Summary of Contents for advidia M-24-FW-T
- Page 1 M-24-FW-T Network Eyeball Cameras Quick Guide V1.00...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! • Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
-
Page 3: Packing List
5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION! • The cable connector must not be exposed and must be kept away from water. • Restore and fasten the device after dismounting. •... - Page 4 ⚫ Make sure the length of the power cable between the power adapter and the camera is not too long, otherwise the voltage of the camera is lowered, causing the camera to work abnormally. If it is required to lengthen the power cable, lengthen the cable between the power adapter and the mains.
-
Page 5: Mount Your Camera
Mount Your Camera Ceiling Mount You can adopt wall mount or ceiling mount and purchase hardware accessories by yourself. The following part takes wall mount as an example. Wall mount is similar to ceilling mount and therefore is omitted here. 1. -
Page 6: Access Your Camera
6. Mount your camera. Mount the housing with install mark aligned Install mark Install mark 7. Adjust the monitoring direction. Rotate the camera to desired monitoring direction. Startup After you have installed the device, connect one end of the power adapter (purchased separately) to power supply, and then connect the other end to the power interface to start up the device. - Page 7 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
- Page 8 interruption, loss of business information, or any special, direct, indirect, incidental, consequential, pecuniary, coverage, exemplary, subsidiary losses, however caused and on any theory of liability, whether in contract, strict liability or tort (including negligence or otherwise) in any way out of the use of the product, even if our company has been advised of the possibility of such damages (other than as may be required by applicable law in cases involving personal injury, incidental or subsidiary damage).
- Page 9 ⚫ Store or use the device in a proper environment that meets environmental requirements, including and not limited to, temperature, humidity, dust, corrosive gases, electromagnetic radiation, etc. ⚫ Make sure the device is securely installed or placed on a flat surface to prevent falling. ⚫...
- Page 10 2013/56/EC. For proper recycling, return the battery to your supplier or to a designated collection point. © i-PRO Co., Ltd. All Rights Reserved. i-PRO, Viewnetcam.com, advidia, VideoInsight, CloUDE, and Unified Digital Evidence are registered trademarks or trademarks of i-PRO Co., Ltd. or i-PRO Americas Inc.
