Summary of Contents for advidia M-26-FW
- Page 1 M-26-FW Network Fixed Dome Cameras Quick Guide V1.00...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Tighten Tighten Tighten Tighten Waterproof tape Wrap the unused cables Wrap the used cables separately together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera User manual Accessory pack Safety Instructions Installation and removal of the unit and its accessories must be carried out by qualified personnel. -
Page 5: Maintenance
During transportation, special attention is required to protect the transparent dome cover from friction, scratch and stain, etc. Do not remove the protective film from the cover until mounting is finished. Remove the protective film before powering on the device. ... -
Page 6: Cable Connection
Cable Connection Power interface Network interface Network NOTE! For specifications, see the latest product datasheets. Mount Your Camera 4.1 Ceiling Mount You can adopt wall mount or pendant mount and purchase hardware accessories separately. The following part takes wall mount as an example. Pendant mount is similar to wall mount and therefore is omitted here. - Page 7 Drill holes on the wall. Use a Ø6-6.5mm drill bit to drill 30 mm-depth guide holes according to the positions marked by stickers. Mount the plastic rivets of self-tapping screws. Knock the plastic rivets into the guide holes and ensure that they are tightened up. Mount the camera.
- Page 8 Adjust the monitoring direction of the lens (tighten screws after vertically adjusting the lens). The lens can horizontally turn by rotating the lens base, as shown by in the following figure. After relaxing the fastening screws, you can vertically turn the lens, as shown by in the following figure. Lens base Fastening...
- Page 9 Mount the transparent dome housing. Align the screw holes in the base, and tighten the three star shape screws on the edge of the transparent dome housing to fix it. NOTE! The preceding installation process is concealed installation, during which holes are drilled in the ceiling and tail cable is led out from the top of the camera.
-
Page 10: Access Your Camera
(purchased separately) to power supply, and then connect the other end to the power interface to start up the device. Access Your Camera Open your Web browser, enter the camera's IP address in the address bar, and then press Enter. The default IP is 192.168.1.13. In the login page, enter the default username and password (admin/123456), then click Login. - Page 11 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
-
Page 12: Network Security
and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus. -
Page 13: Safety Warnings
Disable the automatic login and save password features: If multiple users have access to your computer, it is recommended that you disable these features to prevent unauthorized access. Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. -
Page 14: Regulatory Compliance
Power Requirements Installation and use of the device must be in strict accordance with your local electrical safety regulations. Use a UL certified power supply that meets LPS requirements if an adapter is used. Use the recommended cordset (power cord) in accordance with the specified ratings. ... - Page 15 2013/56/EC. For proper recycling, return the battery to your supplier or to a designated collection point. © i-PRO Co., Ltd. All Rights Reserved. i-PRO, Viewnetcam.com, advidia, VideoInsight, CloUDE, and Unified Digital Evidence are registered trademarks or trademarks of i-PRO Co., Ltd. or i-PRO Americas Inc. in various jurisdictions. All...
