2T 8PCS STEP 2 9 D15.4*D8.2*2T 4PCS 16 D16*D8.5*1.2T 4PCS 15 M8*1.25*15L 4PCS STEP 3 39 M5*12L 8PCS STEP 4 8 D22*D8.5*1.5T 4PCS 9 D15.4*D8.2*2T 3PCS 41 M8*1.25*50L 4PCS 15 M8*1.25*15L 3PCS...
-
Page 14: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 15 M8x1.25x70L M8x1.25x110L D15.4xD8.2x2T D16xD8.5x1.2T 7 16 7 16...
- Page 16 Step 2: Mounting the front post Slide the cover (11) up along the front post (17) (see fig. 2-1). Connect the cables (64 & 65) and the cables (14 & 18) with one another (see fig. 2-2). Insert the front post (17) into the main frame holder (1). Connect the front post (17) with the main frame holder (1) with four bolts (15), four spring washers (9) and four flat washers (16).
- Page 17 Step 3: Mounting the console Connect the cables (76 & 64) and the cables (76 & 14) with one another (see fig. 3-1). Place the console (76) on the front post (17). Guide the ground cable through the console bracket on the console mast (17) and mount the console (76) to the console mast (17) with four screws (39) (see fig.
- Page 18 Step 4: Mounting the handles and backrest Insert the backrest (119) into the main frame (1) and secure with three screws (15), three washers (16), and three spring washers (9). Connect the cables (37L & 18) and the cables (37R & 18) (see fig. 4-1). Attach the handles with the hand pulse sensors (36) to the main frame (1) with two screws (41) and two curved washers (8).
- Page 19 Step 5: Mounting the covers and pedals Mount the seat (69) on the main frame (1) with four screws (112) and four washers (16). Screw the left pedal (51L) to the left crank (48L) by turning the pedal (51L) counterclockwise. Screw the right pedal (51R) to the right crank (48R) by turning the pedal (51R) clockwise.
- Page 20 Step 6: Alignment of the feet If the floor is uneven, you can stabilise the training equipment by turning the two adjustable screws under the main frame. Lift the equipment on the desired side and rotate the adjustable screws under the main frame. Rotate the screws clockwise in order to unscrew them, therefore raising the equipment.
- Page 21 IMPORTANT NOTE To ensure that your equipment has the latest software version, please perform an update before using it for the first time. Proceed as follows: Tap "Settings" in the lower right corner of the screen. Tap "Wireless" and connect your treadmill to the Internet. Return to the settings.
-
Page 22: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display DISPLAY DESCRIPTION Display of the current resistance level Level Display range: 1–32 Display of the training time in minutes... -
Page 23: Button Functions
Display of the MET or Watt value Definition: MET or metabolic equivalent is used to measure the average metabolic rate for a person. MET describes the quantity of oxygen that an average person needs when in rest. 1 MET = 3.5 ml/kg/min (The body consumes 3.5 milliliters of oxygen per kilogram per minute) is the amount of oxygen that the body needs when Mets/Watt in rest. -
Page 24: Programmes
Programmes This equipment offers many different programmes. This includes: a quick start programme, target programmes, pre-set programmes, user-defined programmes, heart rate-oriented programmes and one fitness test. 3.3.1 Quick Start When you are in the main menu, simply press START to start a training session via quick start. Alternatively you can also tap on „QUICK START“... - Page 25 Setting time / 30 = time for each section Programme LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL...
- Page 26 Setting time / 30 = time for each section Programme LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL...
-
Page 27: User-Defined Programmes
3.3.4 User-defined programmes Tap on „USER PROGRAM“ in the main menu. Choose one of the four user profiles (U1-U4). NOTICE The chosen user profile will be displayed on the upper border of the screen. The name of the user profile can be changed. To do this, simply tap on the user profile and type in the desired name. -
Page 28: Heart Rate-Oriented Programmes
3.3.5 Heart rate-oriented programmes ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. There are three different heart rate-oriented programmes. -
Page 29: Watt Programme
3.3.6 Watt programme Tap “WATT MODE” in the main menu. Set your desired target wattage and training time. NOTICE You can set a wattage value between 10 and 350 watts (in increments of 10). The default value is 120. You can enter the training time between 5 and 999 minutes. The default value is 20 minutes. To start the programme, press START. -
Page 30: Fitness Test
Fitness Test The fitness test consists of two phases. One is the warm up phase and the other is the actual fitness test. We recommend a chest strap for this test. NOTICE The RPM must be between 45 - 65 during the test, otherwise an error message will be displayed. If the RPM does not reach the specified amount within 5 seconds, the test will be stopped. -
Page 31: Media
Media Here you will find many different apps like YouTube, Twitter, Facebook or Instagram. IMPORTANT NOTE To make sure the pre-installed apps are working correctly, they must be updated regularly. If needed, the respective app will notify you to do so. To update the app, you need a google account. -
Page 32: Bluetooth And Fitness Apps
Bluetooth and Fitness Apps This console is equipped with a bluetooth interface. Please take note that your mobile device needs to be compatible with the bluetooth interface of the treadmill (bluetooth 4.0). To use training apps you will have to activate the bluetooth function on your mobile device (tablet or smart phone) and start the fitness app. -
Page 33: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 34: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 35: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Lubrication of moving parts Plastic covers... -
Page 36: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. - Page 37 MADE IN Serial nº.: The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / recumbent bike Model Name: RB9.9 Touch Article Number: TF-RB99-TFT...
- Page 38 Parts List Name Supplier Parts No. Specification Qty. Main frame 744S0-3-1000-J1 Rear stabilizer 744S0-3-2112-J0 Adjustable round wheel 26000-6-1095-B0 D38*M10*1.5 Front stabilizer 744S0-3-2100-J0 Cover of front stabilizer 734S0-6-2186-B0 600*190.2*79.4 Allen bolt 50308-5-0040-F3 M8*1.25*40L Bolt 50108-5-0070-F4 M8*1.25*70L Bolt 50108-5-0110-F5 M8*1.25*110L Curve washer 55108-3-2215-FA D22xD8.5x1.5T Spring washer...
- Page 39 Round magnet 742G0-6-2574-00 Upper cable for quick button (2) 734S5-6-2539-00 400L Upper cable for quick button (1) 734S5-6-2542-00 400L Upper cover for handpulse 747S0-6-2517-B0 184.5*20.8*50 Lower cover for handpulse 747S0-6-2518-B0 184.5*35.2*50 Membrane button(-) 744S4-6-2534-00 Membrane button(+) 744S4-6-2533-00 Handlebar 744S0-3-2400-J0 Lower cable for quick button (2) 734S5-6-2536-00 850L Lower cable for quick button (1)
- Page 40 Neutral line 734S0-6-3479-00 150L Ground line 734S0-6-3486-00 200L Upper cable for console 734S5-6-2572-00 300L Middle cable for console 744S4-6-2587-00 600L Lower cable for console 744S4-6-2573-00 800L Power cable 26100-6-1775-02 1700L Round end cap 553K0-1-0016-B8 D1 1/4"*16L Control board 734S5-6-2597-00 PA-AE00550, EMS Saddle 744S0-6-1146-B0 440*254*75...
- Page 41 Cross bolt 52606-2-0015-N0 M6*1*15L Bolt 50108-5-0045-F3 M8*1.25*45L Slide rail reinforce tube (2) 744S0-6-5114-J0 20*20*2.0T*43 Inner hex cylindrical head screw 54008-5-0055-F4 M8*1.25*55L Square buffer 25300-6-2175-B0 34*34*22T Bolt 50308-5-0100-F4 M8*1.25*100L Cable plug 55312-1-0015-BA D4*D12*13 Moving wheel 26100-6-1087-B0 D65*24 Connection tube of slide rail 744S0-3-5125-J0 Ajustable rod 744S0-3-2225-J0...
- Page 42 Exploded Drawing RB9.9 Touch...
- Page 43 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 44 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
- Page 45 CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de �� �� Åbningstider kan findes på...
- Page 46 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store for www.sport-tiedje.co.uk home fitness equipment with currently 80 stores www.sport-tiedje.de/blog and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 web shops www.facebook.com/SportTiedje in the respective national language or have their desired equpiment assembled on site.
- Page 48 Recumbent Bike RB9.9 Touch...
