- Page 1 Assembly and Operating Instructions max. 180 kg ~ 60 Min 60 kg L 169 | B 60 | H 162 FSTFRACERT.01.02 Art. No. TF-RACER-T Taurus Racer Pro Touch...
- Page 2 Racer Pro Touch...
- Page 3 Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Further Functions Programmes 3.4.1 Quick-Start Programme/Target Programme 3.4.2 Pre-set Programmes 3.4.3 Interval Programme 3.4.4 Heart Rate Controlled Programmes 3.4.5 Watt Programme 3.4.6 Virtual Training Routes Multimedia and Software Updates...
- Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT Racer Pro Touch...
- Page 5 European VAT Number: DE813211547 Disclaimer © TAURUS is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
- Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). Racer Pro Touch...
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ࣑...
- Page 8 Set-up dimensions (L x W x H) approx.: 168.5 cm x 60 cm x 162 cm Article weight (gross, incl. packaging) approx.: 66.5 kg Article weight (net, excl. packaging) approx.: 60 kg Maximum user weight: 180 kg Q-factor: 16.5 cm Use class: Racer Pro Touch...
- Page 9 Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.
- Page 10 Hereby, Fitshop GmbH declares that the radio equipment type Wireless Connection (2.402 – 2.480 GHz) complies with Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following website: www.fitshop.com. Racer Pro Touch...
- Page 11 Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.
- Page 12 To prevent damage to the equipment and the floor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. Racer Pro Touch...
- Page 13 Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠...
- Page 14 4 4 2 2 L L & & 4 4 2 2 R R 6 6 6 6 5 5 4 4 L L & & 5 5 4 4 R R 5 5 1 1 L L & & 5 5 1 1 R R Racer Pro Touch...
- Page 15 Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g.
- Page 16 Pass the middle computer cable (64) through the respective opening of the handlebar (36) ࣑ ATTENTION Be careful not to pinch the cables during the following step. Assemble the handlebar (36) to the handlebar adjustable tube (17) with two screws (6), two spring washers (9) and two washers (16). Racer Pro Touch...
- Page 17 Step 3: Assembly of the Computer Supporting Tube Connect the two left quick key cables (92L & 93L) to their corresponding counterparts (32L). Connect the middle computer cable (64) to its corresponding counterpart (63). Connect the two right quick key cables (92R & 93R) to their corresponding counterparts (32R). ࣑...
- Page 18 Step 4: Assembly of the Handbar Protective Cover Assemble the handbar protective cover (43) to the handlebar (36) with two screws (37). ST4*12L Step-4 Racer Pro Touch...
- Page 19 Step 5: Assembly of the Computer Connect the left quick upper cable (32L) to their corresponding counterparts (76). Connect the upper computer cable (63) to its corresponding counterpart (76). Connect the right quick upper cable (32R) to their corresponding counterparts (76). ࣑...
- Page 20 Mount the left and right bottle holder (54L & 54R) to the handlebar (36) with two screws (7) each. Now tighten all screw connections with the tool. 1 1 3 3 ST4*12L S S t t e e p p - - 6 6 Step-4 Racer Pro Touch...
- Page 21 Step 7: Adjustment of the Seat Height Adjustment CAUTION ⚠ The seat post is marked with “STOP” for the minimum insertion depth. When adjusting, make sure not to exceed the minimum insertion depth. Loosen and pull the L knob to adjust the height of the seat post. CAUTION ⚠...
- Page 22 Release the L knob. Retighten the L knob. Horizontal Adjustment Turn the L knob to the left until the handlebar can be moved. Adjust the handlebar into the desired position. Retighten the L knob by turning it to the right. Racer Pro Touch...
- Page 23 1 1 3 3 Step 9: Alignment of the Feet If the floor is uneven, you can stabilize the equipment by turning the two setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment.
- Page 24 Display of the heart rate Display range 0 - 230 Heart Rate NOTICE This equipment does not have hand pulse sensors. To measure the heart rate, a chest strap is required. Display of the Watt value WATT Display range 0-999 Racer Pro Touch...
- Page 25 Display of the heart rate zones HR Zone Display range very light, light, moderate, hard, maximum Display of the BAI consumption Display range 0 - 999 NOTICE Body Activity Intelligence (BAI) is a universal and consistent metric that applies to all ages and genders. It evaluates whether your physical activity and training are sufficient for improving your overall health and physical condition.
- Page 26 Here you can connect the console to a wifi network. Heart Rate Here you can connect the console to a chest strap. Here you can access different media: Netflix, Youtube, Multimedia Spotify, Kinomap, Firefox, Facebook, X (formerly known as Twitter), Instagram Racer Pro Touch...
- Page 27 Programmes There are a variety of programmes available to you. These include Quick Start programme: Target programme: Pre-set programmes: Interval programme: Heart rate programmes: Watt programme: You can also set your own virtual training routes via Google Maps.
- Page 28 To start the training, tap START. You can manually adjust the resistance during the workout. To pause the training, tap PAUSE. To stop the training, tap STOP. → When the training is finished, a summary of the recorded training parameters is displayed. Racer Pro Touch...
- Page 29 3.4.2 Pre-set Programmes Tap PROGRAMS in the main menu. Set the desired training time. Select one of the 12 pre-set programmes. To start the training, tap START. You can manually adjust the resistance during the training. To pause the training, tap PAUSE. To stop the training, tap STOP.
- Page 30 The workout starts with a 1-minute warm-up. You can manually adjust the resistance during the training. To pause the training, tap PAUSE. To stop the training, tap STOP. → When the training is finished, a summary of the recorded training parameters is displayed. Racer Pro Touch...
- Page 31 3.4.4 Heart Rate Controlled Programmes WARNING ⚠ Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. NOTICE For this programme, a chest strap is required.
- Page 32 To pause the training, tap PAUSE. To pause the training, tap STOP. → When the training is finished, a summary of the recorded training parameters is displayed. Racer Pro Touch...
- Page 33 3.4.5 Watt Programme Tap CONSTANT POWER in the main menu. Set the values for the desired training time, target wattage and target cadence for your training. To start the training, tap START. The resistance level is automatically adjusted according to the wattage you set. To pause the training, tap the following icon To stop the training, tap the following icon →...
- Page 34 11. To pause the training, tap the following icon 12. To end the training, tap the following icon → When the training is finished, a summary of the recorded training parameters is displayed. Racer Pro Touch...
- Page 36 Racer Pro Touch...
- Page 37 Multimedia and Software Updates ࣑ ATTENTION Check your TFT-console regularly for possible software updates. If available, make sure to carry out the updates soon. If the updates are not carried out over a longer period of time, this can lead to technical problems with the console. To make sure the pre-installed apps are working correctly, they must be updated regularly as well.
- Page 38 Example of an app Overview of apps and possible software updates Racer Pro Touch...
- Page 39 Compatibility Training Apps This indoor cycle is equipped with a wireless technology interface which allows you to connect the console to different training apps via your mobile device such as smartphone or tablet. You can find and download the training apps in the app stores of Google or Apple. NOTICE Make sure that FTMS is always turned on when connecting the console to third-party apps.
- Page 40 For the Taurus Racer, select Indoor Cycle. On the next page you will see the different brands. Select “Taurus” and then the Taurus Racer. Now all wireless technology sources in the surrounding area are displayed. Select a wireless technology source that begins with i-Console ..
- Page 41 STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑...
- Page 42 Tighten the pedals area Equipment wobbles Equipment is not level Align the feet Handlebar/saddle Loose screws Tighten screws firmly wobbles Display is blank/is not Batteries empty or loose Replace batteries or check cable working cable connection connections Racer Pro Touch...
- Page 43 Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower and vacuum cleaner robot, etc..) the room unsuitable chest strap Use a suitable chest strap (see RECOMMENDED ACCESSORIES). Wrong position of chest No pulse display strap Reposition chest...
- Page 44 The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. Racer Pro Touch...
- Page 45 RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For indoor cycles this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat or silicone spray to keep moving parts in good shape.
- Page 46 It’s located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / indoor cycle Model Name: Taurus Racer Pro Touch Article Number: TF-RACER-T Racer Pro Touch...
- Page 47 Parts List Name Supplier Parts No. Specification Qty. Main frame 849S0-3-1000-J3 Rear stabilizer 849S0-3-2112-J1 Adjustable wheel 76100-6-2174-B0 D50*M10*1.5 Front stabilizer 849S0-3-2100-J1 Oval Cap 849S0-6-2190-B0 125.5*54.6*88.6L Allen bolt M8*1.25*35L 50308-5-0035-F0 M8*1.25*35L,8.8level ScrewM8x1.25x20L 25600-6-3191-F0 M8x1.25x20L,8.8level Computer supporting tube 849S0-3-2460-J1 Spring 55108-2-1520-FA D15.4xD8.2x2T washerD15.4xD8.2x2T Back chain cover(left) 849S0-6-4512-B0...
- Page 48 Right chain cover 849S0-6-4502-B0 898*77.8*675.4 ScrewST4.2*1.4*10L 53342-2-0010-F0 ST4.2*1.4*10L left crank 58007-6-1093-J1 170LxM20*1.5PLeft tooth, large square right crank 849S0-3-2704-J2 Anti-loosen nutM10*1.25*9T 734S0-6-2775-N0 M10*1.25*9T,8.8level screwcover 734S0-6-2779-B0 D29*11.5L 51L&51R Pedal set(L&R) 58029-6-1161-B4 JD-004V M20*1.5P+Black SPD with beak and foot strap Racer Pro Touch...
- Page 49 screwM6*1.0P*16L 815S1-6-3191-F0 M6*1.0P*16L,8.8level Fixed plate(L) 849S0-6-2427-J0 154*75*4T Fixed plate(R) 849S0-6-2428-J0 154*75*4T Bottle holder(L) 850A1-6-2091-B1 148*119.8*83.5*5T Bottle holder® 850A1-6-2092-B1 148*119.8*83.5*5T EMS system 849S0-3-3102-00 D270*D30*50,12kg 71600-6-4586-60 D6*26.5*7.7 Switching mode power 261D8-6-2411-00 With a light source supplier Socket 26100-6-2413-00 ScrewST4*1.41*10L 51004-2-0010-F0 ST4*1.41*10L Live wire 734S0-6-3480-00 150L Neutral wire...
- Page 50 D9*D5.8*13 Block 849S0-6-4073-00 23.5*10.6*25L Round wheel 84302-6-2175-RA0 D70.5*23,pantone1795C BoltM5*0.8*10L 52605-5-0010-F0 M5*0.8*10L,8.8level ScrewM6*1.0*10L 54006-5-0010-F0 M6*1.0*10L,8.8level Flat washerD25*D10*2.0T 55110-1-2520-FA D25*D10*2.0T BoltM5*0.8*12L 52605-2-0012-F0 M5*0.8*12L Seat tube limit piece 849S0-6-2273-F0 486*19*2T Countersunk small taper 51405-2-0010-F0 M5*0.8*10L screws ScrewM5*0.8*10L 54805-2-0010-N0 M5*0.8*10L,Full Teeth Racer Pro Touch...
- Page 51 ScrewM6*1.0*20L 54006-5-0020-F0 M6*1.0*20L,8.8level ScrewM6*1*12L 54806-2-0012-N0 M6*1*12L Flat washerD13*D6.5*1.0T 55106-1-1310-NA D13*D6.5*1.0T ScrewM5*0.8*20L 54805-2-0020-N0 M5*0.8*20L,Full Teeth Allen nutM5*0.8*5T 55205-2-2005-NA M5*0.8*5T Spring 58003-6-1081-N0 D1.2*D19.6*15.3L Anchor Post 849S0-6-1172-F1 19.7*19.7*14.5L Nut Cap 849S0-6-1171-F0 D30*12L*M24*2.0p L knob 849S0-6-1072-RA0 M12*25L Handle 849S0-6-5103-J2 D25.4*1.4T*373L Cushion 849S0-6-1081-B0 194.3*107*1.2T ScrewST2.3*8L 54723-2-0008-C0 ST2.3*8L ScrewST2.3*12L...
- Page 52 Exploded Drawing Racer Pro Touch...
- Page 53 WARRANTY Products from TAURUS® are subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 54 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. Racer Pro Touch...
- Page 55 CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fitshop.dk info@fitshop.co.uk �� technik@fitshop.de �� �� Åbningstider kan findes på You can find the opening ��...
- Page 56 Visit us also on our social media platforms or our blog! Racer Pro Touch...
- Page 57 Notes...
- Page 58 Notes Racer Pro Touch...
- Page 60 Taurus Racer Pro Touch...
